航空直喷发动机缸内混合气形成的试验

胡春明; 李骥琦; 白洪林; 任立红; 董亮亮

航空直喷发动机缸内混合气形成的试验

1.
天津大学机械工程学院内燃机研究所, 天津 30007
2.
天津大学机械工程学院内燃机燃烧学国家重点试验室, 天津 300072

基金项目: 国家高技术研究发展计划(2008AA11A114); 天津大学内燃机燃烧学国家重点试验室自主课题

计量
- 文章访问数: 1785
- HTML浏览量: 68
- PDF量: 579
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-25
- 刊出日期: 2012-09-28

Experiment of in-cylinder mixture formation process low-pressure GDI engine

1.
Tianjin Internal Combustion Engine Research Institute, School of Mechanical Engineering, Tianjin University, Tianjin 30007
2.
State Key Laboratory of Engines, School of Mechanical Engineering, Tianjin University, Tianjin 300072, China

摘要

摘要: 基于航空活塞式基础样机的结构特点,自主研制了单缸低压直喷全透明光学发动机,并利用高速摄影对缸内混合气形成进行试验研究.分析了不同燃烧室形状、燃油启喷时刻以及发动机转速等条件下低压直喷发动机缸内的混合气形成规律.研究结果表明:新设计的偏心碗型活塞顶面能够有效地引导燃油喷雾形成向燃烧室顶部卷吸的运动,从而使得燃油液滴聚集在双侧火花塞附近;燃油喷射时刻对混合气形成影响很大,当进气门开度较小且活塞与上止点距离较为适中时喷射燃油,混合气形成质量最好;进气运动较强烈时,发动机转速提高会加速燃油液滴的蒸发,但同时活塞顶面对喷雾的引导作用被削弱,混合气形成质量变差;当进气运动变弱时,发动机转速提高会增强活塞顶面对油束的作用,即引导作用变强.
- 光学发动机 /
- 低压缸内直喷 /
- 燃烧室形状 /
- 高速摄影 /
- 混合气形成
Abstract: A low pressure direct injection transparent optical engine bench was developed,and the in-cylinder mixture formation process was filmed.Different mixture formation patterns were analyzed in conditions of different combustion chamber geometries,fuel injection timings and engine speeds.The research results show that:guidance of the combustion chamber with decentralized cavity piston is better than that of the proto-engine's combustion chamber;fuel injection timing plays a key role in the mixture formation,and a good mixture formation can be obtained if choosing an injection timing when intake flow is not that strong and the piston moves in the middle position of the cylinder,when the intake flow is strong,an increased engine speed can accelerate the evaporation of the fuel droplets,but the guidance of the combustion chamber is weaked,which results in a bad mixture formation.On the contrary,when the intake flow is weak,higher engine speed can promote the effect of combustion chamber's guidance to the fuel plume.
- optical engine bench /
- low-pressure direct injection /
- combustion chamber geometry /
- high-speed camera /
- in-cylinder mixture formation

HTML

参考文献(15)

[1]	李玉珍,赵阳旭,郭璐.小型航空汽油发动机供油量的模糊控制[J].交通运输工程学报,2006,6(1):89-92. LI Yuzhen,ZHAO Yangxu,GUO Lu.Fussy control of fuel flow rate on small aviation gasoline engine[J].Journal of Traffic and Transportation Engineering,2006,6(1):89-92.(in Chinese)
[2]	李玉珍,高丕周,马震.电控汽油喷射改善小型无人机发动机性能的研究[J].航空学报,2004,25(3):233-236. LI Yuzhen,GAO Peizhou,MA Zhen.Research on the improvements of performance of mini-UAV’s engine by electronic controlled gasoline injection[J].Journal of Aeronautics,2004,25(3):233-236.(in Chinese)
[3]	Corporation R.New UAV engine optimized for power,package,weight-and noise. Ricardo Software and CAE,2010-02,2010.
[4]	Cathcart G,Dikson G,Ahern S.The application of air-assist direct injection for spark-ignited heavy fuel 2-stroke and 4-stroke engines. SAE Paper 2005-32-0065,2005.
[5]	Cathcart G,Railtion D.Improving robustness of spray guided DI combustion systems:the air-assisted approach. SAE Paper 2001-53-60,2001.
[6]	王小青,黄一敏,杨一栋,等.小型无人直升发动机控制系统设计[J].航空动力学报,2007,22(12):2139-2142. WANG Xiaoqing,HUANG Yiming,YANG Yidong,et al.Control system design for engine of a small size unmanned helicopter[J].Journal of Aerospace Power,2007,22(12):2139-2142.(in Chinese)
[7]	张天宏,黄向华.航空小型动力装置试验台测试系统[J].航空动力学报,2001,16(2):189-192. ZHANG Tianhong,HUANG Xianghua.A test system for mini aviation power unit[J].Journal of Aerospace Power,2001,16(2):189-192.(in Chinese)
[8]	曾国贵,廖智麟,阚兆成.某型无人直升机活塞式电喷发动机转速控制设计及试验[J].航空动力学报,2011,26(6):1384-1388. ZENG Guogui,LIAO Zhilin,KAN Zhaocheng.Speed control design and test for piston EFI engine of unmanned helicopter[J].Journal of Aerospace Power,2011,26(6):1384-1388.(in Chinese)
[9]	Matsubara K,Shima Y,Okumi M,et al.Analysis of mixture formation process in a stoichiometric direct injection gasoline engine. SAE Paper 2003-01-0066,2003.
[10]	Kakuho A,Yamaguchi K,Hashizume Y,et al.A study of air-fuel mixture formation in direct-injection SI engines. SAE Paper 2004-01-1946,2004.
[11]	Stan C,Eichert H,Tröger R,et al.Concept for modeling and optimization of the mixture formation using gasoline direct injection in compact high speed engines. SAE Paper 1999-01-2935,1999.
[12]	Zhao F,Laia M C,Harringtonb D L.Automotive spark-ignited direct-injection gasoline engines[J].Progress in Energy and Combustion Science,1999,25(5):437-562.
[13]	LI Yufeng,ZHAO Hua,Brouzos N,et al.Effect of injection timing on mixture and CAI combustion in a GDI engine with an air-assisted injector. SAE Paper 2006-01-0206,2006.
[14]	Kakuhou A,Urushihara T,Itoh T,et al.Characteristics of mixture formation in a direct injection SI engine with optimized in-cylinder swirl air motion. SAE Paper 1999-01-0505,1999.
[15]	Cathcart G,Zavier C.Fundamental characteristics of an air-assisted direct injection combustion system as applied to 4-stroke automotive gasoline engines. SAE Paper 2000-01-0256,2000.
