跨声速压气机转子失速过程的实验
Experimental investigation on the stall process of a transonic compressor rotor
-
摘要: 针对一台跨声速压气机转子在不同转速下的失速过程进行了稳态和动态实验研究.通过对原始信号、小波分析结果以及FFT(fast Fourier transform)变换结果的分析得到,该压气机转子在3个不同转速时均为突跃型全叶高失速,流场中存在一个失速团,失速团沿周向的传播方向与转子转动方向相同,其相对静止坐标系的量纲一转速随转子转速的增大而减小,对这一规律产生的原因进行了分析.Abstract: An experiment with static and dynamic acquisition were carried out on a transonic compressor rotor at three rotating speed.The analysis was performed on the original signal,the FFT(fast Fourier transform)and the wavelet method.The results show that the stall inception is spike type of whole span.Only one stall cell exists in the flow field,the spreading direction of which is the same as the rotor rotating.And the relative rotating speed of the stall cell decreases when the rotor speed increases.
-
Key words:
- stall /
- compressor/fan /
- transonic /
- wavelet analysis /
- stall cell speed
-
[1] Emmons H W,Pearson C E,Grant H P.Compressor surge and stall propagation[J].Transactions of the ASME,1955,77(3):455-469. [2] Moore F K,Greitzer E M.A theory of post-stall transients in axial compressor systems Part Ⅰ:development of equations .ASME Paper 85-GT-171,1985. [3] Camp T R,Day I J.A study of spike and modal stall phenomena in a low-speed axial compressor[J].ASME J.Turbomach,1998,120(3):393-401. [4] Freeman C,Wilson A G,Day I J,et al.Experiments in active control of stall on an aeroengine gas turbine[J].ASME J Turbomach,1998,120(4):637-647. [5] Day I J,Breuer T,Escuret J,et al.Stall inception and the prospects for active control in four high-speed compressors[J].ASME J.Turbomach,1999,12(1):18-27. [6] Vahdati M,Simpson G,Imregun M.Un-steady flow and aeroelasticity behavior of aeroengine core compressors during rotating stall and surge[J].ASME J.Turbomach,2008,130(3):031017.1-031017.9. [7] Cumpsty N A.Compressor aerodynamics[M].US:Krieger Publishing Company,2004. [8] Epstein A H,Ffowcs W J E,Greitzer E M.Active suppression of compressor instabilities .AIAA Paper AIAA-86-1994,1986. [9] 曹人靖,周盛.扰动波对轴流压气机旋转失速的影响[J].航空动力学报,1997,12(2):201-203. CAO Renjing,ZHOU Sheng.Effects of disturbance waves on rotating stall stability of axial compressor[J].Journal of Aerospace Power,1997,12(2):201-203.(in Chinese) [10] 张燕东,王光华,陆亚钧.用小波变换对机匣处理抑制旋转失速的机理研究[J].航空动力学报,1998,13(2):133-139. ZHANG Yandong,WANG Guanghua,LU Yajun.Mechanism investigation on casing treatment for restraining rotating stall by means of wavelet transform[J].Journal of Aerospace Power,1998,13(2):133-139.(in Chinese) [11] Haynes J M,Hendricks G J,Epstein A H.Active stabilization of rotating stall in a three-stage axial compressor[J].Journal of Turbomachinery,1994,116(2):226-239. [12] McDougall N M.Stall inception in axial compressor .Cambridge,UK:Cambridge University,1988. [13] Day I J.Stall inception in axial flow compressor[J].ASME Journal of Turbomachinery.1993,113(1):1-9. [14] Day I J.Active suppression of ratating stall and surge in axial compressors[J].ASME Journal of Turbomachinery.1993,115(1):40-47. [15] Camp T R,Day I J.A study of spike and modal stall phenomena in a low-speed axial compressor[J].ASME Journal of Turbomachinery,1998,120(3):393-401.
