带颗粒减振剂的碰撞阻尼的理论与实验

杜妍辰; 张铭命

带颗粒减振剂的碰撞阻尼的理论与实验

上海理工大学医疗器械与食品学院, 上海 200093

基金项目: 国家自然科学基金(51005157)

计量
- 文章访问数: 1507
- HTML浏览量: 45
- PDF量: 637
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-19
- 修回日期: 2012-02-02
- 刊出日期: 2012-04-28

Theoretical and experimental research on impact damping with fine particles as damping agent

School of Medical Instrument and Food Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China

摘要

摘要: 以两颗粒弹塑性碰撞耗能模型为基础,建立了带颗粒夹击的两球碰撞模型,在此基础上提出了带颗粒减振剂的碰撞阻尼的计算模型,模拟了在带颗粒减振剂的碰撞阻尼作用下的悬臂梁的减振性能.同时对悬臂梁在带颗粒减振剂的碰撞阻尼作用下的减振效果进行实验研究,理论计算结果与实验结果在振动周期、转折点、振幅及共振点迁移等方面均相吻合,验证了提出的模型.得到了以下结论:①带颗粒减振剂的碰撞阻尼的计算模型是可靠的;②带颗粒减振剂的碰撞阻尼具有优秀的减振性能,远远超过单体碰撞阻尼;③带颗粒减振剂的碰撞阻尼对于减小负阻尼的不利影响具有一定的帮助.
- 碰撞阻尼 /
- 颗粒 /
- 减振剂 /
- 塑性变形 /
- 耗能模型
Abstract: Based on the mechanical model of elastic-plastic impact between two spheres,the energy absorption ability of two spheres covered by fine particles during elastic-plastic impact process was predicted,the analysis model of the impact damper with fine particles as damping agent (IDFPDA) was built and the damping performance of a cantilevered beam vibration with IDFPDA was simulated.Experimental studies on the cantilevered beam with IDFPDA were also performed,and the results were in good agreement with the theoretical predictions in vibration period,transition point,amplitude response and resonance transfer,which validated the mechanical models proposed.The following conclusions were drawn through the numerical and experimental studies on the IDFPDA:(1) the analysis model of the IDFPDA proposed is reliable;(2) the IDFPDA has good performance in energy dissipation,which is better than single mass impact damper;(3) the IDFPDA is helpful to alleviate the adverse effects of negative damping.
- impact damping /
- particle /
- damping agent /
- plastic deformation /
- dissipation model

HTML

参考文献(15)

[1]	CHENG Jianlian,XU Hui.Inner mass impact damper for attenuating structure vibration[J].International Journal of Solids and Structures,2006,43(17):5355-5369.
[2]	李伟,胡选利,黄协清,等.柔性约束颗粒阻尼耗能特性研究[J].西安交通大学学报,1997,31(7):23-28. LI Wei,HU Xuanli,HUANG Xieqing,et al.Study on energy dissipation characteristics of granular damping with flexible boundary[J].Journal of Xi’an Jiaotong University,1997,31(7):23-28.(in Chinese)
[3]	Saeki M.Analytical study of multi-particle damping[J]. Journal of Sound and Vibration, 2005,281(3-5):1133-1144.
[4]	MAO Kuanmin,Wang M Y,XU Zhiwei,et al.Simulation and characterization of particle damping in transient vibrations[J].Trans.ASME Journal of Vibration and Acoustics,2004,126(2):202-211.
[5]	Wu C J,Liao W H,Wang M Y.Modeling of granular particle damping using multiphase flow theory of gas-particle[J].Trans.ASME Journal of Vibration and Acoustics,2004,126(2):196-201.
[6]	胡溧,黄其柏,马慰慈.颗粒阻尼减振性能的试验研究[J].噪声与振动控制,2008(5):52-55. HU Li,HUANG Qibai,MA Weici.Experimental research on the damping performance of particle dampers[J].Noise and Vibration Control,2008(5):52-55.(in Chinese)
[7]	周宏伟,陈前.阻尼颗粒动态特性研究[J].南京航空航天大学学报,2008,40(6):742-746. ZHOU Hongwei,CHEN Qian.Experimental investigation on damping particle dynamic characters [J].Journal of Nanjing University of Aeronautics and Astronautics, 2008,40(6):742-746.(in Chinese)
[8]	WANG Shulin.Impact chaos control and stress release:a key for development of ultra fine vibration milling[J].Progress in Natural Science,2002,12(5):336-341.
[9]	XU Zhiwei,WANG M Y,CHEN Tianmin.Particle damping for passive vibration suppression numerical modelling and experimental investigation[J].Journal of Sound and Vibration,2005,279(3/4/5):1097-1120.
[10]	杜妍辰,王树林,朱岩,等.带颗粒减振剂碰撞阻尼的减振特性[J].机械工程学报,2008,44(7):186-189. DU Yanchen,WANG Shulin,ZHU Yan.Vibration characteristics of a new fine particle impact damping[J].Chinese Journal of Mechanical Engineering,2008,44(7):186-189.(in Chinese)
[11]	陆厚根.粉体技术导论[M].上海:同济大学出版社,1998.
[12]	杜妍辰,王树林.代参数法预测颗粒夹击过程中的能量损耗 [J].振动与冲击,2011,30(12):160-163. DU Yanchen,WANG Shulin.Equivalent parameter method for predicting energy dissipation in particle clamping[J].Journal of Vibration and Shock,2011,30(12):160-163.(in Chinese)
[13]	杜妍辰,王树林.两颗粒弹塑性正碰撞的耗散模型[J].机械工程学报,2009,45(2):149-156. DU Yanchen,WANG Shulin.Elastoplastic normal impact dissipation model of two particles elastoplastic normal impact dissipation model of two particles[J].Chinese Journal of Mechanical Engineering,2009,45(2):149-156.(in Chinese)
[14]	龙驭球,包世华.结构力学教程:下册[M].北京:高等教育出版社,1988.
[15]	Rao S S.Mechanical vibrations[M].2nd ed.Reading:Addison-Wesley Publishing Company,1990.
