涡轴发动机LQ/<em>H</em><sub>∞</sub>抗扰控制方法

廖光煌; 李秋红; 卢辰昊; 黄金泉

涡轴发动机LQ/H_∞抗扰控制方法

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
中国航空工业集团公司航空动力控制系统研究所, 江苏无锡 214063

基金项目: 中央高校基本科研业务费专项资金(NZ2012104)

计量
- 文章访问数: 1538
- HTML浏览量: 1
- PDF量: 441
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-17
- 刊出日期: 2012-09-28

Disturbance rejection control method for turboshaft engines based on LQ/H_∞

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Aviation Motor Control System Institute, Aviation Industry Corporation of China, Wuxi Jiangsu 214063, China

摘要

摘要: 提出了抑制涡轴发动机负载干扰的线性二次型(LQ)/H_∞控制算法,以总距为干扰建模,利用线性矩阵不等式求得既满足LQ指标又对干扰具有H_∞性能约束的状态反馈控制律.提出修正指令抑制干扰策略.采用比例微分控制将总距变化转换为动力涡轮转速指令的修正,实现增大或减小机动飞行中动力涡轮转速指令,抑制实际转速的下垂或超调.仿真结果表明:该控制方法能有效抑制干扰并具有良好的实时性.
- 涡轴发动机 /
- 抗扰控制 /
- 线性二次型 /
- H_∞ /
- 变指令
Abstract: The linear quadratic (LQ)/H_∞ control method was proposed for turboshaft engines to reject disturbance.The collective pitch was treated as disturbance during modeling.The state feedback law was obtained based on linear matrix inequality (LMI), and it satisfied both LQ index and H_∞ disturbance rejection index.The disturbance rejection method based on reference adjustment was proposed.The adjustment of power turbine rotor speed reference was achieved by proportional derivative (PD) control according to collective pitch variation,and the overshoot or droop of the real speed was suppressed during maneuver.Simulation results show that the methods proposed can suppress the disturbance effectively and run in realtime.
- turboshaft engine /
- disturbance rejection control /
- linear quadratic /
- H_∞ /
- reference variation

HTML

参考文献(15)

[1]	Ahmet D,Zhen G,Jonathan S L.A simplified dynamic model of the T700 turboshaft engine. NASA TM/105805,TR 92-C-024,1992.
[2]	姚文荣,涡轴发动机/旋翼综合建模控制及优化研究. 南京:南京航空航天大学,2008. YAO Wenrong.Research on integrated modeling,control and optimization of turboshaft engine /rotor. Nanjing:Nanjing University of Aeronautics and Astronautics,2008.(in Chinese)
[3]	杨征山,李胜泉,章霖官.涡轴发动机动力涡轮转速控制回路方案研究[J].航空发动机,2005,31(2):46-50. YANG Zhengshan,LI Shengquan,ZHANG Linguan.Speed control loop schemes for power turbines of turboshaft engine[J].Journal of Aeroengine,2005,31(2):46-50.(in Chinese)
[4]	Smith B,Zagranski R.Next generation control system for helicopter engines. Washington DC:57th Annual Forum of AHS,2001.
[5]	李胜泉,杨征山,孙健国.基于内模原理的涡轴发动机状态反馈控制方法[J].航空动力学报,2007,22(5):829-832. LI Shengquan,YANG Zhengshan,SUN Jianguo.Investigation of state feedback control based on internal model principle for an turbo-shaft engine[J].Journal of Aerospace Power,2007,22(5):829-832.(in Chinese)
[6]	张海波,孙健国,孙立国.一种涡轴发动机转速抗扰控制器设计及应用[J].航空动力学报,2010,25(4):943-950. ZHANG Haibo,SUN Jianguo,SUN Liguo.Design and application of a disturbance rejection rotor speed control method for turbo-shaft engines[J].Journal of Aerospace Power,2010,25(4):943-950.(in Chinese)
[7]	孙立国,孙健国,张海波,等.基于支持向量回归机的发动机/直升机扭矩超前控制[J].航空动力学报,2011,26(3):680-686. SUN Liguo,SUN Jianguo,ZHANG Haibo,et al.Torque feed-forward control of engine/helicopter system based on support vector regression[J].Journal of Aerospace Power,2011,26(3):680-686.(in Chinese)
[8]	Athans M,Kapasouris P,Kappos E,et al.Linear-quadratic Gaussian with loop transfer recovery methodology for the F-100 engine[J].AIAA,1986,9(1):45-52.
[9]	Athans M,Cambridge M,Kappos E,et al.Multivariable control for the F-100 engine using the LQG/LTR methodology. AIAA-1984-1910,1984.
[10]	Dellinger W F,Alouani A T.Application of linear multivariable control design for the GE-21 turbofan jet engine. Tallahassee:System theory,Twenty-First Southeastern Symposium,1989.
[11]	William H P,Gustavo D R,George A B.The application of LQR synthesis techniques to the turboshaft engine control program. AIAA-84-1455,1984.
[12]	DING Daweil,YANG Guanghong.Static output feedback control for discrete-time piecewise linear systems:an LMI approach[J].Acta Automatica Sinica,2009,35(4):337-344.
[13]	Köroğlu H,Carsten W S.An LMI approach to H_∞ synthesis subject to almost asymptotic regulation constraints[J].Systems & Control Letters 2008,57(4):300-308.
[14]	孙立国,孙健国,张海波,等.基于直升机/发动机非线性综合仿真模型的增广LQR 控制器设计[J].航空动力学报,2010,25(2):471-476. SUN Liguo,SUN Jianguo,ZHANG Haibo,et al.Augmented linear quadratic regulator controller design based on non-linear integrated helicopter/engine model[J].Journal of Aerospace Power,2010,25(2):471-476.(in Chinese)
[15]	李秋红,孙健国.航空发动机解耦控制器设计[J].航空学报,2006,27(6):1046-1050. LI Qiuhong,SUN Jianguo.Aeroengine decoupling controller design[J].Acta Aeronautica et Astronautica Sinica,2006,27(6):1046-1050.(in Chinese)
