十字伞伞群的多节点静力学模型动力特性计算

韩雅慧; 杨春信; 徐晓东

十字伞伞群的多节点静力学模型动力特性计算

1.
北京航空航天大学航空科学与工程学院, 北京 100191
2.
陆军航空兵学院机械工程系, 北京 100123
3.
航空装备研究所第一研究室, 北京 100039

计量
- 文章访问数: 1466
- HTML浏览量: 73
- PDF量: 571
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-28
- 修回日期: 2012-02-28
- 刊出日期: 2012-04-28

Multi-node statics model and aerodynamic characteristics of cross parachute clusters

1.
School of Aeronautic Science and Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China
2.
Mechanical Engineering Department, Army Aviation Institute, Beijing 100123
3.
First Research Room, Institute of Aerial Equipment, Beijing 100039, China

摘要

摘要: 为计算某型救灾专用空投系统十字伞伞群的气动特性,建立了多节点静力学模型来计算伞衣充满时的气动外形;对不同臂长比和伞绳比的十字伞进行数值模拟,并与文献中风洞实验结果对比验证;根据建立的模型得到十字伞伞群的气动外形并进行气动力特性研究.结果表明:计算结果和文献结果一致性较好,建立的多节点静力学模型合理可行;十字伞轴向力随臂长比和伞绳比的增大而增大;随攻角增大轴向力先减小后增大,而法向力则增大.建立的模型可用于伞群的气动外形计算,并为降落伞系统的设计提供参考.
- 十字伞 /
- 伞群 /
- 多节点静力学模型 /
- 气动力特性 /
- 数值模拟
Abstract: To calculate clusters’ aerodynamic characteristics for a certain type of disaster relief airdrop system,multi-node statics model of cross parachute system was developed to calculate the aerodynamic shape of canopy.Different cross parachute models were numerically simulated with different canopy arm ratios and suspension line ratios,and the numerical results were compared with test results in literature.According to this model,and aerodynamic shape was obtained for cross parachute clusters,and aerodynamic characteristics were simulated.The results show that:the calculated results and wind tunnel test results in literature are in good agreement,and the multi-node statics model is accurate and feasible.As canopy arm ratio and suspension line ratio of cross parachute increase,the axial force increases;as the angle of attack increases,the axial force firstly decreases and then increases,whereas the normal force increases.This model can be used for calculating aerodynamic shape of parachute clusters,which is also useful for parachute system design.
- cross parachute /
- clusters /
- multi-node statics model /
- aerodynamic characteristics /
- numerical simulation

HTML

参考文献(18)

[1]	王利荣.降落伞理论与应用[M].北京:宇航出版社,1997.
[2]	中国新闻网.地面交通阻碍严重,美军开始向海地空投救灾物资.(2010-01-19).http://www.chinanews.com/gj/gj-bm/news/2010/01-19/2080016.shtml.
[3]	柯鹏.降落伞系统动力学建模和综合仿真.北京:北京航空航天大学,2007. KE Peng.Dynamics modeling and synthetic simulation of parachute system.Beijing:Beijing University of Aeronautics and Astronautics,2007.(in Chinese)
[4]	Shen C Q,Cockrell D J.Aerodynamic characteristics and flow round cross parachutes in steady motion.AIAA-86-2458,1986.
[5]	国家技术监督局.GB/T5453-1997.纺织品织物透气性的测定[S].北京:中国标准出版社,1997.
[6]	Jorgensen D S,Cockrell D J.Aerodynamics and performance of cruciform parachute canopies.AIAA-81-1919,1981.
[7]	Jorgensen D S.Experimental detemination of the input parameters to the parachute equatins of motion.AIAA-84-00798,1984.
[8]	Shen C Q,Cockrell D J.Aerodynamic characteristics and flow round cross parachutes in steady motion[J].Aircraft,1988,25(4):317-323.
[9]	Shen C Q,Cockrell D J.Flow field characteristics around cup-like bluff bodies,parachute canopies.AIAA-91-0855-CP,1991.
[10]	Lafarge R A,James M N,Wgwinn K.A novel CFD/structural analysis of a cross parachute.AIAA-94-0752,1994.
[11]	Stein K,Benney R,Tezduyar T,et al.Fluid-structure interaction action simulation of a cross parachute:comparison of numerical predictions with wind tunnel data.AIAA-99-1725,1999.
[12]	Accorsi M,Leonard J,Benney R,et al.Structural modeling of parcachute dynamics[J].AIAA Journal,2000,38(1):139-146.
[13]	Stein K,Benney R,Tezduyar T,et al.Fluid-structure interactions of a cross parachute:numerical simulation[J].Computer Methods in Applied Mechanics and Engineering,2001,191(6/7):673-687.
[14]	Sathe S,Benney R,Charles R,et al.Fluid-structure interaction modeling of complex parachute designs with the space-time finite element techniques[J].Computer & Fluids,2007,36(1):127-135.
[15]	Render P M,Coulter P R.The stability and aerodynamic perfoumance of clusters of small cruciform parachutes.AIAA-93-1242,1993.
[16]	吴卓,曹义华,宋乾福.锥形降落伞开伞过程流动结构相互作用的数值模拟[J].航空动力学报,2009,24(7):1585-1593. WU Zhuo,CAO Yihua,SONG Qianfu.Numerical simulation of fluid-structure interaction in conical parachute’s opening process[J].Journal of Aerospace Power,2009,24(7):1585-1593.(in Chinese)
[17]	潘星,曹义华.降落伞开伞过程的多结点模型仿真[J].北京航空航天大学学报,2008,34(2):188-192. PAN Xin,CAO Yihua.Simulation of parachute’s opening process with multi-node model[J].Journal of Beijing University of Aeronautics and Astronautics,2008,34(2):188-192.(in Chinese)
[18]	Ke P,Yang C X,Wang Y W.The investigation on a multi-body parachute cluster model.AIAA-2009-2937,2009.
