用于转子系统的气膜密封阻尼结构稳态特性

王虹; 洪杰; 马艳红

用于转子系统的气膜密封阻尼结构稳态特性

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 航空基金(2006ZB51028); 凡舟青年科研基金(20060403)

计量
- 文章访问数: 1562
- HTML浏览量: 0
- PDF量: 487
- 被引次数: 0
出版历程
- 收稿日期: 2011-03-07
- 修回日期: 2011-06-22
- 刊出日期: 2012-01-28

Steady-state properties of gas film seal damper used in a rotor system

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 针对航空发动机转子既转动又进动的运转情况,推导用于转子系统的带金属橡胶弹性外环的气膜密封阻尼结构(gas film seal damper,GFSD)雷诺方程.基于GFSD运动方程和位移协调关系,建立转子－气膜－金属橡胶三者之间的流固耦合关系,确定稳态压力场求解流程,并提出金属橡胶刚度的定量设计方法.采用有限差分法求解稳态压力场,研究GFSD工作参数和结构参数对稳态特性的影响,为GFSD结构参数设计提供参考,最后与直通式篦齿封严的泄漏量进行比较.结果表明:合理设计金属橡胶刚度能够使GFSD自适应地调节气膜间隙;在保证动压润滑的基础上,选取大长径比、小金属橡胶刚度和密封间隙能够使GFSD具有良好的稳态特性;GFSD的泄漏量远小于直通式篦齿封严,能够满足现代航空发动机中高进出口压比下的封严需要.
- 转子系统 /
- 气膜密封 /
- 金属橡胶 /
- 稳态特性 /
- 参数设计
Abstract: In order to describe the movement of rotor system in an aero-engine that combines the rotation and procession together,the Reynolds equation of gas film seal damper (GFSD) was deducted.The fluid-solid coupling relationship among rotor,gas film and metal rubber ring was constructed based on the movement equation and displacement coordinated relationship,so the solution process of steady-state pressure field was clear and the design method for the stiffness of metal rubber was put forward.The finite difference method was employed to solve the steady-state pressure field,and the effects of working parameters and structural parameters on the steady-state properties were analyzed,which could provide references for the structural design of GFSD,and finally the mass flow-rate between GFSD and straight labyrinth seal was compared.The results show that the appropriate stiffness of metal rubber can make GFSD adjust the clearance of gas film adaptively.In order to maintain a dynamic lubrication condition,the larger the ratio of length and diameter,and the smaller the stiffness of metal rubber and clearance of gas film is,the better the steady-state properties are.The mass flow-ratio of GFSD is much less than that of straight labyrinth seal,and therefore GFSD could meet the requirements of the seals in advanced aero-engines.
- rotor system /
- gas film seal /
- metal rubber /
- steady-state properties /
- parameter design

HTML

参考文献(14)

[1]	陈光.航空发动机结构设计分析[M].北京:北京航空航天大学出版社,2006.
[2]	刘雨川.端面气膜密封特性研究.北京:北京航空航天大学,1999. LIU Yuchuan.Behavior of gas film face seal.Beijing:Beijing University of Aeronautics and Astronautics,1999.(in Chinese)
[3]	Munson J,Pecht G.Development of film riding face seals for gas turbine engine[J].Tribology Transaction,1992,35(1):65-70.
[4]	陈秀琴,朱维兵,王和顺.干气密封技术研究现状及发展趋势[J].液压与气动,2008(2):52-56. CHEN Xiuqin,ZHU Weibing,WANG Heshun.Research status and developing trend of dry gas seal technique[J].Chinese Hydraulics & Pneumatics,2008(2):52-56.(in Chinese)
[5]	Steinetg B M,Hendricks R C.Engine seal technology requirements to meet NASA's advanced subsonic technology program goals.AIAA-94-2698,1994.
[6]	Salehi M,Heshmat H.On the fluid flow and thermal analysis of a complaint surface foil bearing and seal[J].Tribology Transactions,2000,43(2):318-324.
[7]	Salehi M,Heshmat H.Performance of a complaint foil seal in a small gas turbine engine simulator employing a hybrid foil/ball bearing support system[J].Tribology Transactions,2001,44(3):458-464.
[8]	Lattime S B,Braun M J,Chory F K.Design consideration towards the construction of hybrid floating brush seal(HFBS)[J].Tribology International,2004,37(2):159-167.
[9]	马纲,席平,沈心敏,等.柔性支承浮环柱面气膜密封准动态特性分析[J].航空动力学报,2010,25(5):1190-1196. MA Gang,XI Ping,SHEN Xinmin,et al.Analysis of quasi-dynamic characteristics of compliant floating ring gas cylinder seal[J].Journal of Aerospace Power,2010,25(5):1190-1196.(in Chinese)
[10]	洪杰,王虹,马艳红.气膜密封阻尼结构的稳态特性分析[J].北京航空航天大学学报,2011,37(1):6-9,35. HONG Jie,WANG Hong,MA Yanhong.Analysis on gas film stability performance of gas film seal damper[J].Journal of Beijing University of Aeronautics and Astronautics,2011,37(1):6-9,35.(in Chinese)
[11]	MA Yanhong,WANG Hong,LI Haoyu,et al.Study on metal rubber material's characteristics of damping and sound absorption.ASME Paper 2008-GT-50961,2008.
[12]	WANG Hong,Rongong J A,Tomlinson G R,et al.Nonlinear static and dynamic properties of metal rubber dampers.ISMA Paper 2010-0064,2010.
[13]	晏砺堂,朱梓根,宋兆泓,等.结构系统动力特性分析[M].北京:北京航空航天大学出版社,1989.
[14]	林基恕,常春江,杨九高,等.航空发动机手册第12册:传动及润滑系统[M].北京:航空工业出版社,2002.
