非均匀温度场下声发射源定位方法

陈亚农; 何田; 肖登红; 刘献栋

非均匀温度场下声发射源定位方法

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
北京航空航天大学交通科学与工程学院, 北京 100191

基金项目: 国家自然科学基金(50875010,51105018); 航空科学基金(2011ZB51039)

计量
- 文章访问数: 1674
- HTML浏览量: 82
- PDF量: 474
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-18
- 刊出日期: 2012-09-28

Location method of acoustic emission source in non-uniform temperature field

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
School of Transportation Science and Engineering, Beijing University of Aeronautics Astronautics, Beijing 100191, China

摘要

摘要: 针对非均匀温度场下声发射信号传播速度不一致导致时差定位法定位精度下降的问题,研究基于波束形成法的声发射源定位效果.首先,基于板波理论研究声发射信号的传播特性,分析频散现象等对声发射信号速度测试的影响;然后通过数值仿真研究声发射波束形成法定位精度对不同重建速度的定位效果,进而发现在声发射波束形成法在阵列方向具有速度不敏感性.在加热前后的薄钢板上进行断铅定位实验,其结果表明声发射波束形成法可以在非均匀温度场中保持较高的定位精度,在机匣温度不均的航空发动机碰摩定位领域有良好的应用前景.
- 定位 /
- 声发射 /
- 波束形成 /
- 板波 /
- 碰摩
Abstract: In view of the location accuracy decrease of time division of arriving (TDOA) method in non-uniform temperature field,the location performance of acoustic emission beam-forming was studied.Firstly,the propagation characteristics of acoustic emission signals were obtained by using plate wave theory,and the main factors affecting the accuracy like dispersion phenomenon are analyzed on the basis of the results.Then,the location performance of acoustic emission beam-forming based on uniform linear array wss explored by numerical simulation,and show that the positioning accuracy on sensors array direction is stable in certain speed range.The artificial acoustic emission sources which were created by breaking a mechanical pencil lead on the plate surface before and after heating were implemented to verify the simulation.The results were analyzed and show that the acoustic emission beam-forming method has high location accuracy in non-uniform temperature field and good prospect of application for positioning stator-rotor rub of aero-engine in which stator has uneven temperature.
- location /
- acoustic emission /
- beam-forming /
- plate wave /
- rub

HTML

参考文献(15)

[1]	Sinha S K.Dynamic characteristics of a flexible bladed-rotor with Coulomb damping due to tip-rub[J].Journal of Sound and Vibration,2004,273(4):875-919.
[2]	刘书国,洪杰,陈萌.航空发动机叶片-机匣碰摩过程的数值模拟[J].航空动力学报,2011,26(6):1282-1288. LIU Shuguo,HONG Jie,CHEN Meng.Numerical simulation of the dynamic process of aero-engine blade-to-case rub-impact[J].Journal of Aerospace Power,2011,26(6):1282-1288.(in Chinese)
[3]	卢文秀,褚福磊,郭丹.基于遗传算法的碰摩位置辨识[J].清华大学学报:自然科学版,2005,45(2):208-211. LU Wenxiu,CHU Fulei,GUO Dan.Rubbing location identification based on genetic algorithms[J].Journal of Tsinghua University:Science and Technology,2005,45(2):208-211.(in Chinese)
[4]	于涛,韩清凯,孙伟,等.基于模态扩展与谐波分解的转子碰摩故障精确诊断[J].东北大学学报:自然科学版,2006,27(5):524-527. YU Tao,HAN Qingkai,SUN Wei,et al.Precise diagnosis of rotor rubbing fault based on modal expansion and harmonic decomposition[J].Journal of Northeastern University:Natural Science,2006,27(5):524-527.(in Chinese)
[5]	邓艾东,包永强,赵力.转子碰摩声发射源定位中的广义互相关时延估计研究[J].中国电机工程学报,2009,29(14):86-92. DENG Aidong,BAO Yongqiang,ZHAO Li.Research on time delay estimation algorithm based on generalized cross correlation in acoustic emission source location[J].Proceedings of the CSEE,2009,29(14):86-92.(in Chinese)
[6]	Hall L D,Mba D.Acoustic emissions diagnosis of rotor-stator rubs using the KS statistic[J].Mechanical Systems and Signal Processing,2004,18(4):849-868.
[7]	金志浩,刘俊煊,金文,等.旋转机械碰摩故障声发射信号的特征识别研究[J].沈阳化工学院学报,2008,22(2):153-156. JIN Zhihao,LIU Junxuan,JIN Wen,et al.Study on the feature recognition of acoustic emission signals from the rubbing fault of rotor[J].Journal of Shenyang Institute of Chemical Technology,2008,22(2):153-156.(in Chinese)
[8]	褚福磊,王庆禹,卢文秀.用声发射技术与小波包分解确定转子系统的碰摩位置[J].机械工程学报,2002,38(3):139-143. CHU Fulei,WANG Qingyu,LU Wenxiu.Detection of the rub location in a rotor system with AE sensors and wavelet analysis[J].Chinese Journal of Mechanical Engineering,2002,38(3):139-143.(in Chinese)
[9]	DENG Aidong,GAO Wei,BAO Yongqiang,et al.Study on recognition characteristics of acoustic emission based on fractal dimension. The 2008 International Conference on Embedded Software and Systems Symposia (ICESS2008): 475-478.
[10]	Majid A,Mehrdad S B.Leak detection in water-filled plastic pipes through the application of tuned wavelet transforms to Acoustic Emission signals[J].Applied Acoustics,2010,71(7):634-639.
[11]	何田,刘耀光,陈亚农,等.基于声发射波束形成法的转静子碰摩故障定位研究[J].航空动力学报,2011,26(10):2207-2213. HE Tian,LIU Yaoguang,CHEN Yanong,et al.Method for locating rub fault of rotor-stator based on acoustic emission beamforming[J].Journal of Aerospace Power,2011,26(10):2207-2213.(in Chinese)
[12]	梁宏宝,朱安庆.高温超声横波波速规律与影响因素研究[J].机械设计与制造,2007(8):27-29. LIANG Hongbao,ZHU Anqing.The study of the law of ultrasonic shear wave velocity and influence factor[J].Machinery Design & Manufacture,2007(8):27-29.(in Chinese)
[13]	Yang J,Gana W,Tan K,Er M.Acoustic beamforming of a parametric speaker comprising ultrasonic transducers[J].Sensors and Actuators A,2005,125(1):91-99.
[14]	Miklowitz J.Elastic waves and waveguides[M].New York:North-Holland Publishing Company,1978.
[15]	Rose J L.Ultrasonic waves in solid media[M].London:Cambridge University Press,1999.
