熵层对高超声速二维钝楔气动参数的影响

程兴华; 杨涛; 常中东

熵层对高超声速二维钝楔气动参数的影响

国防科技大学航天与材料工程学院,长沙 410073

计量
- 文章访问数: 1716
- HTML浏览量: 119
- PDF量: 661
- 被引次数: 0
出版历程
- 收稿日期: 2011-11-09
- 刊出日期: 2012-06-28

Influence of entropy layer on aerodynamics parameters for hypersonic 2-D blunt wedge

College of Aerospace and Material Engineering, National University of Defense Technology,Changsha 410073,China

摘要

摘要: 采用薄激波层理论和流管质量守恒相结合的方法,分析了高超声速二维钝楔边界层外缘熵的分布规律,研究了熵层对边界层外缘密度、马赫数以及壁面气动加热等气动参数的影响.结果表明:边界层外缘熵在倒圆-肩部区下降最为剧烈,熵层对气动参数的影响在高超声速下不可忽略,特别是使转捩区和湍流区的气动加热增加约53.6%.因此,将表面流态控制在层流模式对高超声速飞行器热防护具有重要意义.
- 熵层 /
- 钝楔 /
- 薄激波层 /
- 气动加热 /
- 气动参数 /
- 高超声速
Abstract: Using thin shock layer theory and mass conservation of stream tube,the entropy distribution of boundary layer exterior margin was analyzed for hypersonic two-dimensional(2-D) blunt wedge,and the influence of entropy layer on aerodynamics parameters such as density,Mach number,and aeroheating,et al.,was investigated.The results show that the entropy of boundary layer exterior margin dropped more quickly in rounding-shoulder region,and the influence of entropy layer on aerodynamics parameters should not be neglectable,which especially augmented the aeroheating 53.6% in transition and turbulent region.So,controling the flow of wall to stay in laminar model is very important for thermal protection of hypersonic vehicle.
- entropy layer /
- blunt wedge /
- thin shock layer /
- aeroheating /
- aerodynamics parameters /
- hypersonic

HTML

参考文献(13)

[1]	黄志澄.高超声速飞行器空气动力学[M].北京:国防工业出版社,1995.
[2]	瞿章华,刘伟,曾明,等.高超声速空气动力学[M].长沙:国防科技大学出版社,2001.
[3]	Zoby E V,Moss J N,Sutton K.Approximate convective-heating equations for hypersonic flow[J].Journal of Spacecraft and Rockets,1981,18(1):64-70.
[4]	蒋友娣,董葳,陈勇.高超声速钝头体变熵流表面热流计算[J].航空动力学报,2008,23(9):1591-1594. JIANG Youdi,DONG Wei,CHEN Yong.Surface heat flux calculation of variable entropy flow for hypersonic blunt bodies[J].Journal of Aerospace Power,2008,23(9):1591-1594.(in Chinese)
[5]	蒋友娣.高超声速飞行器气动热和表面瞬态温度计算研究 .上海:上海交通大学,2008. JIANG Youdi.Calculation of aerodynamic heating and transient surface temperature for hypersonic aircraft .Shanghai:Shanghai Jiao Tong University,2008.(in Chinese)
[6]	雷延花,徐敏,陈士橹.高超音速飞行器气动加热计算[J].上海航天,2001(5):10-13. LEI Yanhua,XU Min,CHEN Shilu.The aerothermal calculation of hypersonic vehicle[J].Aerospace Shanghai,2001(5):10-13.(in Chinese)
[7]	中国人民解放军总装备部军事训练教材编辑工作委员会.高超声速气动热和热防护[M].北京:国防工业出版社,2003.
[8]	Klamon J H.Bow shock correlation for slightly blunted cones[J].AIAA Journal,1963,1(2):490-491.
[9]	Van Dyke M D,Gordon H D.Supersonic flow past a family of blunt axisymmetric bodies .NASA TR R-1,1959.
[10]	卞荫贵,赵国英.可压缩流边界层参数的工程计算方法[J].力学学报,1980,16(2):120-128. PIEN Yenkui,CHAO Guoying.An engineering method for calculation of the parameters in compressible boundary layers[J].Chinese Journal of Theoretical and Applied Mechanics,1980,16(2):120-128.(in Chinese)
[11]	Quinn R D,Gong L.A method for calculating transient surface temperatures and surface heating rates for high-Speed aircraft .NASA/TP-2000-209034,2000.
[12]	姜贵庆,刘连元.高速气流传热与烧蚀热防护[M].北京:国防工业出版社,2003.
[13]	吕丽丽,张伟伟,叶正寅.高超声速再入体表面热流计算[J].应用力学学报,2006,23(2):259-263. LV Lili,ZHANG Weiwei,YE Zhengyin.The calculation of surface heating rates for hypersonic reentry-body[J].Chinese Journal of Applied Mechanics,2006,23(2):259-263.(in Chinese)
