双楔面诱导的斜爆轰波阵面的磁流体控制

孙晓晖; 陈志华; 薛大文; 沙莎

双楔面诱导的斜爆轰波阵面的磁流体控制

南京理工大学瞬态物理重点实验室, 南京 210014

基金项目: 江苏省高校研究生科研创新计划(CXZZ11_0233); 高等学校博士学科点基金(20103219110037)

计量
- 文章访问数: 1753
- HTML浏览量: 118
- PDF量: 556
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-09
- 修回日期: 2012-02-20
- 刊出日期: 2012-04-28

MHD control of oblique detonation wave front induced by double wedges

Key Laboratory of Transient Physics, Nanjing University of Science and Technology, Nanjing 210014, China

摘要

摘要: 基于高超声速飞行器爆轰推进发展需要,数值研究了由双楔面诱导的斜爆轰波类型及其磁流体(MHD)控制的可行性,探讨了后楔倾角变化对双楔斜爆轰流场与MHD控制的影响.结果表明:对于前、后楔倾角分别为15°与20°的双楔面诱导的斜爆轰,Lorentz力可以将不同来流马赫数条件下的稳定斜爆轰波阵面恢复到设计位置,并可以使不稳定斜爆轰波趋于稳定,但是,无法将不稳定斜爆轰波恢复到设计位置.而当后楔倾角稍微增加时,若爆轰流场稳定,同样可对斜爆轰波阵面进行有效控制.但当后楔倾角大于25°时,稳定斜爆轰波流场失稳,此时MHD无法控制流场稳定性.但若增加气体反应速率,虽然斜爆轰波不稳定,MHD控制却可使其趋于稳定,但无法将爆轰波阵面恢复到设计位置.
- 斜爆轰波 /
- 斜激波 /
- 磁流体 (MHD) /
- 流体控制 /
- 推进
Abstract: Based on the requirement of detonation propulsion of the hypersonic aircraft research,both of the structural types of the oblique detonation waves (ODWs) induced by double wedges and the feasibility of its magnetohydrodynamic (MHD) control of oblique detonation wave (ODW) have been investigated numerically,furthermore,the influences of angle variations of the second ramp on the detonation flow field and MHD control have been discussed.The results show that,for the double wedge detonation with the first and second ramp angles of 15° and 20°,respectively,MHD control can return the position of a stable ODW wave front to its designed location,and can also turn the unstable ODW to be stable,but it is unable to return the unstable ODW front back to the desired place.With the increase of the second ramp angle,the MHD control can also return the ODW front under the condition of a stable ODW.However,when second ramp angle is bigger than 25°,the flow field becomes unstable,and it cannot be manipulated.In this case,with the increase of reaction rate,the ODW stability can be controlled again,but there is no way to return its front to the desired location.
- oblique detonation wave /
- oblique shock wave /
- magnetohydrodynamic (MHD) /
- flow control /
- propulsion

HTML

参考文献(18)

[1]	Valorani M,Digiacinto M,Buongiorno C.Performance prediction for oblique detonation wave engines(ODWE)[J].Acta Astronautica,2001,48(4):211-228.
[2]	Hertzberg A,Bruckner A P,Bogdanoff D W.Ram accelerator:a new chemical method for accelerating projectiles to ultrahigh velocities[J].AIAA Journal,1988,26(2):195-203.
[3]	Yatsufusa T,Taki S.Visualization of burning flow around a ram accelerator projectile by coaxial simultaneous shadow/direct photography[J].Shock Waves,2002,12(3):235-240.
[4]	Hertzberg A,Bruckner A P,Knowlen C.Experimental investigation of ram accelerator propulsion modes[J].Shock Waves,1991,1(1):17-25.
[5]	Grismer M J,Powers J M.Numerical predictions of oblique detonation stability boundaries[J].Shock Waves,1996,6(5):147-156.
[6]	Silva L F F,Deshaies B.Stabilization of an oblique detonation wave by a wedge:a parametric numerical study[J].Combustion and Flame,2000,121(1/2):152-166.
[7]	Berlyand A T,Vlasenko V V,Svishchev S V.Stationary and nonstationary wave structures that arise in stabilization of detonation over a compression surface[J].Combustion,Explosion,and Shock Waves,2001,37(1):82-98.
[8]	QIN Penggao,CHEN Zhihua,SUN Xiaohui,et al.The influences of MHD control direction on the hypersonic inlet flow[J].International Journal of Applied Electromagnetics and Mechanics,2010,33(1/2):55-61.
[9]	Kopchenov V,Vatazhin A,Gouskov O.Estimation of possibility of use of MHD control in scramjet.AIAA 1999-4971,1999.
[10]	Macheret S O,Shneider M N,Miles R B.External supersonic flow and scramjet inlet control by MHD with electron beam ionization.AIAA 2001-0492,2001.
[11]	Soloviev V R,Krivtsov V M,Konchakov A M,et al.Modeling of MHD effects in 2-D planar flow over a wedge.AIAA 2002-2138,2002.
[12]	Sheikin E G,Kuranov A L.MHD controlled inlet for scramjet with various configurations of magnetic field.AIAA 2004-1195,2004.
[13]	Shneider M N,Macheret S O,Miles R B.Comparative analysis of MHD and plasma methods of scramjet inlet control.AIAA 2003-170,2003.
[14]	Van Wie D M,Nedungadi A.Plasma aerodynamic flow control for hypersonic inlets.AIAA 2004-4129,2002.
[15]	SUN Xiaohui,CHEN Zhihua,ZHANG Huanhao.MHD control of oblique detonation waves[J].Chin. Phys. Lett.,2011,28(1):014703.
[16]	Sanders R,Morano E,Druguett M C.Multidimensional dissipation for upwind schemes:stability and applications to gas dynamics[J]. J. Comput. Phys.,1998,145:511-537.
[17]	Mittal R,Iaccarino G..Immersed boundary methods[J].Annu. Rev. Fluid. Mech.,2005,37:239-261.
[18]	Viguier C,Gourara A,Desbordes D.Three-dimensional structure of stabilization of oblique detonation wave in hypersonic flow //Proceedings of the Twenty-Seventh Symposium (International) on Combustion. :The Combustion Institute,1998:2207-2214.
