航天器推进系统水击及其抑制方法

晏政; 彭小辉; 程玉强; 吴建军

航天器推进系统水击及其抑制方法

国防科学技术大学航天科学与工程学院, 长沙 410073

计量
- 文章访问数: 1475
- HTML浏览量: 0
- PDF量: 619
- 被引次数: 0
出版历程
- 收稿日期: 2012-03-28
- 刊出日期: 2012-09-28

Research of water hammer and its suppression methods for spacecraft propulsion system

College of Aerospace Science and Engineering, National University of Defense Technology, Changsha 410073, China

摘要

摘要: 针对航天器推进系统充填和关机过程水击这一动力学问题,基于已建立的航天器推进系统仿真模型,开展了某型推进系统的仿真研究,并重点分析了节流孔、弯管对推进剂供应管路水击的抑制作用.研究结果表明:①在推进系统充填和关机过程中,其不同位置均出现了明显的水击现象,充填过程水击频率较低,而关机过程水击频率较高,关机过程的水击峰值压力显著高于充填过程;②节流孔可显著削弱充填过程中的压力和流量振荡,关机过程的水击需要由较小的节流孔才能有效抑制;③弯管可明显削弱充填过程中的压力和流量振荡,对流量振荡的抑制效果尤为显著,但弯管对关机过程水击的抑制效果不明显.
- 航天器推进系统 /
- 系统动力学 /
- 动态特性 /
- 数值仿真 /
- 水击 /
- 水击抑制
Abstract: In order to investigate the water hammer dynamics of spacecraft propulsion system during the priming and shutdown processes,dynamic simulation of a certain unified propulsion system (UPS) was conducted firstly based on UPS simulator modeled previously.Then the water hammer suppression effect of orifice and bent pipe on the propellant supply pipeline was analyzed thoroughly.Results show that water hammer phenomena occur obviously in almost the whole propulsion system during the priming and shutdown processes.However,the frequency and the peak pressure of water hammer during the priming process are both lower than that of the shutdown process,especially the peak pressure.The results also show that both the orifice and the bent pipe can suppress the oscillation of pressure and flow rate significantly during the priming processes,but only orifice with small diameter can suppress the water hammer effectively during the shutdown process.Moreover,in contrast to their weak suppression of water hammer during the shutdown process,bent pipe can suppress the oscillation of flow rate especially effective in the priming process.
- spacecraft propulsion system /
- system dynamics /
- dynamic characteristics /
- numerical simulation /
- water hammer /
- water hammer suppression

HTML

参考文献(18)

[1]	林景松,王平阳,高红,等.液体火箭发动机关机水击的数值模拟[J].上海航天,2008(3):53-57. LIN Jingsong,WANG Pingyang,GAO Hong,et al.Numerical simulation of water hammer in shutting liquid rocket engine[J].Aerospace Shanghai,2008(3):53-57.(in Chinese)
[2]	Prickett R P,Mayer E,Hermel J.Water hammer in a spacecraft propellant feed system[J].Journal of Propulsion and Power,1992,8(3):592-597.
[3]	黎勤武,张为华,王振国,等.空间发动机系统关机过程水击现象理论分析[J].推进技术,1998,19(3):27-29. LI Qinwu,ZHANG Weihua,WANG Zhenguo,et al.Theoretical analyses of water-hammering in shutting space engine system[J].Journal of Propulsion Technology,1998,19(3):27-29.(in Chinese)
[4]	戴佳,黄敏超,沈赤兵,等.挤压式液体火箭发动机水击特性研究[J].上海航天,2007(1):52-55. DAI Jia,HUANG Minchao,SHEN Chibing,et al.Study on water hammer characteristics in pressure-fed liquid rocket engine[J].Aerospace Shanghai,2007(1):52-55.(in Chinese)
[5]	程谋森,刘昆,张育林.推进剂供应管路内液体瞬变流一维有限元计算[J].推进技术,2000,21(4):12-15. CHENG Mousen,LIU Kun,ZHANG Yulin.One-dimensional finite element solutions for liquid transients in propellant feedlines[J].Journal of Propulsion Technology,2000,21(4):12-15.(in Chinese)
[6]	聂万胜,陈新华,戴德海,等.姿控推进系统发动机关机的管路瞬变特性[J].推进技术,2003,24(1):6-8. NIE Wansheng,CHEN Xinhua,DAI Dehai,et al.Transient characteristics during shutdown operation of liquid feed line for attitude control propulsion subsystem[J].Journal of Propulsion Technology,2003,24(1):6-8.(in Chinese)
[7]	张黎辉,李家文,张雪梅,等.航天器推进系统发动机动态特性研究[J].航空动力学报,2004,19(4):546-549. ZHANG Lihui,LI Jiawen,ZHANG Xuemei,et al.Dynamic characteristics study of spacecraft propulsion system engine[J].Journal of Aerospace Power,2004,19(4):546-549.(in Chinese)
[8]	张育林,刘昆,程谋森.液体火箭发动机动力学理论与应用[M].北京:科学出版社,2005. ZHANG Yulin,LIU Kun,CHENG Mousen.Theory and application of liquid rocket engine dynamics[M].Beijing:Science Press,2005.(in Chinese)
[9]	苏龙斐,张黎辉,潘海林.卫星推进系统发动机启动过程数值仿真[J].航空动力学报,2005,20(4):698-701. SU Longfei,ZHANG Lihui,PAN Hailin.Numerical simulation on the starting process of satellite propulsion system[J].Journal of Aerospace Power,2005,20(4):698-701.(in Chinese)
[10]	薛科,张黎辉,苏龙斐,等.卫星推进系统真空充填过程数值仿真[J].航空动力学报,2007,22(2):323-326. XUE Ke,ZHANG Lihui,SU Longfei,et al.Numerical simulation of the priming process of satellite propulsion system[J].Journal of Aerospace Power,2007,22(2):323-326.(in Chinese)
[11]	Gibek I,Maisonneuve Y.Waterhammer tests with real propellants. AIAA 2005-4081,2005.
[12]	Lecourt R,Steelant J.Experimental investigation of waterhammer in simplified basic pipes of satellite propulsion systems[J].Journal of Propulsion and Power,2007,23(6):1214-1224.
[13]	Lema M,Steelant J,Pena F L,et al.Multiphase fluid hammer in spacecraft propulsion systems. AIAA 2011-5683,2011.
[14]	魏鑫,孙冰,于子文,等.火箭推进系统充液管路的流固耦合动响应分析[J].航空动力学报,2010,25(4):852-856. WEI Xin,SUN Bing,YU Ziwen,et al.Dynamic response analysis of fluid-structure interaction in liquid-filled pipes of rocket feed system[J].Journal of Aerospace Power,2010,25(4):852-856.(in Chinese)
[15]	Davis G T.The MAP propulsion subsystem. AIAA 2002-4156,2002.
[16]	王英浩.火箭推进剂输送系统中波纹管对水击压力的吸收分析. 长沙:国防科学技术大学,2004. WANG Yinghao.Analysis of bellows absorb water hammer in rocket propellant feed system. Changsha:National University of Defense Technology,2004.(in Chinese)
[17]	晏政,刘泽军,程玉强,等.航天器推进系统模块化建模方法[J].国防科技大学学报,2012,34(4):30-35. YAN Zheng,LIU Zejun,CHENG Yuqiang,et al.Modular modeling of spacecraft propulsion system[J].Journal of National University of Defense Technology,2012,34(4):28-32.(in Chinese)
[18]	Hearn H C.Development and application of a priming surge analysis methodology. AIAA 2005-3738,2005.
