平衡气体对乘波体气动力特性影响

曾卫刚; 李维东; 韩汉桥; 雷麦芳; 王发民

平衡气体对乘波体气动力特性影响

中国科学院力学研究所, 北京 100190

计量
- 文章访问数: 2361
- HTML浏览量: 122
- PDF量: 684
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-03
- 修回日期: 2011-07-04
- 刊出日期: 2012-04-28

Equilibrium gas effects on aerodynamic characteristics of waveriders

Institute of Mechanics, Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 通过计算流体动力学(CFD)方法研究了乘波体在平衡气体条件下的气动力性能,并与完全气体条件下的计算结果进行了对比,分析结果表明:平衡气体对乘波体气动性能的影响是由边界层内的化学反应降低了边界层诱导压力而产生的.相对于攻角的影响,平衡气体效应对乘波体升阻比及俯仰力矩的影响并不大,但对压心位置有一定影响;并且平衡气体效应对乘波体气动特性的影响规律有别于其对再入轨道器气动特性的影响规律.研究结果对高空滑翔乘波体飞行器的设计有一定的参考价值.
- 平衡气体 /
- 乘波体 /
- 升阻比 /
- 俯仰力矩 /
- 压心 /
- 黏性干扰
Abstract: The aerodynamic characteristics of waverider under equilibrium gas condition have been studied by computational fluid dynamics(CFD) method,and the results have been compared with that under perfect gas condition.The analysis reveals equilibrium gas effects on aerodynamics of waverider are due to the decrease of induced pressure of boundary layer,which is caused by the chemical reaction in the boundary layer.In comparison with the angle of attack,equilibrium gas affects little on lift to drag ratio and pitching moment coefficients of waverider,but it has some effects on the pressure center,and the effects are different from that on the reentry vehicle.The results are valuable for the design of gliders based on waverider.
- equilibrium gas /
- waveridr /
- lift to drag ratio /
- pitching moment coefficients /
- center of pressure /
- viscous interaction

HTML

参考文献(17)

[1]	Balakrishnan A,Lombard C K,Davy W C.Real-gas flowfields about three-dimensional configurations.Journal of Spacecraft and Rockets,1985,22(1):46-53.
[2]	Balakrishnan A,Davy W C.Viscous real gas flow field about three-dimensional configurations.AIAA-83-1511, 1983.
[3]	Nagaraj N,Lombard C K,Bardina J.Navier-Stokes simulation of 3-D hypersonic equilibrium air flow.AIAA-88-2695,1988.
[4]	Greene F,Weilmuenster K,Micol J.Predicted aerodynamics for a proposed personnel launch vehicle.AIAA-90-1688,1990.
[5]	Maus J R,Griffith B J,Szema K Y,et al.Hypersonic Mach number and real gas effects on space shuttle orbiter.AIAA-83-0343,1983.
[6]	Maus J R,Griffith B J,Szema K Y.Hypersonic Mach number and real gas effects on space shuttle orbiter aerodynamics[J].Journal of Spacecraft,1984,21(2):136-141.
[7]	叶友达.高空高速飞行器气动特性研究[J].力学进展,2009,39(4):387-397. YE Youda.Study on aerodynamic characteristics of high velocity vehicle flying at high altitude[J].Advances in Mechanics,2009,39(4):387-397.(in Chinese)
[8]	叶友达.近空间高速飞行器气动特性研究与布局设计优化[J].力学进展,2009,39(6):683-694. YE Youda.Study on aerodynamic characteristics and design optimization for high speed near space vehicles[J].Advances in Mechanics,2009,39(6): 683-694.(in Chinese)
[9]	Anderson J D,Chang J,Mclaughlin T A.Hypersonic waveriders:effects of chemically reacting flow and viscous interaction.AIAA-92-0302,1992.
[10]	李维东.近空间高超声速乘波体高空多物理效应影响特性研究.北京:中国科学院研究生院,2011. LI Weidong.Studies of near-space multi-physical effects on hypersonic waveriders.Beijing:Graduate University of Chinese Academy of Sciences,2011.(in Chinese)
[11]	Srinivasan S,Tannehill J C,Weilmuenster K J.Simplidied curve fits for the thermodynamic properties of equilibrium air.NASA CR-181245,1986.
[12]	Srinivasan S,Tannehill J C,Weilmuenster K J.Simplidied curve fits for the thermodynamic properties of equilibrium air.NASA RP-1181,1987.
[13]	Tannehill J C,Mugge P H.Improved curve fits for the thermodynamic properties of equilibrium air suitable for numerical computation using time-dependent or shock-capturing methods.NASA CR-2470,1974.
[14]	Srinivasan S,Tannehill J C.Simplidied curve fits for the transport properties of equilibrium air.NASA CR-178411,1987.
[15]	Tannehill J C,Buelow P,Levalts J A.Three-dimensional upwind parabolized Navier-Stokes code for real gas flow.AIAA-89-1654,1989.
[16]	卞阴贵,徐立功.气动热力学[M].合肥:中国科学技术大学出版社,1997.
[17]	Hallgren W F, Anderson J D.The effects of nonequilibrium chemistry on hypersonic viscous interaction.AIAA-91-3323,1991.
