离心压气机管式扩压器设计与计算分析

王博; 严明

离心压气机管式扩压器设计与计算分析

王博,
严明

北京航空航天大学能源与动力学院航空发动机气动热力国家级重点试验室,北京 100191

计量
- 文章访问数: 1960
- HTML浏览量: 139
- PDF量: 602
- 被引次数: 0
出版历程
- 收稿日期: 2011-07-08
- 刊出日期: 2012-06-28

Design and numerical simulation of pipe diffuser in centrifugal compressor

WANG BO,
YAN Ming

National Key Laboratory of Science and Technology on Aero-Engines Aero-thermodynamics, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 采用程序化建模方法,对离心压气机管式扩压器的三维几何造型进行参数化设计,并采用定常数值模拟的方法分析管式扩压器内流场特性,攻角特性,对影响管式扩压器性能的几何参数进行分析与优化,同时对照某原型叶片式扩压器,分析传统圆形进口管式扩压器的性能优劣,提出类椭圆进口管式扩压器的概念,并揭示其能够有效提高离心压气机性能的机理.
- 离心压气机 /
- 扩压器 /
- 管式扩压器 /
- 前掠 /
- 数值模拟
Abstract: Parameterized design for three-dimensional geometry of the pipe diffuser was preformed based on programmed model-construct method.The flow field and attack angle characteristics were investigated using time-averaged numerical method,and design parameters of the pipe diffuser were analyzed and optimized subsequently.Compared with the prototype vane diffuser,the performance of a pipe diffuser with traditional circle inlet was evaluated.Further study initiated a pipe diffuser with ellipse-like inlet which would expand the working range of centrifugal compressor,and suggested the mechanism of the improvement.
- centrifugal compressor /
- diffuser /
- pipe diffuser /
- forward-swept /
- numerical simulation

HTML

参考文献(15)

[1]	华耀南,饶江,张国庆,等. 跨音速离心压气机的现状和发展[J]. 航空动力学报,1994,9(3),225-232. HUA Yaonan, RAO Jiang, ZHANG Guoqing, et al. The present condition and development of transonic centrifugal compressor [J].Journal of Aerospace Power,1994,9(3), 225-232.(in Chinese)
[2]	Ziegler K Z, Gallus H E, Niehuis R. A study on impeller-diffuser interaction Part1:influence on the performance . ASME 2002-GT-30381,2002.
[3]	Shum Y K P,Tan C S,Cumpsty N A.Impeller-diffuser interaction in centrifugal stages . ASME 2000-GT-426,2000.
[4]	Filipenco V,Denizs,Johnston J,et al.Effects of inlet flow field conditions on the performance of centrifugal compres-sor diffusers Part Ⅰ:discrete passage diffuser .ASME 98-GT-473,1998.
[5]	Deniz S,Greitzer E,Cumpsty N.Effecs of inlet flow field conditions on the performance of centrifugal compressor diffusers Part 2:straight-channel diffuser .ASME 98-GT-474,1998.
[6]	Japikse D.Centrifugal compressor design and performance[M].Wilder VT:Concepts ETI, Inc.,1996.
[7]	Kenny D P.A comparison of the predicted and measured performance of high pressure ratio centrifugal compressor diffusers .ASME Paper 72-GT-54,1972.
[8]	刁正纲,陈静宜.高压比离心压气机发展的一些问题[J]力学进展,1979,9(1):25-34. DIAO Zhenggang,CHEN Jingyi.Some problems of high pressure ratio centrifugal compressors[J].Advances in Mechanics,1979,9(1):25-34.(in Chinese)
[9]	Krain H.Review of centrifugal compressor’s application and development .ASME 2003-GT-38971,2003.
[10]	Vrana J C.Diffuser for centrifugal compressors:US,3333762 .1967-08-01.
[11]	Blair L W,Dr Russo C J.Compact diffusers for centrifugal compressors .Lynn,Massachusetts:American Institute of Aeronautics and Astronautics,1980.
[12]	Rodgers C.The performance of centrifugal compressor channel diffusers .ASME Paper 82-GT-1,1982.
[13]	Rodgers C.Static pressure recovery characteristics of some radial vaneless diffusers .Toronto,Canada:Canadian Aeronautics and Space Institute International Sympesium on Centrifugal Compressor Design,1982.
[14]	石建成,刘宝杰.混合型扩压器流动特点分析[J].推进技术,2008,29(5):583-590. SHI Jiancheng,LIU Baojie.Numerical investigation for a mixed type diffuser[J].Journal of PropulsionTechnology,2008,29(5):583-590.(in Chinese)
[15]	王毅,赵胜丰,卢新根,等.高负荷离心压气机管式扩压器特点及机理分析[J].航空动力学报,2011,26(3):649-655. WANG Yi,ZHAO Shengfeng,LU Xingen,et al.Characteristics and mechanism analysis of high-load centrifugal compressor pipe diffuser[J].Journal of Aerospace Power,2011,26(3):649-655.(in Chinese)
