考虑基体开裂的陶瓷基复合材料应力-应变曲线模拟方法及验证

孙志刚; 苗艳; 宋迎东

考虑基体开裂的陶瓷基复合材料应力-应变曲线模拟方法及验证

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 国家重点基础研究发展计划; 国家自然科学基金(51075204); 航空科学基金(2009ZB52028); 南京航空航天大学基本科研业务费专项科研项目(NS2010044,NZ2012106); 博士点基金(20070287039)

计量
- 文章访问数: 1740
- HTML浏览量: 100
- PDF量: 509
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-13
- 刊出日期: 2012-09-28

Simulating and validating the stress-strain curve of the matrix cracking of ceramic matrix composite

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 提出了蒙特卡罗方法模拟陶瓷基复合材料基体随机开裂过程,采用剪滞模型描述了复合材料出现损伤时细观应力场,并推导得到了考虑基体开裂时复合材料拉伸应力-应变曲线计算公式.开展了室温环境下C/SiC复合材料的单轴拉伸试验,并将理论预测应力-应变曲线与试验结果进行对比.同时,采用该方法对SiC/CAS,SiC/Si₃N₄复合材料应力-应变曲线进行了模拟,并与国外提供的相关试验数据进行比较,发现两者吻合得较好,从而证实了蒙特卡罗法可有效地模拟考虑基体随机开裂过程的陶瓷基复合材料应力-应变曲线.此外,还分析了Weibull模量、残余热应力和初始开裂应力对应力-应变曲线的影响.研究表明:Weibull模量越大,应力-应变曲线非线性越明显;热残余应力越大,应力-应变曲线偏转越早,非线性越明显;初始开裂应力与Weibull模量对应力-应变曲线影响规律相似.
- 蒙特卡罗 /
- 基体 /
- 随机开裂 /
- 应力-应变曲线 /
- 陶瓷基复合材料
Abstract: The matrix random cracking of ceramic matrix composite was simulated by Montel Carlo model.The shear-lag model was used to analyze the micro-stress field of the damaged composites,and the formula of the stress-strain behavior was derived.The uniaxial tensile experiment of unidirectional-C/SiC composites at ambient temperature has been performed,and the simulated stress-strain curve was compared to the experimental data.The tensile stress-strain curves of SiC/CAS and SiC/Si₃N₄ composites were simulated,which agreed well with the related experimental results.Besides,infuence of the model parameters on stress-strain curve was analyzed.Research shows that the higher the Weibull modulus,the more evident the non-linear phenomenon;the higher the thermal residual stress,the earlier the non-linear phenomenon appears;the effect of the minimum cracking stress on the stress-strain is similar to the effect of the Weibull modulus;the Monte Carlo model can simulate the stress-strain curve of ceramic matrix composites efficiently.
- Monte Carlo /
- matrix /
- random cracking /
- stress-strain curve /
- ceramic matrix composites

HTML

参考文献(15)

[1]	苗艳.陶瓷基复合材料的基体失效模型. 南京:南京航空航天大学,2007. MIAO Yan.Research on the failture models of matrix in ceramic matrix composites. Nanjing:Nanjing University of Aeronautics and Astronautics,2007.(in Chinese)
[2]	孙志刚,宋迎东,苗艳,等.陶瓷基复合材料基体随机开裂的损伤模拟[J].复合材料学报,2009,26(4):130-135. SUN Zhigang,SONG Yingdong,MIAO Yan,et al.Simulation of the matrix random cracking of ceramic matrix composite by Monte Carlo model[J].Acta Materiae Compositae Sinica,2009,26(4):130-135.(in Chinese)
[3]	孙志刚,李龙彪,朱彬,等.界面层参数对陶瓷基复合材料单轴拉伸行为的影响[J].航空动力学报,2010,25(3):597-602. SUN Zhigang,LI Longbiao,ZHU Bin,et al.Effect of interface layer parameters on uniaxial tensile behavior of ceramic matrix composites[J].Journal of Aerospace Power,2010,25(3):597-602.(in Chinese)
[4]	李龙彪,宋迎东,孙志刚.单向纤维增强陶瓷基复合材料单轴拉伸行为[J].复合材料学报,2008,25(4):154-160. LI Longbiao,SONG Yingdong,SUN Zhigang.Niaxial tensile behavior of unidirectional fiber reinforced ceramic matrix composites[J].Acta Materiae Composite Sinica,2008,25(4):154-160.(in Chinese)
[5]	李龙彪,宋迎东,孙志刚.纤维泊松收缩对陶瓷基复合材料基体裂纹演化的影响[J].航空动力学报,2008,23(12):2196-2201. LI Longbiao,SONG Yingdong,SUN Zhigang.Influence of fiber Poisson contraction on matrix crack evolution of ceramic matrix composites[J].Journal of Aerospace power,2008,23(12):2196-2201.(in Chinese)
[6]	Zok F W,Spearing S M.Matrix crack spacing in brittle matrix composites[J].Acta Metall Mater,1992,40:2033-2043.
[7]	高希光,孙志刚,廉英琦,等.弱界面黏结通用单胞模型理论及应用[J].航空动力学报,2009,24(8):1684-1690. GAO Xiguang,SUN Zhigang,LIAN Yingqi,et al.General ized method of cell with weak interfacial bonding[J].Journal of Aerospace Power,2009,24(8):1684-1690.(in Chinese)
[8]	高希光,孙志刚,廉英琦,等.弱界面黏结通用单胞模型数值分析[J].航空动力学报,2009,24(8):2019-2025. GAO Xiguang,SUN Zhigang,LIAN Yingqi,et al.Numerical study of generalized method of cell with weak interfacial bording[J].Journal of Aerospace Power,2009,24(8):2019-2025.(in Chinese)
[9]	孙志刚,宋迎东,廉英琦,等.弱界面黏结对复合材料有效性能的影响[J].航空动力学报,2005,20(6):915-919. SUN Zhigang,SONG Yingdong,LIANG Yingqi,et al.Composite mechanical be havior with weak interfacial bonding[J].Journal of Aerospace Power,2005,20(6):915-919.(in Chinese)
[10]	Curtin W A.Theory of mechanical properties of ceramic-matrix composites[J].Journal of American Ceram.Soc.,1991,74(11):2837-2845.
[11]	Ahn B K,Curtin W A.Strain and hysteresis by stochastic matrix cracking in ceramic matrix composites[J].Journal of Mechanics Physical Solids,1997,45:177-209.
[12]	Kuo W S.Damage of multi-directionally reinforced ceramic matrix composites. Delaware:University of Delaware, 1992.
[13]	Douglas S,Bcyerle S,Spearing M,et al.Damage mechanisms and the mechanical properties of a laminaed 0/90 ceramic/matrix composite[J].Journal of American Ceram.Soc.,1992,75(12):3321-3330.
[14]	Bhatt R T.Properties of silicon carbide fiber-reinforced silicon nitride matrix composites. NASA-TM-101356,1988.
[15]	American Society for Testing and Materials.ASTM C 1275-00,standard test method for monotonic tensile behavior of continuous fiber-reinforced advanced ceramics with solid rectangular cross-sections test specimens at ambient temperatures. American:American Society for Testing and Materials,2000.
