树脂基复合材料风扇叶片的优化设计

胡殿印; 彭苗娇; 王荣桥; 冯笑男

树脂基复合材料风扇叶片的优化设计

1.
北京航空航天大学能源与动力工程学院,北京 100191
2.
中国航空工业集团公司中航商用飞机发动机有限责任公司,上海 200240

基金项目: 凡舟基金(20110401); 教育部博士点基金(20111102120011)

计量
- 文章访问数: 1761
- HTML浏览量: 5
- PDF量: 525
- 被引次数: 0
出版历程
- 收稿日期: 2011-08-19
- 刊出日期: 2012-07-28

Optimization design of resin-based composite fan blade

1.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China
2.
Commercial Aircraft Engine Company,Limited, Aviation Industry Corporation of China,Shanghai 200240,China

摘要

摘要: 在深入研究树脂基复合材料的材料属性和设计准则的基础上,提出并建立了一种树脂基复合材料空心风扇叶片的结构设计方法,并对叶片的强度和振动特性进行了研究,结果表明所提出的树脂基复合材料空心风扇叶片的结构设计是可行的,且对于提高风扇叶片的强度和减重起到了显著的效果.在此基础上,以共振裕度为设计目标,提出了树脂基复合材料风扇叶片优化设计的流程,解决了优化过程中学科间、应用软件间的信息传递问题,并实现了叶片铺层顺序设计优化.结果表明:在满足强度约束条件的前提下,树脂基复合材料空心风扇叶片较金属实心叶片质量减少了78.88%,共振裕度增加了8.44%.
- 树脂基复合材料 /
- 风扇叶片 /
- 强度 /
- 振动 /
- 优化设计
Abstract: Based on the study of the material properties and design criteria of resin-based composite,a structural design method of the resin-based composite material hollow fan blade was proposed,and then,the strength and vibration of the fan blade were studied.The results show that the resin-based composite material fan blade has better strength property and lighter weight than the traditional metal fan blade.Then an optimization design process of the resin matrix composite fan blade was established,during which the information transmissions of disciplines and application softwares were solved.Thus,the stacking sequence optimization design of the composite fan blade was achieved.It was verified that compared to the metal fan blade,the weight of the resin-based composite material fan blade decreased by 78.88% and the vibration margin increased by 8.44%.
- resin-based composite material /
- fan blade /
- strength /
- vibration /
- optimization design

HTML

参考文献(12)

[1]	侯冠群,尚波生.宽弦风扇叶片技术的发展[J].国际航空,2002(12):45-47. HOU Guanqun,SHANG Bosheng.Development of wide chord fan blade[J].International Aviation,2002(12):45-47.(in Chinese)
[2]	梁春华,杨锐.航空发动机宽弦空心风扇叶片的发展及应用[J].航空发动机,1999(2):54-58. LIANG Chunhua,YANG Rui Development and application of hollow wide-chord fan blade of aero-engine[J].Aeroengine,1999(2):54-58.(in Chinese)
[3]	梁春华,李宏新,凌瑶.先进航空涡扇发动机风扇/压气机的先进结构与新材料[J].航空制造技术,2007(1):60-63. LIANG Chunhua,LI Hongxin,LING Yao.Advanced structures and materials for fan/compressor of advanced turbo-fan engine[J].Advanced Manufacturing Technology of Aeroengine,2007(1):60-63.(in Chinese)
[4]	陈懋章.风扇/压气机技术发展和对今后工作的建议[J].航空动力学报,2002,17(1):1-15. CHEN Maozhang.Development of fan/compressor techniques and suggestions on further researches[J].Journal of Aerospace Power,2002,17(1):1-15.(in Chinese)
[5]	宋兆泓,熊昌炳,郑光华.航空燃气涡轮发动机强度设计[M].北京:北京航空学院出版社,1988.
[6]	矫桂琼,贾普荣.复合材料力学[M].西安:西北工业大学出版社,2008.
[7]	Anthony J,Strazisar,Wood J R,et al.Laser anemometer measurements in a transonic axial-flow fan rotor .NASA Technical Paper 2879,1989.
[8]	杨建秋,王延荣.基于正交试验设计的空心叶片结构优化设计学[J].航空动力学报,2011,26(2):376-384. YANG Jianqiu,WANG Yanrong.Structural optimization of hollow fan blade based on orthogonal experimental design[J].Journal of Aerospace Power,2011,26(2):376-384.(in Chinese)
[9]	张志民.复合材料结构力学[M].北京:北京航空航天大学出版社,1993.
[10]	杨雯,杜发荣,郝勇,等.宽弦空心风扇叶片动力响应特性研究[J].航空动力学报,2007,22(3):444-449. YANG Wen,DU Farong,HAO Yong,et al.Investigation of dynamic response property of wide-chord hollow fan blade[J].Journal of Aerospace Power,2007,22(3):444-449.(in Chinese)
[11]	《航空涡喷、涡扇发动机结构设计准则》编写委员会.航空涡喷、涡扇发动机结构设计准则第1册:总论[M].北京:中国航空工业总公司发动机系统工程局,1997.
[12]	李敏强.遗传算法的基本理论与应用[M].北京:科学出版社,2002.
