液体火箭发动机再生冷却槽寿命预估

杨进慧; 陈涛; 金平; 蔡国飙

液体火箭发动机再生冷却槽寿命预估

北京航空航天大学宇航学院, 北京 100191

计量
- 文章访问数: 1651
- HTML浏览量: 68
- PDF量: 510
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-11
- 修回日期: 2011-06-29
- 刊出日期: 2012-04-28

Life prediction of cooling passage for reusable liquid rocket engine

School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 基于有限元热结构耦合计算结果分析了液体火箭发动机再生冷却槽的失效形式,并分别采用Porowski模型及其蠕变修正模型对冷却槽进行寿命预估.结果表明冷却槽寿命主要取决于塑性拉伸不稳定失效;蠕变对寿命有一定影响,是寿命预估不可或缺的一部分;减小外壳与内壁的温差幅值、增大每个冷却槽的肋宽比或增加冷却槽数目可以延长寿命.该寿命预估方法可用于指导可重复使用液体火箭发动机再生冷却槽设计.
- 可重复使用 /
- 冷却槽 /
- 塑性拉伸不稳定 /
- 低周疲劳 /
- 蠕变 /
- 寿命
Abstract: The thrust chamber life is mainly limited by the cooling passage failure,which is caused by fatigue,creep rupture and plastic tensile instability.Based on the analysis of coupled heat transfer and stress,the Porowski method was taken to perform life prediction of the reusable liquid rocket engine cooling passage.The life of nozzle throat liner was mainly determined by the plastic tensile instability,whereas the effect of creep damage can not be ignored in the life prediction procedure.Reducing the temperature difference between the ligament and closeout and increasing the width ratio of each passage or the passage number were all in favor of prolonging the life of cooling passage.The method used for predicting the cooling passage life can provide reliable criterion for the design of reusable rocket engine.
- reusable /
- cooling passage /
- plastic tensile instability /
- low cycle fatigue /
- creep /
- life

HTML

参考文献(16)

[1]	Dai X,Ray A.Damage-mitigating control of a reusable rocket engine Part Ⅰ:life prediction of the main trust chamber wall[J].Journal of Dynamic Systems,Measurement,and Control,1996,118(3):401-408.
[2]	Riccius J,Haidn O J,Zametaev E B.Influence of time dependent effects on the estimated life time of liquid rocket combustion chamber walls.AIAA 2004-3670,2004.
[3]	Sung I K,Anderson W.A subscale-based rocket combustor life prediction methodology.AIAA 2005-3570,2005.
[4]	Porowski J S,Badiani M,Kasrale B,et al.Development of a simplified procedure for thrust chamber life prediction.NASA CR-165585,1981.
[5]	Badlani M L,Porowski J S.Development of a simplified procedure for thrust chamber life prediction with creep.NASA CR-168261,1983.
[6]	Dai X,Ray A.Life prediction of the thrust chamber wall of a reusable rocket engine[J].Journal of Propulsion and Power,1995,11(6):1279-1287.
[7]	Kasper H J.Thrust chamber life prediction.NASA CP-2372,1984.
[8]	Quentmeyer R J.Rocket combustion chamber life-enhancing design concepts.AIAA 1980-2116,1990.
[9]	Quentmeyer R J.Experimental fatigue life investigation of cylindrical thrust Chambers.AIAA 1977-893,1977.
[10]	休泽尔.现代液体火箭发动机工程设计[M].北京:中国宇航出版社,2004.
[11]	杨世铭,陶文铨.传热学[M].北京:高等教育出版社, 2002.
[12]	栾叶君,孙纪国,田昌义,等.氢氧推力室再生冷却内壁故障分析[J].火箭推进,2006,32(5):17-21. LUAN Yejun,SUN Jiguo,TIAN Changyi,et al.Failure analysis on regeneratively cooled wall of a hydrogen-oxygen thrust chamber[J].Journal of Rocket Propulsion, 2006,32(5):17-21.(in Chinese)
[13]	Kuhl D,Woschnak A,Haidn O J.Coupled heat transfer and stress analysis of rocket combustion chambers.AIAA 1998-3373,1998.
[14]	陈传尧.疲劳与断裂[M].武汉:华中科技大学出版社,2005.
[15]	Arya V K,Arnoldt S M.Viscoplastic analysis of an experimental cylindrical thrust chamber line[J].AIAA Journal, 1992,30(3):781-789.
[16]	Popp M,Schmidt G.Rocket engine combustion chamber design concepts for enhanced life.AIAA 1996-3303, 1996.
