横向气流中液体圆柱射流的破碎特性和表面波现象

王雄辉; 黄勇; 王方; 王少林; 刘志林

横向气流中液体圆柱射流的破碎特性和表面波现象

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191

计量
- 文章访问数: 2137
- HTML浏览量: 147
- PDF量: 603
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-12
- 刊出日期: 2012-09-28

Breakup characteristics and surface wave phenomenon of round liquid jets in crossflows

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics, School of Jet Propulsion, Beijing University of Aeronauctics and Astronautics, Beijing 100191, China

摘要

摘要: 采用高速摄像仪对横向气流场中的圆形液体射流的圆柱破碎过程(低Weber数)进行了实验研究.实验采用直射式喷嘴,喷孔直径为0.3mm和0.5mm,喷嘴长径比均为40.实验工质采用水.Weber数为1.7~7,液/气动量通量比为3.4~83.实验观察了表面波现象及射流破碎形成的液滴的尺寸及其速度.观测发现,表面波波长随着气流Weber数的对数的增加而线性减小.破碎后形成的液滴直径 d_p/d₀与Weber数的对数成正比.液滴的初始x方向速度与y方向速度大小与液滴直径无关.在实验范围内,液滴y方向速度均不随Weber数和液/气动量通量比的变化,约为初始射流速度的0.94倍;而液滴x方向速度约为0.085倍的气流速度.对表面波和破碎后形成的液滴尺寸及速度的研究有助于构建更精确的初始雾化模型.
- 液体圆柱射流 /
- 横向气流 /
- 圆柱破碎 /
- 表面波 /
- 液滴直径 /
- 液滴速度
Abstract: An experiment was conducted to investigate column breakup process of round liquid jets in crossflow.High-speed camera was employed to observe surface wave phenomenon and the formation of droplets.The injectors used in the experiment were plain orifice nozzle and their diameters were 0.3mm and 0.5mm.The test liquid was tap water.Test Weber number covered the range of 1.7~7,and liquid-to-air momentum flux ratio varied from 3.4 to 83.Present results indicate that the surface wavelength,is in negative proportion to the logarithm of Weber number.With the increase of the logarithm of Weber number,the diameters of droplets increase linearly.Droplets' velocities,both streamwise direction and cross stream direction,are independent on their diameters.In the range of the experiment,droplets' cross stream velocity equals to about 0.94 v_j,and droplets' streamwise velocity is about 0.085 u_a.The results of surface wavelength and droplet's diameter and velocity can significantly improve the accuracy of primary breakup model.
- round liquid jet /
- crossflow /
- column breakup /
- surface waves /
- droplets' diameter /
- droplets' velocity

HTML

参考文献(15)

[1]	Tambe S B,Jeng S M,Mongia H,et al.Liquid jets in subsonic crossflow. Reno:43rd AIAA Aerospace Sciences Meeting and Exhibit,2005.
[2]	Wu P K,Kirkendall K A.Fullern R P.Spray structures of liquid fuel jets atomized in subsonic crossflows[J].Journal of Propulsion and Power,1998,14(2):173-182.
[3]	Becker J,Hassa C.Breakup and atomization of kerosene jet in crossflow at elevated pressure[J].Atomization and Sprays,2002,12(1/2/3):49-67.
[4]	ZHU Ying,HUANG Yong,WANG Fang,et al.Experiment on breakup processes and surface waves of round liquid jets in crossflows. Glasgow:Proceedings of ASME Turbo.Expo.,2010.
[5]	朱英,黄勇,王方,等.横向气流中的液体圆形射流破碎实验[J].航空动力学报,2010,25(10):2261-2266. ZHU Ying,HUANG Yong,WANG Fang,et al.Experiment on the breakup of round liquid jets in cross airflows. Journal of Aerospace Power,2010,25(10):2261-2266.(in Chinese)
[6]	Ingebo R D.Capillary and acceleration wave breakup of liquid jets in axial flow airstreams. Cleveland:National Aeronautics and Space Administration,1981.
[7]	Mazallon J,Dai Z,Faeth G M.Aerodynamic primary breakup at the surface of nonturbulent round liquid jets in crossflow. Reno:36th Aerospace Sciences Meeting and Exhibit,1998.
[8]	Ng C L,Sankarakrishinan R,Sallam K A.Bag breakup of nonturbulent liquid jets in crossflow[J].International Journal of Multiphase Flow,2008,34(3):241-259.
[9]	WANG Shaolin,HUANG Yong,WANG Xionghui,et al.Theoretical analysis of surface waves on the jet in crossflow with deformation. Shanghai:The 4th Asia-Pacific Power and Energy Engineering Conference,2012.
[10]	Sallam K A,Aalburg C,Faeth G M.Breakup of round nonturbulent liquid jets in gaseous crossflows[J].AIAA Journal,2004,42(12):2529-2540.
[11]	Aalburg C,Faeth G M,Sallam K A. Primary breakup of round turbulent liquid jets in uniform crossflows. Reno:43rd AIAA Aerospace Sciences Meeting and Exhibit,2005.
[12]	朱英,黄勇,郭志辉.液体圆形射流变形破碎及破碎长度实验. 吉林:冲压发动机技术交流会,2005.
[13]	万云霞,黄勇,朱英.液体圆柱射流破碎过程的实验[J].航空动力学报,2008,23(1):208-214. WAN Yunxia,HUANG Yong,ZHU Ying.Experiment on the breakup process of free round liquid jet[J].Journal of Aerospace Power,2008,23(1):208-214.(in Chinese)
[14]	Reitz R D,Bracco F V.Mechanism of atomization of a liquid jet[J].Physics of Fluids,1982,25(10):1730-1742.
[15]	Piriz A R,Cortazar O D,Cela J J L,et al.The Rayleigh-Taylor instability[J].American Journal of Physics,2006,74(12):1095-1098.
