非线性谐波法在对转压气机中的校检分析

王雷; 刘波

非线性谐波法在对转压气机中的校检分析

王雷,
刘波

西北工业大学动力与能源学院,西安 710072

基金项目: 国家自然科学基金(50976093)

计量
- 文章访问数: 2283
- HTML浏览量: 125
- PDF量: 687
- 被引次数: 0
出版历程
- 收稿日期: 2011-09-02
- 刊出日期: 2012-07-28

Validation of nonlinear harmonic method in dual-stage counter-rotating compressor

WANG Lei,
LIU Bo

School of Power and Energy, Northwestern Polytechnical University,Xi'an 710072,China

摘要

摘要: 以双级对转压气机为研究对象,对新型非定常模拟方法——非线性谐波(NLH)法进行了不同阶数下的校检,并与常规非定常模拟方法在宏观性能指标和微观流场结构上进行对比,分析了对转压气机转子独特的动-动干涉现象.研究结果表明:非线性谐波方法可在时均框架内有效计及非定常现象,对于该对转压气机,3阶谐波已能在计算成本和计算精度间获得最佳折衷,具备良好的工程应用前景.
- 非线性谐波法 /
- 非定常模拟 /
- 对转 /
- 动-动干涉 /
- 校检
Abstract: NLH (nonlinear harmonic) method implemented in Fine/Turbos code was evaluated for unsteady rotor-rotor interaction analysis of the NWPU (Northwestern Polytechnical University) dual-stage counter-rotating compressor.Strengths and weaknesses of the NLH method were first highlighted through direct comparison with experimental data and reference classic time-domain unsteady simulation close to the design point.Then its ability to correctly capture rotor-rotor interactions of the counter-rotating compressor was investigated in detail to enhance the understanding of the flow physics involved.The results show,on one hand,the good behavior of the NLH method and its ability to correctly predict global quantities as well as local flow pattern,on the other hand,for the present case,the NLH method is about one order magnitude faster than the classic unsteady simulation.
- nonlinear harmonic method /
- unsteady simulation /
- counter-rotating /
- rotor-rotor interaction /
- validation

HTML

参考文献(20)

[1]	Adamczyk J J.Aerodynamic analysis of multistage turbomachinery flows in support of aerodynamic design[J].Journal of Turbomachinery,2000,122(2):189-217.
[2]	Hall K C,Crawley E F.Calculation of unsteady flows in turbomachinery using the linearized Euler equations[J].AIAA Journal,1989,27(6):777-787.
[3]	Hall K C,Clark W S,Lorence C B.A linearized Euler analysis of unsteady transonic flows in turbomachinery[J].Journal of Turbomachinery,1994,116(3):477-488.
[4]	He L,Ning W.Efficient approach for analysis of unsteady viscous flows in turbomachines[J].AIAA Journal,1998,36(11):2005-2012.
[5]	Chen T,Vasanthakumar P,He L. Analysis of unsteady blade row interaction using nonlinear harmonic approach [J].Journal of Propulsion and Power,2001,17(3):651-658.
[6]	He L.Fourier methods for turbomachinery applications[J].Progress in Aerospace Sciences,2010,46(8):329-341.
[7]	Sicot F,Puigt G,Montagnac M.Block-jacobi implicit algorithms for the time spectral method[J].AIAA Journal,2008,46(12):3080-3089.
[8]	Ekici K,Hall K C.Nonlinear analysis of unsteady flows in multistage turbomachines using harmonic balance[J].AIAA Journal,2007,45(5):1047-1057.
[9]	Ekici K,Hall K C.Harmonic balance analysis of blade row interactions in a transonic compressor[J].Journal of Propulsion and Power,2010,26(2):335-343.
[10]	Sicot F,Dufour G,Gourdain N.A time-domain harmonic balance method for rotor stator interactions[J].Journal of Turbomachinery,2012,134(1):011001(13 pages).
[11]	Hembera M,Loos A,Kührmann A,et al.Validation of the non-linear harmonic approach for quasi-unsteady simulations in turbomachinery .ASME Paper GT-2009-59933,2009.
[12]	Guidotti E,Turner M G.Analysis of the unsteady flow in an aspirated counter-rotating compressor using the nonlinear harmonic method .ASME Paper GT-2009-60285,2009.
[13]	Vilmin S,Hirsh C,Lorrain E,et al.Unsteady flow modeling across the rotor/stator interface using the nonlinear harmonic method .ASME Paper GT-2006-90210, 2006.
[14]	He L.Harmonic solution of unsteady flow around blades with separation[J].AIAA Journal,2008,46(6):1299-1307.
[15]	陈云永.对转压气机特性、流场分析及三维优化研究 .西安:西北工业大学,2008. CHEN Yunyong.Flow field and performance investigation and three-dimension optimization study of contra-rotating compressor .Xi’an:Northwestern Polytechnical University,2008.(in Chinese)
[16]	王雷,刘波,王庆伟,等.基于多级环境下的双排对转压气机优化设计.航空动力学报,2010,6(3):516-521. WANG Lei,LIU Bo,WANG Qingwei,et al.Optimization in multistage environment of dual stage counter-rotating compressor[J].Journal of Aerospace Power,2010,25(6):1382-1388.(in Chinese)
[17]	Gerolymos G A,Michon G J.Analysis and application of chorochronic periodicity in turbomachinery rotor/stator interaction computations[J].Journal of Propulsion and Power,2002,18(6):1139-1152.
[18]	Frobel T,Kau H P.Numerical investigation of unsteady flow phenomena in an HP axial compressor incorporating stator shroud cavities .AIAA 2010-6532,2010.
[19]	Smith L H.Wake dispersion in turbomachines[J].Journal of Basic Engineering,1966,88(3):688-690.
[20]	Valkov T,Tan C S.Control of unsteady flow in a stator blade row interacting with upstream moving wakes[J].Journal of Turbomachinery,1995,117(1):97-105.
