尾缘锯齿修形对波瓣强迫混合排气系统性能影响

丁玉林; 刘友宏; 谢翌; 邵万仁; 吴飞

尾缘锯齿修形对波瓣强迫混合排气系统性能影响

1.
北京航空航天大学能源与动力工程学院,北京 100191
2.
中国航空工业集团公司沈阳发动机设计研究所,沈阳 110015

计量
- 文章访问数: 1574
- HTML浏览量: 0
- PDF量: 671
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-18
- 刊出日期: 2012-10-28

Effect of serrated cut at trailing edge on performance of lobed mixer in forced mixing exhaust system

1.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China
2.
Shenyang Aeroengine Design and Research Institute, Aviation Industry Corporation of China,Shenyang 110015,China

摘要

摘要: 针对某涡扇发动机波瓣强迫混合排气系统建立了尾缘锯齿修形流场数值计算模型,通过三维数值模拟研究,得到了不同尾缘锯齿修形波瓣强迫混合排气系统流场的演变规律和热混合效率、总压恢复系数的变化规律.结果表明:在强迫混合排气系统出口截面处,热混合效率随修形量的增加而增大,总压恢复系数随修形量的增加而减少.1个三角形(1-SJ)锯齿修形模型的热混合效率最大,达到79.73%;2个梯形修形(2-TX)的综合效果最优,其热混合效率达到77.50%,总压恢复系数比1-SJ高出0.5%.
- 尾缘锯齿修形 /
- 波瓣 /
- 混合排气系统 /
- 热混合效率 /
- 总压恢复系数
Abstract: Based on a lobed mixer in the forced mixing exhaust system of a turbofan engine,geometric models of different serrated cuts at trailing edge were constructed.Through three-dimensional computational fluid dynamic simulations,the effect of serrated cut at trailing edge on the performance of a lobed mixer in a forced mixing exhaust system on the thermal mixing efficiency and total-pressure recovery coefficient were studied.The results show that the thermal mixing efficiency rises while the total-pressure recovery coefficient declines as the cut size of the serrated cut increases.The thermal mixing efficiency of one triangle (1-SJ) serrated modification model was 79.73%.The thermal mixing efficiency of two trapezoidal modifications (2-TX) was 77.50%,and the total-pressure recovery coefficient of 2-TX was 0.5 percentage higher than that of 1-SJ.
- serrated cut at trailing edge /
- lobed mixer /
- mixing exhaust system /
- thermal mixing efficiency /
- total-pressure recovery coefficient

HTML

参考文献(15)

[1]	Tew D E.A computational study of mixing downstream of a lobed mixer with a velocity difference between the co-flow stream .M A,US:MIT,Department of Aeronautics and Astronautics,1992.
[2]	Presz W M,Reynolds G,Mccormick D C.Thrust augment using mixer-ejector-diffuser systems .AIAA Paper 94-0020,1994.
[3]	张靖周,李立国,高潮,等.波瓣喷管红外抑制系统的实验研究[J].航空动力学报,1997,12(2):212-214. ZHANG Jingzhou,LI Liguo,GAO Chao,et al.An experimental study on a lobed nozzle of an infrared suppression system[J].Journal of Aerospace Power,1997,12(2):212-214.(in Chinese)
[4]	Skebe S A,Paterson R W,Barber T J.Experimental investigation of three-dimensional forced mixer lobed flow fields .AIAA Paper 88-3785,1988.
[5]	刘友宏,陈锵,李立国.圆排波瓣圆柱混合管的气动特性实验研究[J].南京航空航天大学学报,2000,32(4):375-380. LIU Youhong,CHEN Qiang,LI Liguo.Experimental investigation of internal aerodynamics of periodically axisymmetry lobed exhaust-ejector mixers[J].Journal of Nanjing University of Aeronautics and Astronautics,2000,32(4):375-380.(in Chinese)
[6]	刘友宏,李立国.有无中心锥圆排波瓣喷管引射器内流场模拟与比较[J].航空动力学报,2002,17(3):280-286. LIU Youhong,LI Liguo.Numerical simulation of flow field in circularly lobed exhaust-ejector mixer with/without a central plug[J].Journal of Aerospace Power,2002,17(3):280-286.(in Chinese)
[7]	LIU Youhong.Experimental and numerical investigation of circularly lobed ejector with bend mixer[J].Heat Transfer- Asian Research,2007,36(7):387-397.
[8]	LIU Youhong.Experimental and numerical research on high pumping performance mechanism of lobed exhauster-ejector[J].International Communication of Heat and Mass Transfer,2007,34(2):197-209.
[9]	刘友宏,谢翌.菊花形混合器混合效率理论计算[J].航空动力学报,2009,24(4):740-745. LIU Youhong,XIE Yi.Analytical solution of mixing efficiency of lobed mixer[J].Journal of Aerospace Power,2009,24(4):740-745.(in Chinese)
[10]	刘友宏,樊超,谢翌,等.波瓣数对波瓣强迫混合排气系统性能影响[J].航空动力学报,2010,25(8):1683-1689. LIU Youhong,FAN Chao,XIE Yi,et al.Effect of lobe numbers on the performance of a lobed mixer in the forced mixing exhaust system[J].Journal of Aerospace Power,2010,25(8):1683-1689.(in Chinese)
[11]	谢翌,刘友宏.波瓣高宽比对波瓣强迫混合排气系统性能影响[J].航空动力学报,2010,25(12):2787-2794. XIE Yi,LIU Youhong.Effect of ratio of height to width of lobe on the performance of a lobed mixer in a forced mixing exhaust system[J].Journal of Aerospace Power,2010,25(12):2787-2794.(in Chinese)
[12]	刘友宏,谢翌,郭楠.尾缘凹扇及综合修形对波瓣混合器性能影响[J].航空动力学报,2010,25(2):243-250. LIU Youhong,XIE Yi,GUO Nan.Effect of elliptical and compositive cut at trailing edge on the performance of a lobed mixer[J].Journal of Aerospace Power,2010,25(2):243-250.(in Chinese)
[13]	Cooper N J,Merati P,HU Hui.Numerical simulation of the vortical structures in a lobed jet mixing flow .AIAA 2005-635,2005.
[14]	Frost T H.Practical bypass mixing systems for fan jet aero-engines[J].Royal Aeronautical Society,1966,17:141-160.
[15]	XIE Yi,LIU Youhong.A modified thermal mixing efficiency and its application to lobed mixer nozzle for aero-engines[J].Heat Transfer Research,2011,42(4):317-335.
