失谐流体激励下叶盘结构响应特性

辛健强; 王建军

失谐流体激励下叶盘结构响应特性

辛健强,
王建军^,

北京航空航天大学能源与动力工程学院, 北京 100191

基金项目: 国家高技术研究发展计划(2008AA04Z403)

计量
- 文章访问数: 1734
- HTML浏览量: 217
- PDF量: 637
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-18
- 修回日期: 2011-10-26
- 刊出日期: 2012-04-28

Forced response characteristic of bladed disk with aerodynamic mistuning

XIN Jian-qiang,
WANG Jian-jun^,

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 对非均匀静子叶片分布影响下的失谐流体激励叶盘结构响应特性进行研究.首先推导叶盘结构强迫共振条件与流体失谐设计理论;其次对工程叶盘结构响应分析的模态减缩方法和精细积分法进行理论描述;最后给出数值算例,对谐调和失谐流体激励特性和实际工程叶盘的响应特性进行研究,分析流体失谐设计方法对叶盘强迫响应的影响.在响应特性计算中,通过有限元方法得到叶盘的系统质量、阻尼和刚度矩阵后,利用MATLAB软件编制程序进行响应特性分析.
- 流体失谐 /
- 非对称静子 /
- 叶盘结构 /
- 响应特性 /
- 节径谱
Abstract: The forced response characteristic of bladed disk under fluid excitation with aerodynamic mistuning was analyzed.The resonant criterion of bladed disk and the aerodynamic mistuning theory were performed first.Then, the modal reduction theory and the precise integration method were given.Finally, the transient response characteristics of bladed disk under tuned and mistuned fluid excitations were investigated.In this section,the system mass,stiffness and damping matrix were obtained by FEM(finite element method),and MATLAB code was then used to study the response characteristic.
- aerodynamic mistuning /
- asymmetric vane spacing /
- bladed disk /
- response characteristic /
- nodal diameter spectrums

HTML

参考文献(15)

[1]	宋兆泓.航空燃气涡轮发动机强度设计[M].北京:北京航空航天大学出版社,1988.
[2]	王建军,李其汉.航空发动机失谐叶盘振动减缩模型与应用[M].北京:国防工业出版社,2009.
[3]	Castanier M P,Pierre C.Modeling and analysis of mistuned bladed disk vibration:status and emerging directions [J].Journal of Propulsion and Power,2006, 22(2):384-396.
[4]	王建军,李其汉,朱梓根. 失谐叶片-轮盘结构系统振动局部化问题的研究进展[J].力学进展,2000,30(4):517-528. WANG Jianjun,LI Qihan,ZHU Zigen.Vibatory localization of mistuned bladed disk assemblies:a reviwe[J].Advances in Mechnics,2000,30(4):517-528.(in Chinese)
[5]	YAO Jianyao,WANG Jianjun,LI Qihan.Robustness analysis of mistuned bladed disk using the upper bound of structured singular value[J].ASME Journal of Engineering for Gas Turbines and Power, 2009,131(3):032501(7 pages).
[6]	于长波.失谐叶盘结构的建模方法与振动特性研究.北京:北京航空航天大学,2010. YU Changbo.Investigation on the modeling method and vibratory characteristics of mistuned blades disk structures.Beijing: Beijng University of Aeronautics and Astronautics,2010.
[7]	王帅.整体叶盘结构失谐识别方法和动态特性实验研究.北京:北京航空航天大学,2010. WANG Shuai.Mistuning identification theory and dynamic characteristic experiment for integrally bladed disk.Beijing: Beijng University of Aeronautics and Astronautics,2010.
[8]	Kemp R H,Hirschberg M H.Theoretical and experimental analysis of the reduction of rotor blade vibration in turbomachinery through the use of modified stator vane spacing.NACA-TN-4373,1958.
[9]	Gottfried D A,Fleeter S.Passive detuning for HCF reduction.AIAA 2002-3634,2002
[10]	Kaneko Y,Mori K,Okui H.Study on the effect of asymmetric vane spacing on vibratory stress of blade.ASME paper GT-2004-53023,2004.
[11]	孟越,李林,李其汉.气动非谐对叶片非定常气动激振力影响[J].航空动力学报,2007,22(7):1060-1064. MENG Yue,LI Lin,LI Qihan.Unsteady aerodynamic force of blade under aerodynamic mistuned influence[J].Journal of Aerospce Power,2007,22(7):1060-1064.(in Chinese)
[12]	孟越,李林,李其汉.不对称静子叶片非谐方案研究[J].航空动力学报,2007,22(12):2083-2088. MENG Yue,LI Lin,LI Qihan.Asymmetry stator mistuned blade design and research[J].Journal of Aerospace Power,2007,22(12):2083-2088.(in Chinese)
[13]	姚建尧.流体激励下谐调和失谐叶盘结构响应分析.北京:北京航空航天大学,2010. YAO Jianyao.Response analysis for tuned and mistuned bladed disk Under fluid excitation.Beijing: Beijng University of Aeronautics and Astronautics,2010.
[14]	钟万勰.应用力学对偶体系[M].北京:科学出版社,2002.
[15]	Seinturier E,Lombard J P,Dumas M,et al.Forced response prediction methodology for the design of HP compressors bladed disks.ASME paper GT-2004-53372, 2004.
