下腹板长度对单边膨胀喷管性能的影响

谭杰; 金捷; 杜刚; 徐惊雷

下腹板长度对单边膨胀喷管性能的影响

1.
北京航空航天大学能源与动力工程学院航空发动机数值仿真研究中心, 北京 100191
2.
南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1906
- HTML浏览量: 92
- PDF量: 758
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-09
- 修回日期: 2012-02-09
- 刊出日期: 2012-04-28

Effect of flap length on the performance of single-expansion-ramp-nozzle

1.
Aeroengine Numerical Simulation Research Center, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 在落压比为4~60范围内,对两个不同下腹板长度的单边膨胀喷管模型进行了试验研究,得到了其壁面静压分布,并对4种不同下腹板长度的喷管模型进行了数值模拟研究,获得了总体性能参数.结果表明:在整个落压比范围内,喷管流动都呈现很强的三维特征,而且在高落压比条件下上膨胀面两侧边气流出现了横向分离.喷管轴向推力系数峰值随下腹板长度增大而增加,峰值对应的落压比也逐渐增大并趋近设计点.在落压比为30~80范围内,轴向推力系数随着下腹板长度增大而增加,在设计点轴向推力系数的最大值和最小值相差约1.8%;在特定低落压比条件下,较短下腹板长度的喷管具有高的轴向推力系数.气流矢量角随下腹板长度增加而增大,在设计点最大值和最小值分别为6.03°和-1.83°.
- 单边膨胀喷管 /
- 激波/边界层干扰 /
- 壁面静压分布 /
- 数值模拟 /
- 高超声速飞行器
Abstract: An experimental study of single-expansion-ramp-nozzle (SERN) models has been conducted to investigate how the nozzle flow was affected by the flap length variation at nozzle pressure ratios (NPR) from 4 to 60 under wind off condition.Wall static pressure distributions were obtained.A three-dimensional numerical simulation was also conducted to predict the performance which was unattainable in the test facility of four models with different flap lengths.The results show that the flow exhibits strong three-dimensionality and crossflow separation of the exhaust flow is apparent in the ramp side regions at high NPR.The peak value of the axial thrust coefficient (ATC) increases with the increase of the length of flap;moreover,the corresponding NPR becomes larger and approaches to design NPR.The ATC increases with increasing flap length at NPR between 30 and 80 and the gap between maximum and minimum reaches 1.8% at the design NPR,whereas the model with shorter flap has higher ATC at certain low NPR.The thrust vector angle increases along with the flap length increase,and the maximal and minimal values of the thrust vector reaches 6.03° and -1.83° at the design point respectively.
- single-expansion-ramp-nozzle /
- shock wave/boundary-layer interaction /
- wall static pressure distributions /
- numerical simulation /
- hypersonic vehicle

HTML

参考文献(13)

[1]	Edwards C L,Small W J,Weidner J P,et al.Studies of scramjet/airframe integration techniques for hypersonic aircraft.AIAA 75-58,1975.
[2]	Capone F J.The nonaxisymmetric nozzle:it is for real.AIAA 79-1810,1979.
[3]	Small W J,Weidner J P,Johnston P J.Scramjet nozzle design and analysis as applied to a highly integrated hypersonic research airplane.NASA TN D-8334,1974.
[4]	Ruffin S M,Venkatapathy E,Keener E R,et al.Hypersonic single expansion ramp nozzle simulations [J].Journal of Spacecraft and Rockets,1992,29(2):749-755.
[5]	Huebner L D,Witte D W.Exhaust simulation testing of a hypersonic airbreathing model at transonic speeds.AIAA 2003-7001,2003.
[6]	张堃元,张荣学,徐辉.非对称大膨胀比喷管研究[J].推进技术,2001,22(5):380-382. ZHANG Kunyuan,ZHANG Rongxue,XU Hui.Investigation of single expansion ramp nozzle[J].Journal of Propulsion Technology,2001,22(5):380-382.(in Chinese)
[7]	Capone F J,Re R J,Bare E A.Parametric investigation of single-expansion-ramp-nozzles at Mach numbers from 0.60 to 1.20.NASA TP-3240,1992.
[8]	Gruhn P,Henckels A,Kirschstein S.Flap contour optimization for highly integrated SERN nozzles [J].Aerospace Science and Technology,2000,4(8):555-565.
[9]	徐大军,陈兵,蔡国飙,等.高超声速飞行器后体喷管三维构型设计[J].航空动力学报,2009,24(2):247-254. XU Dajun,CHEN Bing,CAI Guobiao,et al.Design of three dimensional afterbody/nozzle configuration of airbreathing hypersonic vehicle[J].Journal of Aerospace Power,2009,24(2):247-254.(in Chinese)
[10]	谭杰,金捷,杜刚,等.过膨胀单边膨胀喷管试验和数值模拟研究[J].推进技术,2009,30(3):292-296. TAN Jie,JIN Jie,DU Gang,et al.Experimental and computational investigation of a over-expanded single-expansion-ramp nozzle[J].Journal of Propulsion Technology,2009,30(3):292-296.(in Chinese)
[11]	谭杰,金捷,杜刚,等.单边膨胀喷管试验和数值模拟研究[J].航空动力学报,2011,26(6):1223-1230. TAN Jie,JIN Jie,DU Gang,et al.Experimental and computational investigation of single expansion ramp nozzles[J].Journal of Aerospace Power,2011,26(6):1223-1230.(in Chinese)
[12]	谭杰,金捷.跨声速和超声速流中激波/边界层干扰数值模拟[J].推进技术,2010,31(4):394-400. TAN Jie,JIN Jie,DU Gang,et al.Numerical simulation of shock wave/turbulent boundary-layer interactions in transonic and supersonic flows[J].Journal of Propulsion Technology,2010,31(4):394-400.(in Chinese)
[13]	Lederer R,Krüger W.Nozzle development as a key for hypersonics.AIAA 93-5058,1993.
