新型变几何火焰稳定器燃烧特性试验

柳杨; 金捷; 王慧汝; 杨茂林

新型变几何火焰稳定器燃烧特性试验

北京航空航天大学能源与动力工程学院,北京 100083

计量
- 文章访问数: 1623
- HTML浏览量: 7
- PDF量: 560
- 被引次数: 0
出版历程
- 收稿日期: 2012-03-23
- 刊出日期: 2012-10-28

Experiment on combustion characteristics of novel variable geometry flame-holder

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100083,China

摘要

摘要: 在二元燃烧试验台上研究了一种新型变几何火焰稳定器的燃烧特性,重点描述了在不同试验工况下,稳定器燃烧效率、出口温度分布与稳定器几何形状变化的关系,并且通过稳定器的燃烧图像分析了几何变化对于燃烧状态及火焰结构的影响.结果表明:试验工况下,随着几何形状的改变,稳定器的燃烧效率呈现一定幅度的变化;尾缘槽宽与整流罩宽度比 w/h =1.25表现出其特殊性,在该点稳定器的燃烧状态和火焰结构发生较明显地改变;在稳定燃烧过程中,随着 w/h 的减小,出口截面中心温度不断升高,温度分布的均匀性降低.试验数据和结论有助于加深对该型变几何火焰稳定器的了解,并对该型稳定器的数值模拟和进一步试验研究有着重要的参考意义.
- 火焰稳定器 /
- 燃烧 /
- 加力燃烧室 /
- 变几何 /
- 试验
Abstract: A novel variable geometry flame-holder (“VGF” for short) based on v-gutter has been experimentally studied on a two-dimensionally combustion test-bed for its combustion characteristics .The effect of the change of gutter trailing edge width w on combustion efficiency and exit temperature distribution in different operating conditions was analyzed emphatically.Furthermore,the effect of the change of w on combustion status and flame structure was discussed by the combustion images in recirculation zone.Results show that: for the test conditions, (1) when w/h changes in 1.25~2.00, there is a certain range change in combustion efficiency.(2) w/h =1.25 shows specificity because the VGF combustion status and flame structure have changed at this point.(3) In the stable combustion condition,temperature of outlet cross-section center increases with the w decrease basically.Results and experimental data presented would enhance the phenomenological understanding of this novel VGF,and would contribute to the next experimental study and numerical simulation on it.
- flame-holder /
- combustion /
- afterburner /
- variable geometry /
- experiment

HTML

参考文献(15)

[1]	高歌,宁榥.沙丘驻涡火焰稳定性的理论及试验研究[J].工程热物理学报,1982,3(1):89-95. GAO Ge,NING Huang.Theoretical and experimental study in stability of the barchan dune vortex flame[J].Journal of Engineering Thermophysics,1982,3(1):89-95.(in Chinese)
[2]	杨茂林,全中,白兴艳,等.尾缘吹气式火焰稳定器试验研究[J].航空动力学报,1998,13(2):185-188. YANG Maolin,QUAN Zhong,BAI Xingyan,et al.Experimental investigation on EBMC flame-holder[J].Journal of Aerospace Power,1998,13(2):185-188.(in Chinese)
[3]	张洪滨,王纪根.双V型火焰稳定器的研制和应用[J].推进技术,1994,15(1):38-43. ZHANG Hongbin,WANG Jigen.Development and application of double V type flame stabilizer[J].Journal of Propulsion Technology,1994,15(3):38-43.(in Chinese)
[4]	韩启祥,刘洪,王方,等.开孔沙丘驻涡火焰稳定器总压损失的试验研究[J].推进技术,1999,20(4):82-85. HAN Qixiang,LIU Hong,WANG Fang,et al.Experimental investigation on total pressure loss of vortex flame holder with holes[J].Journal of Propulsion Technology,1999,20(4):82-85.(in Chinese)
[5]	刘鸿,王方,王家骅.特种V型蒸发式火焰稳定器的低压性能试验研究[J] 江苏工业学院学报,2004,15(1):12-14. LIU Hong,WANG Fang,WANG Jiahua.Experimental study of the performance of special evaporating V-gutter flame-holder at low pressure[J].Journal of Jiangsu Polytechnic University,1999,32(4):82-85.(in Chinese)
[6]	郑殿峰,张会强,林文漪,等.带U型槽射流缝隙式稳定器燃烧性能的试验研究[J].航空动力学报,2003,18(6):808-812. ZHENG Dianfeng,ZHANG Huiqiang,LIN Wenyi,et al.Experimental investigation of combustion performance of U-type flame holder[J].Journal Of Aerospace Power,2003,18(6):808-812.(in Chinese)
[7]	杜一庆.高温、低阻、高效加力燃烧室火焰稳定器机理研究 .武汉:华中科技大学,2005. DU Yiqing.Mechanism investigation on aircraft afterburner flameholder of high efficiency,low drag and high temperature resistance .Wuhan:Huazhong University of Science and Technology,2005.(in Chinese)
[8]	Eugene L,Caleb N C,John T C,et al.Novel carbureted flame holder for improved afterburner stability .AIAA 2008-98,2008.
[9]	Eric C,Rrederic P E,Gerard E A J.Variable geometry flame retention device for turbomachine after-burner:UK,GB2264554A .1993-01-09.
[10]	Robert H R,Bruno G L,Jack L R.Element de montage d'aubes:France,FR2522362A1, .1983-02-22.
[11]	Richard R,Charles T S,Arthur P A.Ispositif de montage d'aube a pas variable:France,FR2312673A1, .1976-05-26.
[12]	Jean G,Marc F B,Denis J M.Disposltlf de reglage de la perte de charge d'au moins un des flux dans un turboreacteur multiflux:Europeen,EP0094296A1, .1983-03-05.
[13]	LIU Yang,JIN Jie,WANG Huiru,et al.Experiment of drag characteristics of a novel variable geometry flame-holder[J].Journal of Aerospace Power.2011,26(11):2485-2494.
[14]	顾善建,杨茂林,吴继平,等.油珠在火焰稳定器表面的溅跳雾化及集油率测量[J].推进技术,1987,8(5):27-34. GU Shanjian,YANG Maolin,WU Jiping,et al.Splashing atomization and collecting rate measurement of fuel droplets on flameholder[J].Journal of Propulsion Technology,1987,8(5):27-34.(in Chinese)
[15]	杨茂林,黄勇,顾善建,等.燃油在稳定器尾缘的二次雾化研究[J]航空动力学报,1992,7(1):61-64. YANG Maolin,HUANG Yong,GU Shanjiang,et al.Study on secondary atomization of liquid fuel at the lip of the flameholder[J].Journal of Aerospace Power,1992,7(1):61-64.(in Chinese)
