航空活塞发动机燃烧煤油冷起动油量控制研究
Research on cold start fuel flow control of aero-piston engine burning kerosene
-
摘要: 为了解决航空活塞发动机燃烧煤油时冷起动油量控制的问题,根据油膜理论,建立冷起动油膜补偿模型,并推导出适于在微控制器上实现的离散控制算法.利用Matlab/Simulink对基于油膜补偿器的冷 起动油量控制模型进行仿真,结果表明该模型能够保证起动瞬间有足够数量燃油进入气缸.进行原型机改烧煤油试验,在不改动发动机供油和点火系统的情况下,通过冷起动油量控制,煤油发动机冷起动性能得到改善.Abstract: In order to solve the problem of cold start fuel flow control of an aero-piston engine fueled by kerosene,a fuel film compensation model based on fuel film theory was presented,and a discrete control algorithm running on microcontroller was given.What's more,a fuel flow control model for cold start which was based on fuel film compensation was simulated on Matlab/Simulink platform.The simulation result shows this control model can ensure sufficient kerosene flowing into the cylinder.Finally,the prototype burning kerosene experiments were performed,which shows that without changing fuel feeding and ignition system,the cold start capability of kerosene engine has been improved by cold start fuel flow control.
-
Key words:
- aero-piston engine /
- kerosene /
- cold start /
- fuel film compensation /
- fuel flow
-
[1] 刘济瀛.中国喷气燃料[M].北京:中国石化出版社,1991. [2] Suhy P J,Evers L W,Morgan E J,et al.The feasibility of a kerosene fueled spark ignited two-stroke engine .SAE Paper,911846,1991. [3] Cathcart G,Dickson G,Tubb J,et al.Development of lightweight 2-stroke & 4-stroke heavy fuel UAV engines .Australia :Orbital Corporation,2006. [4] Aquino C F.Transient A/F control characteristics of the 5 liter central fuel injection engine .SAE Paper 810494, 1981. [5] Hendricks E,Sorenson S C.Mean value modeling of spark ignition engines .SAE Paper,900616,1990. [6] Luan Y F,Henein N A.A simulation model for gasoline engine cold start fuel calibration .SAE Paper,2002-01-2802,2002. [7] 陈林林,魏民祥,杨海青.航空二冲程汽油发动机均值模型的试验与仿真[J].航空动力学报,2008,23(12):2249-2255. CHEN Linlin,WEI Minxiang,YANG Haiqing.Experiment and simulation of the mean value model on two-stroke gasoline aero-engine[J].Journal of Aerospace Power,2008,23(12):2249-2255.(in Chinese) [8] 钟祥麟.基于油膜模型的多点喷射汽油机瞬态工况控制研究 .长春:吉林大学,2007. ZHONG Xianglin.Study on control of MPI gasoline engine in transient condition .Changchun:Jilin University,2007.(in Chinese) [9] Hendricks E,Vesterholm T.The analysis of mean value SI engine models .SAE Paper,920682,1992. [10] 邹博文,吴锋,桂旭阳.基于模型的燃油动态补偿器的仿真研究[J].内燃机工程,2003,24(3):41-45. ZOU Bowen,WU Feng,GUI Xuyang.Simulating research of fuel dynamic compensator [J].Chinese Internal Combustion Engine Engineering,2003,24(3):41-45.(in Chinese) [11] 朱航,王绍銧.电控汽油机进气管道油膜特性参数的标定[J].汽车工程,2004,26(2):127-130. ZHU Hang,WANG Shaoguang.Calibration for characteristic parameters of fuel film in intake duct of EFI gasoline engine[J].Automotive Engineering,2004,26(2):127-130.(in Chinese) [12] 李顶根,舒咏强.汽油机进气道油膜模型参数辨识算法的研究[J].内燃机学报,2009,27(4):363-369. LI Dinggen,SHU Yongqiang.Research of parameter identification algorithm of intake port fuel film model for gasoline engine[J].Transactions of CSICE,2009,27(4):363-369.(in Chinese)
