轴流涡轮基元级动叶稠度特性的数值研究

杨杰; 乔渭阳; 侯伟涛; 魏佐君

轴流涡轮基元级动叶稠度特性的数值研究

西北工业大学动力与能源学院,西安 710072

计量
- 文章访问数: 1876
- HTML浏览量: 104
- PDF量: 554
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-20
- 刊出日期: 2012-06-28

Numerical study on the rotor solidity characteristics of axial turbine element stages

School of Power and Energy, Northwestern Polytechnical University,Xi'an 710072,China

摘要

摘要: 利用商用软件数值模拟了5个不同动叶稠度的轴流涡轮基元级的非定常流动情况,以研究动叶稠度对轴流涡轮基元级性能和流动情况的影响.通过对动叶稠度对基元级反力度、叶片进出口气流角、转子和静子中的流场及损失影响情况的考察研究,发现动叶稠度的改变对涡轮基元性能和流动情况的影响与静叶稠度存在重要关系.静叶稠度不变时,动叶稠度的改变通过影响流过涡轮基元级的流量来使基元级的反力度发生变化.当动叶稠度过大时,气流在转子中会过度膨胀加速而产生激波损失及其与附面层干涉形成的流动分离损失.动叶稠度过小时,转子进口会出现极大的正攻角致使动叶吸力面发生大范围的流动分离.静叶稠度一定时,存在一个最佳的动叶稠度,使涡轮基元级呈现最好的性能.
- 轴流涡轮 /
- 动叶 /
- 静叶 /
- 稠度 /
- 反力度 /
- 激波 /
- 流动分离 /
- 损失
Abstract: To explore the influence of the rotor solidity on the axial turbine element stage flow status and performance,unsteady numerical simulations on the turbine element stages with five different rotor solidity were conducted,and the rotor solidity influence on the element stage reaction,blade inlet and outlet flow angles,stator and rotor flow fields and loss status was investigated.The research results indicate that the effects of the rotor solidity alteration on the turbine element stage flow status and performance are directly associated with the stator solidity.When the stator solidity remains constant,The rotor solidity alteration changes the turbine element stage reaction by changing the mass flow rate through the element stage.As the rotor solidity increased to a certain extent,shocks will arise from the excessive expansion and acceleration of the gas flow in the stator region,as well as the flow separation caused by the shock interaction with the boundary layer.As the rotor solidity reduced to a certain extent,an large positive flow incidence will occur at the rotor inlet and cause a great range of flow separation on the rotor suction side.When the stator solidity remains constant,there's one best rotor solidity,resulting in the best turbine element stage performance.
- axial turbine /
- rotor /
- stator /
- solidity /
- reaction /
- shock /
- flow separation /
- loss

HTML

参考文献(15)

[1]	廖红桃,赛庆毅,杨爱玲,等.扩压器稠度对离心压缩机性能影响的数值分析[J].风机技术,2010(3):3-6. LIAO Hongtao,SAI Qingyi,YANG Ailing,et al.Numerical analysis on performance of centrifugal compressor with different solidity diffusers[J].Compressor,Blower & Fan Technology,2010(3):3-6.(in Chinese)
[2]	Abdelwahab A.An airfoil diffuser with variable stagger and solidity for centrifugal compressor applications .ASME Paper GT2007-27920,2007.
[3]	陈浮,宋彦萍,赵桂杰,等.附面层吸除对压气机叶栅稠度特性影响[J].工程热物理学报,2005,26(2):211-215. CHENG Fu,SONG Yanping,ZHAO Guijie,et al.Effects of boundary layer suction on the performance of compressor cascade with different solidities[J].Journal of Engineering Thermophysics,2005,26(2):211-215.(in Chinese)
[4]	张永军,冯国泰.跨音速压气机叶栅中稠度对弯掠叶栅流场影响的数值分析[J].热能动力工程2007,22(3):237-240. ZHANG Yongjun,FENG Guotai.A numerical analysis of the impact of solidity on bowed and swept cascade flow fields in a transonic compressor cascade[J].Journal of Engineering for Thermal Energy & Power,2007,22(3):237-240.(in Chinese)
[5]	赵养正,刘前智.轴流压缩机动静叶不同稠度组合对性能的影响[J].风机技术,2007(6):3-7. ZHAO Yangzheng,LIU Qianzhi.The effects of solidity of rotor-stator cascades on axial-flow compressor performance[J].Compressor,Blower & Fan Technology,2007(6):3-7.(in Chinese)
[6]	Simpson A,Spence S,Watterson J.Numerical and experimental study of the performance effects of varying vaneless space and vane solidity in radial inflow turbine stators .ASME Paper GT2008-50261,2008.
[7]	Tashima T,Sasaki T,Kalfas A I,et al.Blade loading influence on unsteady flow interactions in axial steam turbines .AMSE Paper GT2007-27452,2007.
[8]	周莉,张鑫,蔡元虎.轴向间距对涡轮损失影响的非定常数值研究[J].航空动力学报,2010,25(7):1595-1601. ZHOU Li,ZHANG Xin,CAI Yuanhu.Unsteady numerical investigation of the influence of axial gap on the turbine loss[J].Journal of Aerospace Power,2010,25(7):1595-1601.(in Chinese)
[9]	周莉,蔡元虎.不同轴向间距下涡轮级内非定常流场的数值研究[J].航空动力学报,2010,2(3):629-631. ZHOU Li,CAI Yuanhu.Numerical investigation on the unsteady flowfield of the turbine stage under different axial gaps[J].Journal of Aerospace Power,2010,25(3):629-631.(in Chinese)
[10]	党政,席光,王尚锦.叶片安装角对动/静叶排内部非定常流动的影响[J].工程热物理学报,2002,23(3):319-322. DANG Zheng,XI Guang,WANG Shangjin.Influence of diffuser stagger angle on the rotor/stator unsteady interaction flow[J].Journal of Engineering Thermophysics,2002,23(3):319-322.(in Chinese)
[11]	李宇,邹正平,刘火星,等.叶片安装角偏差对涡轮通道内热斑迁移的影响[J].工程热物理学报,2009,30(6):944-948. LI Yu,ZOU Zhengping,LIU Huoxing,et al.Influence of blade-stagger departure on the migration of hot streak in turbine passage[J].Journal of Engineering Thermophysics,2009,30(6):944-948.(in Chinese)
[12]	Barmpalias K G,Kalfas A I,Chokani N,et al.The dynamics of the vorticity field in a low solidity axial turbine .ASME Paper GT2008-51142,2008.
[13]	Lazaro B J,Gonzalez E,Vazquez R.Unsteady loss production mechanisms in low Reynolds number,high lift,low pressure turbine profiles .ASME Paper GT2007-28142,2007.
[14]	Wolf T,Kost F,Janke E,et al.Experimental and numerical studies on highly loaded supersonic axial turbine cascades .ASME Paper GT2010-23808,2010.
[15]	Schmitz J T,Morris S C,Ma R,et al.Highly loaded low-pressure turbine:sign,numerical,and experimental analysis .ASME Paper GT2010-23591,2010.
