基于二维曲面基准流场的流线追踪高超声速进气道设计

李永洲; 张堃元; 王磊; 南向军; 张林

基于二维曲面基准流场的流线追踪高超声速进气道设计

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 国家自然科学基金(90916029)

计量
- 文章访问数: 2394
- HTML浏览量: 385
- PDF量: 577
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-29
- 刊出日期: 2012-09-28

Design of streamline-traced hypersonic inlets based on two-dimensional curved surface basic flowfield

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 以压力梯度可控设计方法优化后的二维曲激波基准流场为基础,结合流线追踪和截面渐变技术实现了矩形进口、圆形进口以及方转椭圆进气道设计,证明基于二维曲激波基准流场可以设计出各种进出口截面形状的高超声速进气道.利用上述设计方法设计的3种不同进出口形状的高超声速进气道,与相同约束条件下的常规二元三楔进气道进行了对比.数值仿真研究表明:3种非常规进气道设计点无黏流场马赫数分布及总体性能与基准流场接近,具有二维基准流场的特征,波系结构简单,出口畸变较小.此类进气道的总体性能相当,较常规进气道可以显著缩短外压段长度,流量捕获能力更强,非设计点也表现出良好的性能.以上结果表明该设计方法是可行的,值得进一步研究.
- 高超声速进气道 /
- 基准流场 /
- 弯曲激波 /
- 流线追踪 /
- 数值仿真
Abstract: The rectangular and circular shape intake hypersonic inlets and rectangular to elliptical shape transition hypersonic inlet have been designed with the technologies of streamline tracing and varying section using an optimized two-dimensional(2-D) curved surface basic flowfield with controlled pressure gradient.It proved that hypersonic inlets with various entrance and exit shapes can be designed based on 2-D curved surface basic flowfield.Utilizing this design method,three hypersonic inlets with different entrance and exit shapes have been generated and compared with typical 2-D inlets under the same constraints.The numerical simulation shows that Mach number distributions and general performance for unconventional inlets approximate the basic flowfield at design point under the inviscid condition,which has the characteristics of 2-D basic flowfield that shock structure is simple and exit distortion is low.This kind of inlet has the roughly equivalent general performance.Comparison with typical 2-D inlet indicates that they significantly reduce the length of external compression portion,have greater flow ability to capture and demonstrate better performance at off design points.In conclusion,this design method is feasible and is worth being investigated further.
- hypersonic inlet /
- basic flowfield /
- curved shock /
- streamline tracing /
- numerical simulation

HTML

参考文献(16)

[1]	Mölder S,Szpiro J.Busemman inlet for hypersonic speeds[J].Journal of Spacecraft and Rockets,1966,3(8):1303-1304.
[2]	孙波,张堃元,王成鹏,等.Busemann 进气道无粘流场数值分析[J].推进技术,2005,26(3):242-247. SUN Bo,ZHANG Kunyuan,WANG Chengpeng,et al.Inviscid CFD analysis of hypersonic Busemann inlet[J].Journal of Propulsion Technology,2005,26(3):242-247.(in Chinese)
[3]	Billig F S,Baurle R A,Tam C J,et al.Design and analysis of streamline traced hypersonic inlets. AIAA 1999-4974,1999.
[4]	Smart M K.Design of three-dimensional hypersonic inlets with rectangular-to-elliptical shape transition[J].Journal of Propulsion and Power,1999,15(3):408-416.
[5]	Taylor T M,David V W.Performance analysis of hypersonic shape-changing inlets derived from morphing streamline traced flowpaths. AIAA 2008-2635,2008.
[6]	尤延铖,梁德旺.基于内乘波概念的三维变截面高超声速进气道[J].中国科学:E辑,2009,39(8):1483-1494. YOU Yancheng,LIANG Dewang.Design concept of three- dimensional section controllable internal wave-rider hypersonic inlet[J].Sci. China:Ser. E Tech. Sci.,2009,39(8):1483-1494.(in Chinese)
[7]	张堃元,Meier G E A.二维非均匀超音来流下最有利压缩面型面的随机选取法数值研究[J].推进术,1994,15(5):9-15. ZHANG Kunyuan,Meier G E A.A study on optimum compression surface under non-uniform 2-D supersonic flow condition using RC method[J].Journal of Propulsion Technology,1994,15(5):9-15.(in Chinese)
[8]	金志光,张堃元.二维非常规压缩型面/高超声速进气道的设计概念[J].推进技术,2004,25(3):226-229. JIN Zhiguang,ZHANG Kunyuan.Concept of a two-dimensional supersonic/hypersonic inlet with a non-conventional compression wall[J].Journal of PropulsionTechnology,2004,25(3):226-229.(in Chinese)
[9]	居燕.弯曲激波压缩面设计及试验研究. 南京:南京航空航天大学,2005. JU Yan.Design of curved shock compression surface and experimental investigation. Nanjing:Nanjing University of Aeronautics and Astronautics,2005.(in Chinese)
[10]	潘瑾,张堃元,王磊.几种超声速非常规压缩系统的研究[J].推进技术,2009,30(6):673-676. PAN Jin,ZHANG Kunyuan,WANG Lei.Study of several supersonic non-conventional compression surfaces[J].Journal of Propulsion Technology,2009,30(6):673-676.(in Chinese)
[11]	Starkey R P,Lewis M J.Simple analytical model for parametric studies of hypersonic waveriders. AIAA 1998-1616,1998.
[12]	王磊,张堃元.高超声速二元弯曲激波压缩面设计优化//中国力学大会:2011暨钱学森诞辰100周年纪念大会论文摘要集.北京:中国力学学会,2011:245.
[13]	南向军,张堃元,金志光,等.矩形转圆形高超声速内收缩进气道数值及实验研究[J].航空学报,2011,32(6):988-996. NAN Xiangjun,ZHANG Kunyuan,JIN Zhiguang,et al.Numerical and experimental investigation of hypersonic inward turning inlets with rectangular to circular shape transition[J].Acta Aeronautica et Astronautica Sinica,2011,32(6):988-996.(in Chinese)
[14]	NAN Xiangjun,ZHANG Kunyuan.Numerical and experimental investigation on hypersonic inward turning inlets with basic flow field using arc tangent curve law of pressure rise. AIAA 2011-2270,2011.
[15]	Bagaveyev N T,Engbom W A,Bhagwandin V A.Parametric investigation of racetrack-to-circular cross section transition of a dual-mode ramjet isolator. AIAA 2010-0942,2010.
[16]	李永洲,张堃元,南向军,等.类水滴进口高超声速内收缩进气道设计及数值研究[J].航空动力学报,2012,27(6):1355-1361. LI Yongzhou,ZHANG Kunyuan,NAN Xiangjun,et al.Design and numerical investigation of hypersonic inward turning inlet with water-drop like shape intake[J].Journal of Aerospace Power,2012,27(6):1355-1361.(in Chinese)
