当量比和间隙尺寸对爆震波传播过程的影响
Effects of equivalence ratio and gap size on the propagation behavior of detonations
-
摘要: 为探索微型脉冲爆震发动机推进系统的可行性,进行了微空间内爆震极限特性的研究.通过对预混氢气/氧气爆震火焰在平板狭缝中的传播过程进行测量,分析了爆震波压力、速度随当量比和间隙尺寸的变化趋势,发现在极限范围外,来自稳流段的爆震波都能在间隙内通过压力和速度的自我调整后达到稳定状态,调整过程所需的距离随间隙尺寸减小而增长.根据爆震波速度衰减的定义,给出了激波和火焰锋面速度沿间隙通道方向的变化特点,观察到了微尺寸下爆震波的4种传播模式:稳定爆震波、准稳定爆震波、低速爆震波和非爆震波.Abstract: To explore the feasibility of micro-scale pulse detonation engine propulsion system,detonation limits in narrow channels have been investigated.By observing and measuring the propagation behavior of premixed hydrogen-oxygen detonation flames in narrow gaps,effects of gap size and equivalence ratio on detonation wave pressure and velocity were experimentally analyzed.Outside the detonation limit,the detonation wave coming from the guide section can reach a steady state in the gap by self-adjustment of the pressure and velocity.The distance required by the adjustment process was growing when the gap size decreased.According to the definition of velocity deficit,the characteristics of the velocities of shock and flame front along the micro-channel were summarized,and four propagation models-steady detonation,sub-steady detonation,low-speed detonation and non-detonation were observed.
-
Key words:
- micro-size /
- detonation wave /
- detonation limit /
- velocity deficit /
- propagation behavior
-
[1] Kitano S,Kimura Y,Sato H,et al.Micro-size pulse detonation engine performance. AIAA 2007-581,2007. [2] 黄玥,唐豪,李建中,等.煤油/空气小尺寸脉冲爆震发动机实验研究[J].航空学报,2009,30(11):2015-2022. HUANG Yue,TANG Hao,LI Jianzhong,et al.Experimental investigation on small-scale pulse detonation engine with kerosene/air[J].Acta Aeronautica et Astronautica Sinia,2009,30(11):2015-2022.(in Chinese) [3] 李建中.煤油/空气气动阀式脉冲爆震发动机研究. 南京:南京航空航天大学,2006. LI Jianzhong.Investigation on kerosene/air aero-valve pulse detonation engine. Nanjing:Nanjing University of Aeronautics and Astronautics,2006.(in Chinese) [4] 严传俊,范玮.脉冲爆震发动机原理及关键技术[M].西安:西北工业大学出版社,2005. [5] Dupre G,Knystautas R,Lee J H S.Near-limit propagation of detonation in tubes[J].Prog.Astronaut.Aeronaut,1986,106(1):244-259. [6] Dupre G,Peraldi O,Joannon J,et al.Limit criterion detonation in circular tubes[J].Prog.Astronaut.Aeronaut,1991,133(1):156-169. [7] Manson N,Guenoche H.Effect of charge diameter on the velocity of detonation waves in gas mixtures[J].Proceedings of the Combustion Institute,1957,6(1):631-639. [8] Fay J A.Two-dimensional gaseous detonations:velocity deficit[J].Phys.Fluids,1959,2(3):283-289. [9] Wu M H,Wang C Y.Reaction propagation modes in millimeter-scale tubes for ethylene/oxygen mixtures[J].Proceedings of the Combustion Institute,2011,33(2):2287-2293. [10] Wu M H,Burke M P,et al.Flame acceleration and the transition to detonation of stoichiometric ethylene/oxygen in microscale tubes[J].Proceedings of the Combustion Institute,2007,31(2),2429-2436. [11] 张彭岗,何小民,李建中,等.丙烷爆震特性的试验[J].航空动力学报,2009,24(6):1236-1241. ZHANG Penggang,HE Xiaomin,LI Jianzhong,et al.Experimental study on detonation characteristic of propane[J].Journal of Aerospace Power,2009,24(6):1236-1241.(in Chinese) [12] 邓君香,严传俊,范玮,等.单次爆震波的对比实验研究[J].燃烧科学与技术,2000,6(4):356-358. DENG Xiangjun,YAN Chuanjun,FAN Wei,et al.Comparative experimental study on single detonation wave[J].Journal of Combustion Science and Technology,2000,6(4):356-358.(in Chinese) [13] Schultz E,Shepherd J E.Validation of detailed reaction mechanisms for detonation simulation. Graduate Aeronautical Laboratories of the California Institute of Technology,Explosion Dynamics Laboratory Report FM99-5,2000. [14] Camargo A,Ng H D,Chao J,et al.Propagation of near-limit gaseous detonations in small diameter tubes[J].Shock Waves,2010,20(6):499-508. [15] Jackson S I.Gaseous detonation initiation via wave implosion. California:California Institute of Technology,2005.
