分流器对进气粒子分离器性能的影响

况开鑫; 王锁芳

分流器对进气粒子分离器性能的影响

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 1603
- HTML浏览量: 2
- PDF量: 536
- 被引次数: 0
出版历程
- 收稿日期: 2011-09-04
- 刊出日期: 2012-07-28

Effect of splitter on performance of inlet particle separator

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 为了揭示分流器位置及形状对进气粒子分离器(IPS)性能的影响,采用Realizable k-ε湍流模型对IPS进行了数值模拟,得到了分流器沿轴向移动及径向移动对IPS流场、分离效率、总压损失的影响,在此基础之上,研究了分流器唇口处与内壁面最高点轴向距离及径向距离的比值及分流器形状对IPS的影响,结果表明:比值较大时,随着轴向距离的增加,总压损失呈下降趋势,且下降梯度较大.当比值较小时,总压损失呈先减小后增加的趋势;与未改变分流器形状相比,分流器形状改变后总压损失有所降低,分离效率提高,并且分流器唇口处最高马赫数有所降低.
- 分流器 /
- 进气 /
- 粒子分离器 /
- 总压损失 /
- 分离效率
Abstract: In order to investigate how the position and the size of splitter affect the performance of integral particle separator (IPS),a numerical simulation was conducted by using the Realizable k-ε turbulence model.The simulation came out with the effects of splitter movements in axial direction and radial direction on flowfield,separation efficiency and total pressure loss in IPS.On this basis,the ratio of axial distance to radial distance at splitter lip,the highest point of inner wall surface,and the shape of the splitter's effect on IPS were studied.The results show that:When the ratio is large,with the increase of the axial distance,total pressure loss declines with a large gradient descent.When the ratio is small,total pressure loss tends to decrease at first and then increase;after the shape of the splitter changes,the total pressure loss becomes much lower while the separation efficiency getting much higher,and the highest Mach number at the splitter lip also decreases.
- splitter /
- inlet /
- particle separator /
- total pressure loss /
- separation efficiency

HTML

参考文献(12)

[1]	Hamed A.Particle dynamic of inlet flow fields with swirling vanes[J].Journal of Aircraft,1982,19(9):707-712.
[2]	Hamed A.An investigation in the variance in particle surface interactions and their effects in gas turbines[J].Journal of Engineering for Gas Turbines and Power,1992,114(2):235-241.
[3]	Hamed A,Jun Y D,Yeuan J J.Particle dynamic simulations in inlet separator with an experimentally based bounce model[J].Journal of Propulsion and Power,1995,11(2):230-235.
[4]	Vittal B V R,Tipto D L,Bennett W A.Development of an advanced vane less inlet particle separator for helicopter engines .AIAA Paper 85-1277,1985.
[5]	Al-Faris E F,Saeed F.Design and optimization method for inertial particle separator (IPS) systems .AIAA Paper 2008-6066,2008.
[6]	侯凌云,严传俊.二维粒子分离器的流场及分离效率的数值模拟[J].航空动力学报,1997,12(4):374-376. HOU Lingyun,YAN Chuanjun.Numerical simulation of two-dimensional flow field in particle separator[J].Journal of Aerospace Power,1997,12(4):374-376.(in Chinese)
[7]	侯凌云,严传俊.直升机粒子分离器三维两相流场的数值模拟[J].航空动力学报,2000,15(2):215-217. HOU Lingyun,YAN Chuanjun.Numerical simulation of 3-d two-phase flow field in inlet particle separator for helicopter[J].Journal of Aerospace Power,2000,15(2):215-217.(in Chinese)
[8]	吴恒刚,王锁芳.整体式粒子分离器数值模拟[J].航空学报,2007,28(5):1073-1079. WU Henggang,WANG Suofang.Numerical simulation of inertial particle separators[J].Acta Aeronautica et Astronautica Sinica,2007,28(5):1073-1079.(in Chinese)
[9]	吴恒刚.无叶片整体式粒子分离器性能研究 .南京:南京航空航天大学,2007. WU Henggang.Characteristic study on vaneless integral particle separator .Nanjing:Nanjing University of Aeronautics and Astronautics,2007.(in Chinese)
[10]	董晓婷,王锁芳.有叶片整体式粒子分离器三维两相流数值模拟[J].机床与液压,2008,36(10):136-139. DONG Xiaoting,WANG Suofang.Numerical simulation of three-dimensions two-phase flow in inlet particle separator with vanes[J].Machine Tool & Hydraulics,2008,36(10):136-139.(in Chinese)
[11]	叶静,胡柏安,熊焰.涡轴发动机无叶片粒子分离器流道设计[J].现代机械,2007(2):39-42. YE Jing,HU Boan,XIONG Yan.Flow path design of vanless particle separator for turbo shaft engine[J].Modern Machinery,2007(2):39-42.(in Chinese)
[12]	Duffy R J,Shttuck B F.Integral engine inlet particle separator Volume Ⅱ:design guide .AD Paper A015 064,1975.
