静-转叶排轴向间距对某跨声速压气能的影响

史亚锋; 吴虎; 徐倩楠; 宋石平

静-转叶排轴向间距对某跨声速压气能的影响

西北工业大学动力与能源学院, 西安 710072

计量
- 文章访问数: 1638
- HTML浏览量: 107
- PDF量: 554
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-30
- 修回日期: 2012-01-13
- 刊出日期: 2012-04-28

Effect of stator-rotor blade row axial spacing on transonic axial compressor performance

School of Power and Energy, Northwestern Polytechnical University, Xi’an 710072, China

摘要

摘要: 对两种轴向间距下某跨声速轴流压气机静子-转子叶排间的流场进行了定常数值模拟,结果表明:在大流量工作状态下,近轴向间距时的效率较远轴向间距时有明显降低;在高负荷工作状态下,两者的效率相差不大.对大流量工况点与高负荷工况点的流场非定常数值模拟结果表明:近轴向间距时转子前缘激波对上游静子叶片附面层的干扰要强烈的多;近轴向间距时上游静子尾迹对在高负荷工况点动叶叶尖处出现的二次泄漏有更强的抑制作用,能更有效的减弱叶尖泄漏流造成的堵塞和损失.
- 轴向间距 /
- 压气机 /
- 尾迹 /
- 二次泄漏 /
- 干扰
Abstract: The steady flow field of stator-rotor blade rows has been numerically simulated,and the computational results show the far axial spacing between blade rows can improve compressor efficiency near the choked mass flow,and the efficiency does not matter with the axial spacing at high loading.The numerical simulation results of unsteady flow field show the close axial spacing can enlarge the interaction of rotor shock on the stator boundary layer and more efficiently suppress the rotor tip double-leakage at high loading which can cause tip blockage and loss.
- axial spacing /
- compressor /
- wake /
- double-leakage /
- interaction

HTML

参考文献(13)

[1]	Ottavy X,Trebinjac I,Vouillarmet A.Analysis of the interrow flow field within a transonic axial compressor Part1:experimental investigation[J].ASME Journal of Turbomachinery,2001,123(1):49-56.
[2]	Ottavy X,Trebinjac I,Vouillarmet A.Analysis of the interrow flow field within a transonic axial compressor Part 2:unsteady flow analysis[J].ASME Journal of Turbomachinery,2001,123(1):57-63.
[3]	李绍斌,苏杰先,冯国泰.动静叶干扰下跨声压气机级性能与叶片型面静压研究[J].航空动力学报,2007,22(7):1153-1160. LI Shaobin,SU Jiexian,FENG Guotai.Study of performance and profile pressure distribution of transonic compressor under rotor-stator interaction condition[J].Journal of Aerospace Power,2007,22(7):1153-1160.(in Chinese)
[4]	党政,席光,王尚锦.轴向间隙对动/静相干叶排内部非定常特性的影响[J].工程热物理学报,2000,21(5):584-586. DANG Zheng,XI Guang,WANG Shangjin.Axial spacing effects on unsteady rotor/stator interaction flow[J].Journal of Engineering Thermophysics,2000,21(5):584-586.(in Chinese)
[5]	Gorrell S E,Okiishi T H,Copenhaver W W.Stator-rotor interactions in a transonic compressor Part 1:effect of blade-row spacing on performance[J].ASME Journal of Turbomachinery,2003,125(2):328-335.
[6]	Gorrell S E,Okiishi T H,Copenhaver W W.Stator-rotor interactions in a transonic compressor Part 2:effect of blade-row spacing on performance[J].ASME Journal of Turbomachinery,2003,125(2):336-345.
[7]	陈浮,陆华伟,顾中华,等.轴向间隙对压气机时序效应影响之一:总性能[J].工程热物理学报,2007,28(2):232-234. CHEN Fu,LU Huawei,GU Zhonghua.Clocking effect of compressor with different axial gaps Part 1:overall performance[J].Journal of Engineering Thermophysics, 2007,28(2):232-234.(in Chinese)
[8]	陈浮,陆华伟,顾中华,等.轴向间隙对压气机时序效应影响之二:截面特性[J].工程热物理学报,2007,28(5):769-771. CHEN Fu,LU Huawei,GU Zhonghua.Clocking effect of compressor with different axial gaps Part 2:traverse measurement results[J].Journal of Engineering Thermophysics,2007,28(5):769-771.(in Chinese)
[9]	李传鹏,胡骏,张燎原,等.轴向间距变化对轴流压气机全流量特性的影响[J].推进技术,2004,25(6):508-511. LI Chuanpeng,HU Jun,ZHANG Liaoyuan,et al.Effects of axial spacing on compressor performance in all flow range[J].Journal of Propulsion Technology,2004,25(6):508-511.(in Chinese)
[10]	张环,胡骏,李传鹏,等.轴向间距对压气机气动稳定性的影响[J].航空动力学报,2005,20(1):120-124. ZHANG Huan,HU Jun,LI Chuanpeng et al.Effect of axial spacing between rotor and stator on axial compressor stability[J].Journal of Aerospace Power,2005,20(1):120-124.(in Chinese)
[11]	Sanger N L.Performance of a 1.57-pressure-ratio transonic fan stage with a screen-induced 90°circumferential inlet flow distortion.NASA TN-D8163,1975.
[12]	Denton J D.Loss mechanisms in turbomachines[J].ASME Journal of Turbomachinery,1993,115(4):621-656.
[13]	Sirakov B T,Tan C S.Effect of unsteady stator wake-rotor double-leakage tip clearance flow interaction on time-average compressor performance[J].ASME Journal of Turbomachinery,2003,125(3):465-474.
