线性塞式喷管外流干扰数值计算与冷流试验

程诚; 王一白; 刘宇

线性塞式喷管外流干扰数值计算与冷流试验

北京航空航天大学宇航学院, 北京 100191

基金项目: 航天支撑技术基金(0476002)

计量
- 文章访问数: 2034
- HTML浏览量: 187
- PDF量: 634
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-02
- 修回日期: 2011-12-30
- 刊出日期: 2012-04-28

Numerical simulation and cold-flow test of outflow effect on linear aerospike nozzle

School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 采用有限体积法对由塞锥截短率为25%的线性塞式喷管和升力体构成的塞式喷管运载器风洞冷流试验模型进行仿真计算,并结合试验测量结果,研究了不同高度(压比)下外流对线性塞式喷管流场结构和性能的影响.结果表明,外流干扰导致线性塞式喷管内流过膨胀和横向侧流强度增加,并影响塞锥底部气流的受限流动;低空工况下外流的存在造成塞锥壁面和底部压强降低以及运载器底部阻力增加,喷管性能损失较大;高空工况下塞锥壁面和底部的压强已经不再受外流的影响,喷管性能损失较小,主要由运载器底部阻力损失造成.
- 塞式喷管 /
- 外流干扰 /
- 性能损失 /
- 数值模拟 /
- 冷流试验
Abstract: Finite volume method was adopted to get the simulation results of aerospike nozzle vehicle model for cold-flow test in wind tunnel which was composed of a linear plug nozzle truncated rate 25% and a lift body.Simultaneously combined with test measurements,outflow effect on flow field structure and performance of linear plug nozzle at different heights (pressure ratio) were presented.It is shown that outflow interference results in excessive expansion of jet and increase of the intensity of lateral flow in linear aerospike nozzle,and also affect the restricted flow around plug bottom.Under the low-altitude flight conditions,there is a serious loss of nozzle performance caused by pressure decrease on plug wall and at the bottom,and a vehicle base drag increase due to the existence of outflow.Under high-altitude flight conditions,the loss of nozzle performance mainly caused by vehicle base drag loss is small,because the pressure on plug wall and at the bottom is no longer affected by outflow.
- aerospike nozzle /
- outflow interference /
- performance loss /
- numerical simulation /
- cold flow test

HTML

参考文献(12)

[1]	Muss J A,Nguyen T V.Evaluation of altitude compensating nozzle concepts for RLV.AIAA 97-3222,1997.
[2]	Ruf J H,MaConnaughey P K.The plume physics behind aerospike nozzle altitude compensation and slipstream effect.AIAA 97-3218,1997.
[3]	Silver R.Final report,advanced aerodynamic spike configurations:volum 1,analytical and cold flow studies.Rockwell International Corporation,Rocketdyne Division,Report AFRPL-TR-67-246-Vol Ⅰ,Air Force Contract 04(611)-9948,1967.
[4]	Silver R.Final report,advanced aerodynamic spike configurations:volum 2,hot fire investigation:basic,slipstream and liquid TVC.Rockwell International Corporation,Rocketdyne Division,Report AFRPL-TR-67-246-Vol Ⅱ,Air Force Contract 04(611)-9948,1967.
[5]	Hagemann G,Immich H,Terhardt M.Flow phenomena in advanced rocket nozzles-the plug nozzle.AIAA 98-3522,1998.
[6]	Hidemasa M,Akiko M,Takayuki K.Effects of sidewall configurations on rectangular plug nozzle performance.AIAA 2006-4373,2006.
[7]	李军伟,刘宇,王长辉.塞锥侧板对直排塞式喷管性能的影响[J].推进技术,2004,25(3):252-258. LI Junwei,LIU Yu, WANG Changhui.Effects of plug sidewall on linear plug nozzles performance[J].Journal of Propulsion Technology,2004,25(3):252-258.(in Chinese)
[8]	覃粒子,刘宇,王一白.线性塞式喷管型面快速设计方法[J].推进技术,2004,25(2):144-147. QIN Lizi,LIU Yu,WANG Yibai.Rapid method for contour design of linear plug nozzle[J].Journal of Propulsion Technology,2004,25(2):144-147.(in Chinese)
[9]	Dinesh K,Mark P,Venkatapathy E,et al.X-33 Aerothermal Environment Simulations and Aerothermodynamic Design.AIAA 98-868-111,1998.
[10]	Spalart P,Allmaras S.An one-equation turbulence model for aerodynamic flows.AIAA 92-0439,1992.
[11]	Dai W Y,Liu Y,Cheng X C,et al.Analytical and experimental studies of tile-shaped aerospike nozzle[J].Journal of Propulsion and Power,2003,19(4):640-645.
[12]	琚春光,刘宇,覃粒子.塞式喷管效率高度特性分析[J].航空动力学报,2005,20(4):693-697. JU Chunguang,LIU Yu,QIN Lizi.Altitude characteristics analysis of plug nozzle[J].Journal of Aerospace Power,2005,20(4):693-697.(in Chinese)
