超声速气流中煤油射流的等离子体点火实验

李飞; 余西龙; 顾洪斌; 陈立红; 张新宇

超声速气流中煤油射流的等离子体点火实验

中国科学院力学研究所温气体动力学国家重点实验室, 北京 100190

基金项目: 国家自然科学基金(10772188,90816015)

计量
- 文章访问数: 1753
- HTML浏览量: 157
- PDF量: 551
- 被引次数: 0
出版历程
- 收稿日期: 2010-07-28
- 修回日期: 2011-10-08
- 刊出日期: 2012-04-28

Experiment on kerosene fueled scramjet ignition by using plasma torch

State Key Laboratory of High Temperature Gas Dynamics, Institute of Mechanics, Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 在直连式超燃实验台上开展来流马赫数为2.5,总温为1650K的液态煤油燃料点火实验.在未使用引导氢气的情况下,利用输入能量为1.5kW的电弧等离子体炬实现煤油可靠点火和稳定燃烧.研究了煤油的不同喷注位置、喷射压力对点火性能的影响.实验表明:燃料喷口距离点火凹腔为550mm,喷射压力为1.5~2.3MPa时,可成功点火,更近的喷射位置和更高的喷射压力无法点火,分析认为点火凹腔的局部混合特征是影响点火的关键因素.根据点火和火焰前传的高速摄影图,发现下游凹腔在点火初期的作用不大,但是对于稳定燃烧和火焰前传有重要作用.
- 超燃冲压发动机 /
- 煤油 /
- 等离子体火炬 /
- 点火 /
- 火焰传播
Abstract: Liquid kerosene ignition was explored in a direct-connected scramjet test facility,that the entrance flow Mach number of the combustor was 2.5,and the total temperature was 1650K.Using a plasma torch with 1.5kW input power,kerosene ignition and sustain combustion realized without any pilot hydrogen.Fuel injection pressure and injector location were investigated as factors affecting the ignition performance.The test results indicate that successful ignition can be achieved when the injectors are located 550mm,upstream the ignition cavity and the fuel injection pressure is between 1.5-2.3MPa.It is also found that higher injection pressure and shorter distance between injection location and the cavity brings negative effects to ignition.Therefore,local fuel-air-ratio is considered as one of the main factors of ignition.Based on the high-speed images of ignition and combustion,it is indicated that the downstream cavity does not advance ignition at the beginning period of the ignition but is very important for sustain combustion and flame propagation.
- scramjet /
- kerosene /
- plasma torch /
- ignition /
- flame propagation

HTML

参考文献(12)

[1]	李大鹏,潘余,吴继平,等.几何可调侯道双模态冲压发动机点火过程实验研究[J].弹箭与制导学报,2006,26(4):210-214. LI Dapeng,PAN Yu,WU Jiping,et al.Ignition experimental study of a variable geometrical throat dual-model ramjet[J].Journal of Projectiles;Rockets;Missiles and Guidance,2006,26(4):210-214.(in Chinese)
[2]	潘余,李大鹏,刘卫东,等.变几何喉道对超燃冲压发动机点火与燃烧性能的影响木[J].推进技术,2006,27(3):225-229. PAN Yu,LI Dapeng,LIU Weidong,et al.Variable geometry effects on the scramjet ignition and combustion[J].Journal of Propulsion Technology,2006,27(3):225-229.(in Chinese)
[3]	丁猛,余勇,梁剑寒,等.碳氢燃料超燃冲压发动机点火技术实验[J].推进技术,2004,25(6):566-569. DING Meng,YU Yong,LIANG Jianhan,et al.Experimental investigation of ignition technology in liquid hydrocarbon fueled scramjet combustor[J].Journal of Propulsion Technology,2004,25(6):566-569.(in Chinese)
[4]	Jacobsen L S,Caeter C D,Jackson T A,et al.Plasma-assisted ignition in scramjets[J].Journal of Propulsion and Power,2008,24(4):641-654.
[5]	Jacobsen L S,Gallimore S D,Schetz J A,et al.Integrated aeroramp injector/plasma-igniter for hydrocarbon fuels in a supersonic flow Part A:experimental studies of the geometrical configuration.AIAA Paper 2001-1766,2001.
[6]	Gallimore S D,Jacobsen L S,O’brien W F,et al.Integrated aeroramp injector/plasma-igniter for hydrocarbon fuels in a supersonic flow Part B:experimental studies of the operating conditions.AIAA Paper 2001-1767.2001.
[7]	Wagner T C,O’brien W F,Northam G B,et al.Plasma torch igniter for scramjets[J].Journal of Propulsion and Power,1989,5(5):548-554.
[8]	Leonov S B,Yarantsev D A.Plasma-induced ignition and plasma-assisted combustion[J].Plasma Sources Science and Technology,2007,16(1):132-138.
[9]	Billingsley M C,O’brien W F,Schetz J A,et al.Plasma torch atomizer-igniter for supersonic combustion of liquid hydrocarbon fuels.AIAA 2006-7970,2006.
[10]	宋文艳,刘伟雄,贺伟,等.超声速燃烧室等离子体点火实验研究[J].实验流体力学,2006,20(4):20-24. SONG Wenyan,LIU Weixiong,HE Wei,et al.Experimental investigation of plasma ignition in supersonic combustor[J].Journal of Experiments in Fluid Mechnics,2006,20(4):20-24.(in Chinese)
[11]	GU Hongbin,CHEN Lihong,CHANG Xinyu.Experimental investigation on the cavity-based scramjet model[J].Chinese Science Bulletin,2009,54(16):2794.
[12]	仝颖刚.等离子体增强超声速燃烧的实验研究.北京:中国科学院力学研究所,2010. TONG Yinggang.Experimental research on plasma-assisted combustion in supersonic flow.Beijing:Institute of Mechanics,Chinese Academy of Sciences,2010.(in Chinese)
