小流量多级高负荷轴流压气机设计

解亚东; 单鹏

小流量多级高负荷轴流压气机设计

解亚东,
单鹏

北京航空航天大学能源与动力工程学院, 北京 100191

计量
- 文章访问数: 1417
- HTML浏览量: 2
- PDF量: 434
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-14
- 刊出日期: 2012-09-28

Design research of small flow rate multi-stage high-loaded axial compressor

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100019, China

摘要

摘要: 以增压比为6的国外某小流量5级轴流压气机为设计原型,在不超过其前3级的轴向长度的条件下,设计了3级轴流压气机,研究其最大增压能力.在采用了正预旋、静子端弯、第2、3级转子叶尖适度斜流等措施后,3级轴流的设计点流量为5.80kg/s,增压比为5.445,效率为0.8272,喘振裕度为11.8%,3级平均级增压比为1.759.研究结果表明:在一定的轴向长度限制下,小流量3级轴流压气机虽可以达到5.5量级的增压比,但其流量特性曲线已经变得很陡峭.
- 轴流压气机设计 /
- 小流量压气机 /
- 多级压气机 /
- 高负荷 /
- 端弯
Abstract: The pressure ratio of a five stage foreign compressor with small flow rate is 6.On condition that not exceeding its pre three stage axial length,a three stage compressor was designed and its maximum pressurizing ability was researched.By using positive pre-whirl,end-bend stator and the measure that properly boosted the shroud of the second and third stages,the design result of this three stage compressor was that the mass flow rate was 5.80kg/s,pressure ratio was 5.445,efficiency was 0.8272,surge margin was 11.8%,and average stage pressure ratio was 1.759.On condition that not exceeding the limit of a certain axial length,the small flow three stages got the pressure level of 5.5.The flow characteristic curve has been cliffy.
- axial compressor design /
- small mass flow ratio compressor /
- multi-stage compressor /
- high-loaded axial compressor /
- end-bend
