基于圆弧刀廓的端面滚切锥齿轮啮合接触分析
Tooth meshing contact analysis for bevel gears by face hobbing method based on arc blade profile
-
摘要: 为改善端面滚切法加工的锥齿轮齿面接触质量,基于奥利康锥齿轮全展成加工方法,对直线刀廓圆弧修形及齿面啮合接触分析进行了研究.首先对圆弧刀廓进行了几何设计,推导出了刀齿切削刃方程.在建立锥齿轮端面滚切加工数学模型的基础上,推导出了被加工齿轮理论齿面方程.研究了刀廓圆弧修形对齿面形状的影响,利用数值方法计算出了齿面修形量.建立了考虑安装误差的齿轮副滚检数学模型,推导出了齿面接触分析简化算法.最后对采用圆弧刀廓加工的一对奥利康锥齿轮进行了啮合分析,结果表明,选取合理的圆弧刀廓半径对齿面修形可以降低边缘接触风险,降低对安装误差的敏感性,改善内对角接触,此外还可以实现对两齿面接触区进行独立修正.Abstract: In order to improve tooth contact quality of bevel gears by face hobbing method,the straight-line blade profile modified with arc profile and tooth meshing analysis was studied based on generating method of Oerlikon bevel gears.Firstly,the arc blade profile geometry was designed,and the arc blade edge equation was derived.On the basis of mathematical model of bevel gears by face hobbing method,the theoretical tooth surface equation of processed gear was derived.The effect of blade profile modified with arc shape on tooth surface was studied,and the modified quantity of tooth flank was calculated by the use of numerical method.The mathematical model of gears testing with alignment errors was established,and the simplified algorithm of tooth contact analysis was derived.Finally,making tooth contact analysis for Oerlikon bevel gears processed with arc blade profile,the results demonstrate that modifying tooth surface with arc blade profile by selecting appropriate radius not only can reduce risk to edge contact,lower sensitive to alignment errors,and improve bias-in contact quality,but also can revise contact areas for two tooth surfaces,respectively.
-
[1] 吴乃云.延伸外摆线等高齿的设计及应用[J].汽车工艺与材料,2008(2):49-51. WU Naiyun.Design and application of extended epicycloid equal height spiral bevel gear[J].Automobile Technology and Material,2008(2):49-51.(in Chinese) [2] Fong Z H.Mathematical model of universal hypoid generator with supplemental kinematic flank correction motions[J].Journal of Mechanical Design,Transactions of the ASME,2000,122(1):136-142. [3] 吴联银,魏洪钦,王小椿.延伸外摆线锥齿轮的成形原理及齿面结构研究[J].西安交通大学学报,2001,35(1):43-46. WU Lianyin,WEI Hongqin,WANG Xiaochun.Analysis of the forming principle and the differential structure of extended epicycloids bevel gear tooth surface[J].Journal of Xi'an Jiaotong University,2001,35(1):43-46.(in Chinese) [4] 李海涛,魏文军.摆线齿锥齿轮齿面接触区的计算机辅助分析[J].中国农业大学学报,2004,9(5):45-50. LI Haitao,WEI Wenjun.Computer aided analysis for contact pattern of prolate epicycloids bevel and hypoid gears[J].Journal of China Agricultural University,2004,9(5):45-50.(in Chinese) [5] Fan Q.Computerized modeling and simulation of spiral bevel and hypoid gears manufactured by gleason face hobbing process[J].Journal of Mechanical Design,Transactions of the ASME,2006,128(6):1315-1327. [6] Fan Q.Kinematical simulation of face hobbing indexing and tooth surface generation of spiral bevel and hypoid gears[J].Gear Technology,2006,23(1):30-38. [7] Shih Y P,Fong Z H,Lin G C Y.Mathematical model for a universal face hobbing hypoid gear generator[J].Journal of Mechanical Design,Transactions of the ASME,2007,129(1):38-47. [8] Fan Q.Enhanced algorithms of contact simulation for hypoid gear drives produced by face-milling and face-hobbing processes[J].Journal of Mechanical Design,Transactions of the ASME,2007,129(1):31-37. [9] Shih Y P,Fong Z H.Flank modification methodology for face-hobbing hypoid gears based on ease-off topography[J].Journal of Mechanical Design,Transactions of the ASME,2007,129(12):1294-1302. [10] Vimercati M.Mathematical model for tooth surfaces representation of face-hobbed hypoid gears and its application to contact analysis and stress calculation[J].Mechanism and Machine Theory,2007,42(6):668-690. [11] Shih Y P,Fong Z H.Flank correction for spiral bevel and hypoid gears on a six-axis CNC hypoid generator[J].Journal of Mechanical Design,Transactions of the ASME,2008,130(6):0626041-06260411. [12] Nishino T.Computerized modeling and loaded tooth contact analysis of hypoid gears manufactured by face hobbing Process[J].Journal of Advanced Mechanical Design,Systems,and Manufacturing,2009,3(3):224-235 . [13] 聂少武,邓效忠,李天兴.奥利康准双曲面齿轮的理论齿面推导及仿真[J].机械传动,2009,33(2):20-22. NIE Shaowu,DENG Xiaozhong,LI Tianxing.Theoretical tooth surface deduction and simulation of Oerlikon hypoid gears[J].Journal of Mechanical Transmission,2009,33(2):20-22.(in Chinese) [14] Kolivand M,Kahraman A.A load distribution model for hypoid gears using ease-off topography and shell theory[J].Mechanism and Machine Theory,2009,44(10):1848-1865. [15] Shih Y P.A novel ease-off flank modification methodology for spiral bevel and hypoid gears[J].Mechanism and Machine Theory,2010,45(8):1108-1124. [16] Fan Q.Tooth surface error correction for face-hobbed hypoid gears[J].Journal of Mechanical Design,Transactions of the ASME,2010,132(1):0110041-0110048. [17] 董学朱.摆线齿锥齿轮及准双曲面齿轮设计与制造[M].北京:机械工业出版社,2002. [18] Litvin F L.Gear geometry and applied theory[M].Englewood Cliffs,N J:Prentice Hall,1994.
