一种离心甩油盘雾化性能的试验
Experimental study of atomization performance on a fuel slinger
-
摘要: 在离心甩油盘性能试验器上对一种离心甩油盘雾化性能进行了较详细的试验研究,用相位多普勒粒子分析仪(PDPA)测量了不同转速下甩油盘的燃油雾化粒度索太尔平均直径(SMD)、雾化锥角等性能参数.试验结果表明:在试验转速范围内,随甩油盘转速增大,甩油盘雾化锥角α逐渐减少; 随甩油盘转速增大,雾化粒度SMD值逐渐减少,当甩油盘转速大于25000r/min时,燃油的SMD值基本保持不变; 在同一甩油盘转速下,燃油的SMD值随离甩油盘喷油孔距离的增大而增大.
-
关键词:
- 折流燃烧室 /
- 离心甩油盘 /
- 相位多普勒粒子分析仪(PDPA) /
- 雾化粒度 /
- 雾化锥角
Abstract: An experimental study was performed to investigate the atomization performance on a rotating fuel injection system in a fuel slinger test rig.Performance parameters such as fuel droplet size Sauter mean diameter (SMD) and spray cone angle etc was measured by using phase Doppler particle analyzer (PDPA) system under different slinger rotary speeds.The test results indicate that during the given rotational speed ranges,the fuel atomization cone angle of the slinger is gradually decreased with increasing shaft speed,the fuel droplet size of the slinger is gradually decreased while the rotational speed increased.Over than 25000r/min,SMD is not changed and kept constant,under the same rotary speed,the droplet size increased when the distance away from the fuel slinger hole increased. -
[1] Lefebvre A H.Gas turbine combustion[M].New York:Hemisphere Publishing Corporation,1983. [2] Lefebvre A H.Atomization and sprays[M].New York:Hemisphere Publishing Corporation,1983. [3] Meller A M.Design of modern turbine combustor[M].New York:Academic Press Inc.,1990. [4] 航空发动机设计手册总编委会.航空发动机设计手册(第9册)[M].北京:航空工业出版社,2000. [5] 宋双文,罗辉.离心甩油盘特性浅析 //中国航空学会第三界小发动机学术讨论会.北京:中国航空学会,2000:125-133. [6] 宋双文.折流环形燃烧室结构特点分析 //湖南省航空学会2001年学术年会.长沙:湖南省航空学会,2001:24-32. [7] 甘晓华.航空燃气轮机燃油喷嘴技术[M].北京:国防工业出版社,2006. [8] Maskey H C ,Marsh F X.The annular combustion chamber with centrifugal fuel injection .SAE-444C,1962. [9] Rogo C,Trauth R L.Design of high heat release slinger combustor with rapid acceleration requirement .SAE-740167,1974. [10] Morishita T.A development of the fuel atomizing device utilizing high rotational speed .ASME GT 81-180,1981. [11] 贾永忠.甩油盘的雾化分析[J].推进技术,1995,16(4):45-49. JIA Yongzhong.An analysis on atomization of fuel slinger[J].Journal of Propulsion Technology,1995,16(4):45-49.(in Chinese) [12] DahmW J A,Patel P R,Lerg B H.Visualization and fundamental analysis of liquid atomization by fuel slingers in small gas turbine engines .AIAA-2002-3183,2002. [13] Lee K Y,Choi S M,Han Y M,et al.Ignition characteristics on the annular combustor with rotating fuel injection system .ASME-GT2004-53233,2004. [14] Choi S M,Lee D H,Park J.Ignition and combustion characteristics of the gas turbine slinger combustor[J].Journal of Mechanical Science and Technology,2008,22(3):538-544. [15] Brackett C L,Trauth R L.Small turbine engine experience with high density fuels .AIAA 83-1177,1983.
