火焰筒压力损失对点火特性的影响

薛鑫; 林宇震; 张弛; 许全宏; 杜江毅

火焰筒压力损失对点火特性的影响

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

计量
- 文章访问数: 1618
- HTML浏览量: 2
- PDF量: 610
- 被引次数: 0
出版历程
- 收稿日期: 2011-11-21
- 刊出日期: 2012-10-28

Effects of liner pressure loss on combustor ignition performances

National Key Laboratory of Science and Technology on Aero-Engine Aerothermodynamics, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing,100191,China

摘要

摘要: 以3.0%火焰筒压力损失火焰筒作为基准,分别设计了2.5%和2.0%火焰筒压力损失的火焰筒,通过试验研究火焰筒压力损失对地面起动点火性能的影响,对火焰筒内部流场进行数值模拟.在火焰筒压力降3.0%以内的空气条件下,3种方案贫油点火边界基本一致,低压力损失火焰筒能够在更宽的压力降条件下点燃,2.5%方案的综合点火性能最好.结合数值模拟结果:压力损失降低至2.0%,流场结构与基准方案有较大的区别,对燃烧室的性能开始产生不利影响,2.5%方案与基准方案流场结构较为接近,定量的变化对燃烧室的性能影响是有益的.
- 燃气轮机燃烧室 /
- 燃烧室设计 /
- 火焰筒压力损失 /
- 地面点火特性 /
- 贫油边界
Abstract: Based on a combustor of 3.0% liner pressure loss, two low pressure loss liners ( 2.5% and 2.0% ) were designed. The light lean ignition experiments and numerical simulation were conducted to study the effect of liner pressure loss on the combustor ignition performance. On the condition of pressure drop less than 3%, the ignition performances were almost the same. On the condition of pressure drop greater than 3%, the ignition performances of low liner pressure loss were better than that of the baseline liner, and 2.5% pressure loss liner was the best of the overall ignition performance. Combined with numerical simulation results, the flow structure of liner of 2.0% pressure loss was significantly different from that of the baseline liner, which had a negative effect on the performance of ignition. The flow structure of liner of 2.5% pressure loss was similar with that of the baseline liner, which had a positive effect on the performance of ignition.
- gas turbine combustor /
- combustor design /
- liner pressure loss /
- ignition performance /
- lean ignition boundary

HTML

参考文献(15)

[1]	沈维道,蒋智敏,童钧耕.工程热力学[M].北京:高等教育出版社,2001.
[2]	廉筱纯,吴虎.航空发动机原理[M].西安:西北工业大学出版社,2005.
[3]	金如山.航空燃气轮机燃烧室[M].北京:宇航出版社,1988.
[4]	Lefebvre A H,Ballal D R.Gas turbine combustion,alternative fuels and emission,third edition edition[M].Boca Raton:Taylor & Francis,2010.
[5]	Williams F A.Combustion theory[M].2版.庄逢辰,杨本濂,译.北京:科学出版社,1990.
[6]	林宇震,许全宏,刘高恩.燃气轮机燃烧室[M].北京:国防工业出版社,2008.
[7]	胡正义.航空发动机设计手册:第9册[M].北京:航空工业出版社,2000.
[8]	彭云晖,林宇震,许全宏,等.双旋流空气雾化喷嘴喷雾、流动和燃烧性能[J].航空学报.2008,29(1):1-14. PENG Yunhui,LIN Yuzhen,XU Quanhong,et al.Atomization,aerodynamics and combustion performance of swirl cup[J].Acta Aeronautica et Astronautica Sinica,2008,29(1):1-14.(in Chinese)
[9]	Ballal D R,Lefebvre A H.Ignition of liquid fuel sprays at subatmospheric pressures[J].Combustion and Flame,1978,31(2):115-126.
[10]	Rao H N S,Lefebvre A H.Ignition of kerosene fuel spray in a flowing air stream[J].Combustion Science and Technology,1973,8(1/2):95-100.
[11]	Rao K V L,Lefebvre A H.Minimum ignition energies in flowing kerosene-air mixture[J].Combustion and Flame,1976,27:1-20.
[12]	Ballal D R,Lefebvre A H.A general model of spark ignition for gaseous and liquid fuel-air mixture //18th Symposium (International) on Combustion.Waterloo:Combustion Institute,1981:1737-1746.
[13]	Lefebvre A H.Fuel effects on gas turbine combustion-ignition,stability,and combustion efficiency[J].Journal of Engineering for Gas Turbine and Power,1985,107(24):23-37.
[14]	Ballal D R,Lefebvre A H.Ignition and flame quenching in flowing gaseous mixtures //Proceedings of the Royal Society of London.Series A,Methematical and Physical Sciences.London:Royal Society,1977:163-181.
[15]	Ballal D R,Lefebvre A H.Ignition and flame quenching in flowing heterogeneous fuel-air mixtures[J].Combustion and Flame,1979,35:155-168.
