非对称喷管超声速流场的PIV实验与数值模拟

俞凯凯; 徐惊雷; 马静

非对称喷管超声速流场的PIV实验与数值模拟

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 国家自然科学基金(50876042,90916032)

计量
- 文章访问数: 1647
- HTML浏览量: 3
- PDF量: 487
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-18
- 刊出日期: 2012-09-28

PIV experimental study and numerical simulation of single expansion ramp nozzle supersonic flow field

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 选取了跟随性能以及散射性能都上佳的二氧化钛粒子,利用了粒子图像测速仪(particle image velocimetry,PIV)对不同落压比下的非对称喷管(single expansion ramp nozzle,SERN)流场进行了测量,成功获取了相应流动结构,以及沿程上壁面压力分布和速度场等.在测得的图像中,可以清晰地观察到由于过膨胀产生的激波与膨胀波系,并进一步获得出口速度分布.运用计算流体动力学数值模拟方法,对实验状态下的非对称喷管进行了模拟.对比结果发现:PIV实验测得流场结构能很好地与其吻合,这互相验证了CFD计算和PIV实验的正确性及可靠性.
- 非对称喷管 /
- 粒子图像测速仪 /
- 示踪粒子 /
- 数值模拟 /
- 过膨胀
Abstract: The experiment choose TiO₂ which had good following performance as well as scattering property.The flowfield of the single expansion ramp nozzle (SERN) under different pressure ratios was researched by particle image velocimetry (PIV) and numerical method.In the experiment,the structure of the flowfield,the pressure on the upper expansion wall,the velocity vector,and so on have been successfully obtained.From the processed images,the shock and expansion wave can be observed clearly,and the velocity at the outlet has been further analysized.The experimental data agreed very well with the data from the computational fluid dynamics (CFD).Therefore,the accuracy and reliability of the PIV experiment and the CFD result were both validated.
- single expansion ramp nozzle (SERN) /
- particle image velocimetry (PIV) /
- tracer particle /
- numerical simulation /
- over-expansion

HTML

参考文献(16)

[1]	马钊.非对称大膨胀比喷管的实验研究与数值模拟. 南京:南京航空航天大学,2008. MA Zhao.The experiment and numerical study of single expansion ramp nozzle. Nanjing:Nanjing University of Aeronautics and Astronautics,2008.(in Chinese)
[2]	Capone F J.The nonaxisymmetric nozzle-it is for real. AIAA-1979-1810,1979.
[3]	Settles G S.Schlieren and shadowgraph techniques:visualizing phenomena in transparent media[M].New York:Springer Press,2001.
[4]	Estruch D,Lawson N J,Garry K P.Application of optical measurement techniques to supersonic and hypersonic aerospace flows[J].Journal of Aerospace Engineering,2009,22(4):383-395.
[5]	Raffel M,Willert C,Wereley S,et al.Particle image velocimetry:a practical guide[M].New York:Springer Press,2007.
[6]	盛森芝,徐月亭,袁辉靖.近十年来流动测量技术的新发展[J].力学与实践,2002,24(5):1-15. SHENG Senzhi,XU Yueting,YUAN Huijing.New development in the technology of flow measurement over the last decade[J].Mechanics and Engineering,1998,24(5):1-15.(in Chinese)
[7]	Goyne C P,McDaniel J C,Krauss R H,et al.Velocity measurement in a dual-mode supersonic combustor using particle image velocimetry. AIAA Paper 2001-1761,2001.
[8]	Melling A.Tracer particles and seeding for particle image velocimetry [J].Measurement Science and Technology,1997,8(12):1406-1416.
[9]	Van Der Draai R K.Application of PIV in (local) supersonic flows in DNW wind tunnels. AIAA 2005-4082,2005.
[10]	Zucrow M J,Hoffman J D.Gas dynamics[M].New York:Wiley,1976-1977.
[11]	TSI Incorporated.PIV reference manual[M].USA:TSI Incorporated,2003.
[12]	李念,张堃元,徐惊雷.二维非对称喷管数值模拟与验证[J].航空动力学报,2004,19(6):802-805. LI Nian,ZHANG Kunyuan,XU Jinglei.Simulation and experiment validation of a two dimensional asymmetric ramp nozzle[J].Journal of Aerospace Power,2004,19(6):802-805.(in Chinese)
[13]	梁德旺.流体力学基础[M].北京:航空工业出版社,1998.
[14]	Anderson J D,Jr.Hypersonic and high temperature gas dynamics[M].Reston,Virginia:American Institute of Aeronautics and Astronoutica Inc.,2000.
[15]	Zill A.Flow separation in rectangular over-expanded supersonic nozzles. Reno,NV,USA;44th AIAA Aerospace Sciences Meeting and Exhibit,2006.
[16]	Humble R A,Scarano F,Van Oudheusden B W,et al.PIV measurements of a shock wave/turbulent boundary layer interaction. Lisbon,Portugal:13th Int.Symp.on Applications of Laser Techniques to Fluid Mechanics,Paper No.1033,2006.
