小型向心透平一维和三维设计分析

奚忠; 付经伦; 刘建军; 张晓东

小型向心透平一维和三维设计分析

1.
中国科学院研究生院,北京 100190
2.
中国科学院工程热物理研究所,北京 100190

基金项目: 青年科学基金(50906082)

计量
- 文章访问数: 1659
- HTML浏览量: 0
- PDF量: 782
- 被引次数: 0
出版历程
- 收稿日期: 2011-09-05
- 刊出日期: 2012-07-28

One and three-dimensional designs and analyses of small radial turbines

1.
Graduate University of Chinese Academy of Sciences,Beijing 100190,China
2.
Institute of Engineering Thermophysics, Chinese Academy of Science,Beijing 100190,China

摘要

摘要: 在分析各种因素对向心透平速比和反动度限制的基础上,给出了一种比较合理的速比和反动度的选择方法,并用C语言编写了小型燃气透平一维热力计算程序OCC(one-dimensional computer code),来进行向心透平的热力计算.通过与已发表文献中的一维热力计算程序OFC(one-dimensional computer FORTRAN code)结果进行比较,发现两者结果基本一致,且OCC设计总对静效率要高于OFC的设计效率.为了对一维程序计算结果与三维CFD(computational fluid dynamics)数值模拟进行比较,选取已发表文献中600kW燃气轮机作为分析实例,用编写的一维热力设计程序对600kW燃气轮机向心透平导叶和动叶进行了设计.一维程序计算结果与三维CFD数值模拟结果比较发现,两者的偏差小于10%.综上所述,使用的设计方法以及一维热力设计程序对于小型向心透平的初步设计是适用的.
- 向心透平 /
- 数值模拟 /
- 热力计算 /
- 初步设计 /
- 速比
Abstract: A reasonable method of choosing speed ratio and degree of reaction for small radial turbines was described,and a one-dimensional design code OCC(one-dimensional computer code)was programmed by analyzing all kinds of restriction factors on the speed ratio and degree of reaction.The code OCC was used for the design of nozzle and rotor blade of a 600kW simple cycle gas turbine taken from the literature.The OCC results were compared with the results of the design and analysis code OFC(one-dimensional computer FORTRAN code)in the literature.The results were in agreement,and the total static isentropic efficiency of the radial turbine designed by OCC was larger than that designed by OFC.The comparison between the CFD(computational fluid dynamics) simulation resulted that and the OCC results for the radial turbine shows the discrepancies were lower than 10%.In conclusion,the present design method and the one-dimensional design program are appropriate to the preliminary design of micro radial turbines.
- radial turbine /
- numerical simulation /
- thermodynamic calculation /
- preliminary design /
- speed ratio
