畸变进气下压气机三维黏性数值计算模型

时培杰; 乔渭阳; 魏佐君; 陈萍萍

畸变进气下压气机三维黏性数值计算模型

西北工业大学动力与能源学院,西安 710072

计量
- 文章访问数: 2043
- HTML浏览量: 189
- PDF量: 673
- 被引次数: 0
出版历程
- 收稿日期: 2011-08-30
- 刊出日期: 2012-07-28

Investigation of three-dimensional viscous model for compressor with distortion inlet

School of Power and Energy, Northwestern Polytechnical University,Xi'an 710072,China

摘要

摘要: 通过对压气机环形无叶片通道求解带源项的N-S(Navier-Stokes)方程,实现对压气机全通道流场的计算,建立了压气机三维黏性非定常数值计算模型.源项是由三维计算流体动力学(CFD)求解器定常计算的气流参数计算得到,求得不同工作点源项大小,然后根据进口参数对源项插值得到当前计算点源项.采用该模型对某跨声速单级压气机在均匀进气下性能和流场的计算结果与实验结果进行了对比,两者能够较好的一致,验证了模型的可靠性;之后应用该模型对周向总压畸变进气下的流场和性能进行了计算,分析了畸变进气对压气机三维流场和性能的影响,并引入压气机失稳判据分析畸变对压气机稳定性的影响.
- 计算模型 /
- 黏性 /
- 求解器 /
- 源项 /
- 畸变进气 /
- 性能 /
- 稳定性
Abstract: A three-dimensional model for predicting compressor performance and stability was developed by solving N-S(Navier-Stokes) equation with source terms to annulus duct without blades.The source terms were calculated by flow field parameters which were generated by conventional three-dimensional computational fluid dynamics(CFD) solver at different operation conditions.A transionic single-stage compressor was investigated by the model with clean inlet.The three-dimensional flow field and performance of CFD results agreed well with those of the experiment,which indicat that the model is reliable and correct.Finally,the effect of circumferential total-pressure distortion on the compresser flow and performance was studied with the model.The compressor stability was further analyzed by introducing the stall criterion.
- calculation model /
- viscous /
- solver /
- source term /
- distortion inlet /
- performance /
- stability

HTML

参考文献(12)

[1]	刘大响,叶培梁,胡骏,等.航空燃气涡轮发动机稳定性设计与技术评定[M].北京:航空工业出版社,2004.
[2]	Pearson H,McKenzie A B.Wakes in axial compressors[J].Journal of the Royal Aeronautical Society,1959,63(583):415-416.
[3]	Reid C.The response of axial compressors to intake flow distortion .ASME Paper 69-GT-29,1969.
[4]	乔渭阳,蔡元虎,陈玉春.进气畸变对压缩系统稳定性影响的数值模拟[J].推进技术,2001,22(4):307-310. QIAO Weiyang,CAI Yuanhu,CHEN Yuchun.Effect of pressure and temperature distortion orientation on turbine engine stability[J].Journal of Propulsion Technology,2001,22(4):307-310.(in Chinese)
[5]	Hale A,Brien W O.A three-dimensional turbine engine analysis compressor code (TEACC) for steady-state inlet distortion[J].Journal of Turbomachinery,1998,120(2):422-430.
[6]	Chima R V.A three-dimensional unsteady CFD model of compressor stability .ASME GT2006-90040,2006.
[7]	许开富,乔渭阳,罗华玲,等.风扇/压气机稳定性三维模型的研究[J].推进技术,2008,29(3):344-348. XU Kaifu,QIAO Weiyang,LUO Hualing,et al.A 3-D CFD analysis code of fan and compressor stability[J].Journal of Propulsion Technology,2008,29(3):344-348.(in Chinese)
[8]	Lieblein S,Schwenk F C,Broderick R L.Diffusion factor for estimating losses and limiting blade loading in axial flow compressor blade elements .NACA RME53D01, 1953.
[9]	Cumpsty N A.Compressor aerodynamics[M].New York:Longman Scientific & Technical,1989.
[10]	Van Z,Dale E,Strazisar A J,et al.Recommendations for achieving accurate numerical simulations of tip clearance flows in transonic compressor rotors[J].Journal of Turbomachinery,2000,122(4):733-742.
[11]	Reid L,Moore R D.Performance of a single stage axial-flow compressor with rotor and stator aspect ratio of 1.19 and 1.26,respectively,and with design pressure ratio of 1.82 .NASA Technical Paper-1338,1978.
[12]	Marble F E.Three-dimensional flow in tubomachines,aerodynamic of turbine and compressor[M].Princeton:Princeton University Press,1964.
