中心锥对波瓣强迫混合排气系统气动热力性能的影响

谢翌; 刘友宏

中心锥对波瓣强迫混合排气系统气动热力性能的影响

谢翌,
刘友宏

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

计量
- 文章访问数: 1806
- HTML浏览量: 156
- PDF量: 769
- 被引次数: 0
出版历程
- 收稿日期: 2011-08-09
- 刊出日期: 2012-07-28

Effect of central plug on performance of forced mixing exhaust system

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 在波瓣混合器几何结构不变的情况下,通过分别改变波瓣出口截面处中心锥半径以及波瓣长度建立了一系列几何模型,并采用数值模拟的方法,研究了中心锥关键结构参数对涡扇发动机波瓣混合排气系统气动热力性能的影响规律.结果表明:当中心锥长度不变时,随着波瓣出口处中心锥半径的增加,热混合效率先增加后减小,其中当波瓣出口处中心锥半径为0.55倍波瓣高度时,波瓣混合排气系统出口处热混合效率最大.此外,当中心锥长度不变时,波瓣混合排气系统总压恢复系数大体上不断减小;排气系统出口处推力系数则呈现出先增大后迅速减小.当波瓣出口处中心锥半径不变时,随着中心锥长度的增加,热混合效率和总压恢复系数变化极小,在排气系统出口处,推力系数则先迅速增大后略有降低.
- 波瓣混合排气系统 /
- 波瓣出口处中心锥半径 /
- 中心锥长度 /
- 流向涡 /
- 热混合效率 /
- 总压恢复系数 /
- 推力系数
Abstract: Geometric models with respective changes of plug radius at lobe exit and plug length in the lobed forced mixing exhaust system were established.Then these models were numerically simulated based on Navier-Stokes equations.The results show that when plug length is constant,the thermal mixing efficiency increases at first and then declines with plug radius at the lobe exit augmenting,and when ratio of plug radius at lobe exit to lobe height is equal to 0.55,the lobed mixing exhaust system has the biggest thermal mixing efficiency at the nozzle exit among the models researched.Generally speaking,the total pressure recovery coefficient declines as radius increases.Moreover,the thrust coefficient at the nozzle exit firstly increases and then decreases sharply.When plug radius at lobe exit keeps constant,with plug length rising,the thermal mixing efficiency and total pressure recovery coefficient vary little and the thrust coefficient at the nozzle exit augments quickly in the beginning and then declines slowly.
- lobed forced mixing exhaust system /
- plug radius at lobe exit /
- plug length /
- streamwise vortices /
- thermal mixing efficiency /
- total-pressure recovery coefficient /
- thrust coefficient

HTML

参考文献(13)

[1]	Skebe S A,Paterson R W,Baber T J.Experimental investigation of three dimensional forced mixer lobe flow field .AIAA Paper 88-3785,1988.
[2]	Paterson R W.Turbofan mixer nozzle flow field: a benchmark experimental study[J].Journal of Engineering for Gas Turbines and Power,1984,106(3):692-698.
[3]	Elliott J K,Manning Y J,Qiu Y J,et al.Computational and experimental studies of flow in multi-lobed forced mixers .AIAA Paper 1992-3568,1992.
[4]	Ooba Y,Kodama H,Nakamura Y,et al.Large eddy simulation analysis of a 18-lobe convoluted mixer nozzle .AIAA Paper 2002-0717,2002.
[5]	Hu H,Saga T,Kobayashi T.Investigation of the vortex structures downstream of a lobed nozzle by mean of dual-plane stereoscopic PIV .Gottingen, Germany:4th-International Symposium on Particle Image Velocimetry,Paper 1020,2001.
[6]	Presz W M,Reynolds G,Mccormick D C.Thrust augment using mixer-ejector-diffuser systems .AIAA Paper 94-0020,1994.
[7]	Presz W M,Mixer/ejector noise suppressors .AIAA Paper 91-2243,1991.
[8]	张靖周,李立国,高潮等.波瓣喷管红外抑制系统的实验研究[J].航空动力学报,1997,12(2):212-214. ZHANG Jingzhou,LI Liguio,GAO Chao,et al.An experimental study on a lobed nozzle of an infrared suppression system[J].Journal of Aerospace Power,1997,12(4):212-2141.(in Chinese)
[9]	刘友宏,樊超,谢翌.波瓣数对波瓣强迫混合排气系统性能影响[J].航空动力学报,2010,25(8):1683-1689. LIU Youhong,FAN Chao,XIE Yi.Effect of lobe numbers on the performance of a lobed mixer in the forced mixing exhaust system[J].Journal of Aerospace Power,2010,25(8):1683-1689.(in Chinese)
[10]	谢翌,刘友宏.瓣高宽比对波瓣强迫混合排气系统性能影响[J].航空动力学报,2010,25(12):2787-2794. XIE Yi,LIU Youhong.Effect of ratio of height to width of lobe on the performance of a lobed mixer in a forced mixing exhaust system[J].Journal of Aerospace Power,2010,25(12):2787-2794.(in Chinese)
[11]	谢翌,刘友宏.波瓣穿透率对波瓣混合排气系统性能影响[J].推进技术,2011,32(2):207-213. XIE Yi,LIU Youhong.Effects of lobe penetration ratio on performance of mixer exhaust system[J].Journal of Propulsion Technology,2011,32(2):207-213.(in Chinese)
[12]	Cooper N J,Merati P,Hu H.Numerical simulation of the vortical structures in a lobed jet mixing flow .AIAA Paper 2005-635,2005.
[13]	XIE Yi,LIU Youhong.A modified thermal mixing efficiency and its application to lobed mixer nozzle for aero-engines[J].Heat Transfer Research,2011,42(4):317-335.
