涡轮带冠叶片干摩擦阻尼减振试验

陈香; 朱靖; 李光辉; 王春健

涡轮带冠叶片干摩擦阻尼减振试验

中国航空工业集团公司中国燃气涡轮研究院, 四川江油 621703

计量
- 文章访问数: 1742
- HTML浏览量: 121
- PDF量: 537
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-22
- 修回日期: 2012-02-09
- 刊出日期: 2012-04-28

Experiment on dry friction damping of shrouded turbine blades

China Gas Turbine Establishment, Aviation Industry Corporation of China, Jiangyou Sichuan 621703, China

摘要

摘要: 设计一套涡轮带冠叶片干摩擦阻尼减振试验系统,并利用该试验系统对阻尼块与叶冠之间不同接触紧度、不同接触面积以及采用不同材料阻尼块时涡轮叶片动力特性和减振效果进行了分析研究.结果表明接触紧度、阻尼块的接触面积、材料以及外部激振力共同影响涡轮叶片的减振效果,共同决定该系统是否存在最优正压力以及最优正压力存在时的范围或大小.另外,激振力的变化将导致叶片的响应、系统阻尼比、共振频率以及最优正压力等一系列参数变化.试验结果能够为理论计算提供数据验证,为指导涡轮带冠叶片的减振设计提供依据.
- 涡轮叶片 /
- 干摩擦 /
- 阻尼 /
- 最优正压力 /
- 试验
Abstract: A dry friction damping test system of shrouded turbine blades was designed.The effects of different mounting tightness and contact areas between damping block, blade shroud and different materials of damping block on dynamical characteristic and damping of the turbine blades were studied with this system.The results show that damping of the turbine blades is affected by mounting tightness,contact area,materials of damping block and excitation force,which also determin whether the damping system has best vertical press,and dominates its range and domain under the existence of best vertical press.Moreover,change of the excitation force can induce the changing a series of experimental parameters,such as response of the turbine blades,damping ratio of the system,resonance frequency and best vertical press.Those results can provide the experimental verification for theoretical arithmetic and provide further insight into damping design of the shrouded turbine blades.
- turbine blade /
- dry friction /
- damping /
- best vertical press /
- experiment

HTML

参考文献(13)

[1]	《航空发动机设计手册》总编委会.航空发动机设计手册(第18册)[M].北京:航空工业出版社,2001.
[2]	单颍春,朱梓根,刘献栋.凸肩结构对叶片的干摩擦研究:理论方法[J].航空动力学报,2006,21(1):168-173. SHAN Yingchun,ZHU Zigen,LIU Xiandong.Investigation of vibration control by frictional constraints between blade shrouds-theoretical method[J].Journal of Aerospace Power,2006,21(1):168-173.(in Chinese)
[3]	Sanliturk K Y,Ewins D J.Modeling two dimensional friction contact and its application using harmonic balance method[J].Journal of Sound and Vibration,1996,193(2):511-523.
[4]	Srinivasan A V,Cutts D G.Dry friction damping mechanisms in engine blades[J].ASME Journal of Engineering for Power,1983,105:332-341.
[5]	Feeri A A,Heek B S.Vibration analysis of dry friction damped turbine blades using singular perturbation theory[J].Journal of Vibration and Acoustics,1998,120(2):588-595.
[6]	Sinha A,Griffin J H.Effects of friction dampers on erodynamically unstable rotor stages[J].AIAA Journal,1985,23(2):262-270.
[7]	Csaba G.Modeling microslip friction damping and its influence on turbine blade vibrations.Linkoping,Sweden:Linkoping University,1998.
[8]	Meng C H,Griffin J H,Bielak J.The forced response of shrouded fan stages[J].ASME Journal of Vibration,Acoustics,Stress,and Reliability in Design,1986,108(1):50-55.
[9]	Yang B D,Meng C H.Modeling of friction contact and its application to the shroud contact[J].Transaction of ASME Journal of Engineering for Gas Turbines and Power,1997,119(4):958-963.
[10]	Yang B D,Chen J J,Meng C H.Prediction of resonant,response of shrouded blades with three-dimensional shroud constraint[J].Transactions of ASME Journal of Engineering for Gas Turbines and Power,1999,121(3):523-529.
[11]	周传月,邹经湘,闻雪友,等.燃气轮机带冠叶片耦合振动分析[J].哈尔滨工业大学学报,2001,33(1):129-133. ZHOU Chuanyue,ZOU Jingxiang,WEN Xueyou,et al.Coupled vibration of gas turbine shrouded blades[J].Journal of Harbin Institute of Technology,2001,33(1):129-133.(in Chinese)
[12]	陈璐璐,马艳红,杨鑫,等.带干摩擦阻尼结构叶片振动响应试验[J].航空动力学报,2008,23(9):1647-1653. CHEN Lulu,MA Yanhong,YANG Xin,et al.Experiment of vibration and response of blade with dry friction structure[J].Journal of Aerospace Power,2008,23(9):1647-1653.(in Chinese)
[13]	李迪,洪杰,陈璐璐,等.带冠涡轮叶片干摩擦阻尼减振试验研究[J].燃气涡轮试验与研究,2008,21(4):22-27. LI Di,HONG Jie,CHEN Lulu,et al.Experiment of dry friction damping effect of shrouded turbine blade[J].Gas Turbine Experiment and Research,2008,21(4):22-27.(in Chinese)
