一种槽道式处理机匣的准定常流动模型Ⅱ: 跨声转子处理机匣的优化设计

樊琳; 宁方飞; 刘火星

一种槽道式处理机匣的准定常流动模型Ⅱ: 跨声转子处理机匣的优化设计

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 国家自然科学基金(50506001)

计量
- 文章访问数: 1460
- HTML浏览量: 6
- PDF量: 563
- 被引次数: 0
出版历程
- 收稿日期: 2012-02-16
- 刊出日期: 2012-06-28

Quasi-steady flow model of slot-type casing treatments Ⅱ: design optimization of casing treatment for a transonic rotor

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 对带气室的槽道式处理机匣的结构进行了参数化,然后采用所发展的处理机匣流动模型对槽道式处理机匣进行了数值模拟分析,获得了槽道式处理机匣各主要结构参数对处理机匣扩稳作用和转子效率的影响.基于原基准处理机匣,并选取各个结构参数经分析得到的最优值设计了一个优化的处理机匣.实验结果表明:优化的处理机匣设计在60%,80%,98%设计转速下都在原基准处理机匣的基础上进一步提高了转子的失速裕度,并且带有优化处理机匣的转子峰值效率比基准处理机匣、甚至实壁机匣的情形都有所提高.另外,为考察处理机匣槽道数的影响,对一个在优化处理机匣的基础上缩减槽道数而得到的处理机匣设计也进行了实验研究.
- 航空发动机 /
- 轴流压气机 /
- 处理机匣 /
- 结构参数 /
- 优化设计
Abstract: A geometrical parameterization method for the slot-type casing treatment was presented.The relation between a set of key geometrical parameters and the casing treatment performance was obtained based on the numerical simulations of the slot-type casing treatments using the developed quasi-steady casing treatment flow model.Then,an optimized casing treatment was obtained based on the previously designed baseline casing treatment and by the selection of the optimal geometrical parameters.The subsequent experiment shows that the optimized casing treatment can further improve the stall margin over that using the baseline casing treatment.Moreover,the rotor peak efficiency using the optimized casing treatment is also improved the speeds of at 60%,80% and 98% as compared to that of the baseline casing treatment case and even the solid built.Additionally,to investigate the effect of the number of slots,the experimental study of a casing treatment which was the same as the optimized one but with different slot number was also performed.
- aero-engine /
- axial compressor /
- casing treatment /
- geometrical parameters /
- design optimization

HTML

参考文献(15)

[1]	Takata H,Tsukuda Y.Stall margin improvement by casing treatment:its mechanism and effectiveness[J].Journal of Engineering for Power,1977,99(1):121-133.
[2]	Fujita H,Takata H.A study of configurations of casing treatment for axial flow compressors[J].Bulletin of the JSME,1984,27(230):1675-1681.
[3]	Smith G D J,Cumpsty N A.Flow phenomena in compressor casing treatment[J].Journal of Engineering for Gas Turbines and Power,1985,106(3):532-541.
[4]	Azimian A R,Elder R L,McKenzie A B.Application of recess vaned casing treatment to axial flow fans[J].Journal of Turbomachinery,1990,112(1):145-150.
[5]	Crook A J,Greitzer E M,Tan C S,et al.Numerical simulation of compressor endwall and casing treatment flow phenomena[J].Journal of Turbomachinery,1993,115(3):501-512.
[6]	Hall E J,Crook A J,Delaney R A.Aerodynamic analysis of compressor casing treatment with a 3-D Navier-Stokes solver .AIAA-94-2796,1994.
[7]	Wilke I,Kau H P.A numerical investigation of the influence of casing treatments on the tip leakage flow in a hpc front stage .ASME Paper,GT-2002-30642,2002.
[8]	Wilke I,Kau H P,Brignole G.Numerically aided design of a high-efficient casing treatment for a transonic compressor .ASME Paper GT-2005-68993,2005.
[9]	Seitz P A.Casing treatment for axial flow compressors .Cambridge,England:Cambridge University,1999.
[10]	Emmrich R,Honen H,Niehuis R.Time resolved investigations of an axial compressor with casing treatment Part 1:experiment .ASME Paper GT-2007-27581,2007.
[11]	吴昌明,刘大凯.处理机匣特征参数变化对多级轴流压气机性能的影响[J].航空发动机,1997(1):38-43. WU Changming,LIU Dakai.Influence of characteristic parameters of casing treatment to the performance of multistage compressor[J].Aeroengine,1997(1):38-43.(in Chinese)
[12]	LU Xingen,CHU Wuli,ZHU Junqiang,et al.Mechanism of the interaction between casing treatment and tip leakage flow in a subsonic axial compressor .ASME Paper GT2006-90077,2006.
[13]	张燕东,陆亚钧.圆弧斜槽处理机匣的实验研究[J].航空动力学报,1998,13(3):254-258. ZHANG Yandong,LU Yajun.An experimental investigation on arc skewed slot casing treatment[J].Journal of Aerospace Power,13(3):254-258.(in Chinese)
[14]	祝剑虹,朴英,周建兴,等.跨声压气机缝式处理机匣非定常模拟研究[J].航空动力学报,2008,23(5):882-888. ZHU Jianhong,PIAO Ying,ZHOU Jianxing,et al.Unsteady numerical simulation on transonic compressor with screwed slots casing treatment[J].Journal of Aerospace Power,23(5):882-888.(in Chinese)
[15]	Prince D C,Jr,Wisler D C,Hilvers D E.A study of casing treatment stall margin improvement phenomena .NASA Report,NASA-CR-134552,1974.
