基于多层优化策略的涡轮盘叶设计研究

王荣桥; 贾志刚; 杨俊杰; 胡殿印; 樊江; 申秀丽

基于多层优化策略的涡轮盘叶设计研究

北京航空航天大学能源与动力工程学院,北京 100191

计量
- 文章访问数: 1761
- HTML浏览量: 3
- PDF量: 717
- 被引次数: 0
出版历程
- 收稿日期: 2011-08-04
- 刊出日期: 2012-06-28

Study on disk and blade design based on multi-layer optimization strategy

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 针对涡轮多学科优化设计,将多层优化策略中的重要原则学科自治扩展到组件自治;并结合目前的多学科优化策略BLISS(bi-level integrated system synthesis)2000和CO(collaborative optimization)以及ATC(analytical target cascading),设计出新的多学科优化框架.利用BLISS2000建立了涡轮盘叶的两层双子系统优化框架和两层三子系统的优化框架;结合BLISS2000和CO各自的优点构建了三层三子系统优化框架;从定性的分析角度排除了ATC在涡轮多学科多层优化设计上的应用.通过对比分析,三子系统的多层优化策略的优势主要体现在优化效率方面;层与层之间存在复杂的交互迭代过程导致三层系统往往比双层系统表现出差的精度和效率.
- 多学科优化设计 /
- 多层优化策略 /
- 涡轮盘叶 /
- 学科自治 /
- 组件自治
Abstract: For the turbine multi-discipline optimization (MDO) design,the important principle of MDO firstly extended to component autonomy from disciplinary autonomy.Based on these principles,four kinds of MDO frameworks,which were applied on the turbine design,combining present MDO strategies including BLISS(bi-level integrated system synthesis)2000,CO(collaborative optimization) and ATC(analytical target cascading) were designed.Both the two-layer including double-subsystem strategy and the two-layer including triple-subsystem strategy were built by BLISS2000 strategy as the two-layer framework for turbine design,while the three-layer including triple-subsystem strategy gave the full play to the merits of BLISS2000 and CO strategies.The ATC optimization strategy required huge extra optimization cost,so it is not qualitatively suitable for triple-layer MDO strategy on turbine.After testing,the preponderance of the multi-layer optimization strategies including three subsystems is higher efficiency,while complex interactions between layers always lead to worse optimization accuracy and efficiency on three layers strategy compared with two layers strategy.
- multi-discipline optimization (MDO) design /
- multi-layer design strategy /
- turbine disk and blade /
- disciplinary autonomy /
- component autonomy

HTML

参考文献(12)

[1]	杨俊杰,王荣桥,樊江,等.涡轮叶片的气动-热-结构多学科设计优化研究[J].航空动力学报,2010,25(3):617-622. YANG Junjie,WANG Rongqiao,FAN Jiang,et al.Multi-disciplinary aerodynamic-thermal-structure design optimization for turbine blade[J].Journal of Aerospace Power,2010,25(3):617-622.(in Chinese)
[2]	Sellar R S,Batill S M,Renaud J E.Response surface based,concurrent subspace optimization for multidisciplinary system design .AIAA-96-0714,1996.
[3]	Braun R D,Gage P J,Kroo I M,et al.Implementation and performance issues in collaborative optimization .NASA-AIAA-96-4017,1996.
[4]	Sobieszczanski-Sobieski J,Altus T D,Phillips M,et al.Bi-level integrated system synthesis (BLISS) for concurrent and distributed processing .Atlanta,Georgia:9th AIAA/ISSMO Symposium on Multidisciplinary Analysis and Optimization,AIAA,2002.
[5]	Kim H M,Michelena N F,Papalambros P Y,et al.Target cascading in optimal system design[J].Transactions of the ASME,2003,125(9):474-480.
[6]	Dennis J E,Lewis R M.Problem formulations and other optimization issues in multidisciplinary optimization .Colorado Springs:AIAA Symposium on Fluid Dynamics,AIAA,1994.
[7]	Cramer E J,Dennis J E,Jr,Frank P D,et al.Problem formulation for multi-disciplinary optimization[J].SIAM Journal of Optimization,1994,13(4):754-776.
[8]	Jun S,Jeon Y H,Rho J.Application of collaborative optimization using response surface methodology to an aircraft wing design .AIAA 2004-4442,2004.
[9]	De Baets P W G,Mavris D N.Aeroelastic design by combining conventional practice with bi-level integrated system synthesis(BLISS) .Albany,New York:10th AIAA/ISSMO Multidisciplinary Analysis and Optimization Conference,AIAA,2004.
[10]	Chen X,Hasselman T K,Neill D.Reliability based structural design optimization for practical applications .Kissimmee,FL,USA:The AIAA/ASME/ASCE/AHS/ASC 37th Conferences in Structures,Structural Dynamics and Materials,AIAA,1997.
[11]	田文正,王荣桥.基于MDO体系的涡轮叶片热-结构耦合分析[J].航空发动机,2008,34(2):5-9. TIAN Wenzheng,WANG Rongqiao.Coupled thermal-structural analysis of turbine blade based on MDO system[J].Aeroengine,2008,34(2):5-9.(in Chinese)
[12]	Michelena N,Park H,Papalambros P.Convergence properties of analytical target cascading .Atlanta,Georgia:9th AIAA/ISSMO Symposium on Multidisciplinary Analysis and Optimization,AIAA,2002.
