微型定容多次燃油喷射系统高速响应特性仿真

张奇; 杨凯; 徐国强; 杜发荣

微型定容多次燃油喷射系统高速响应特性仿真

1.
北京航空航天大学交通科学与工程学院,北京 100191
2.
北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 航空基金(2011ZB51017)

计量
- 文章访问数: 1684
- HTML浏览量: 117
- PDF量: 665
- 被引次数: 0
出版历程
- 收稿日期: 2012-05-18
- 刊出日期: 2012-10-28

Design and simulation of electronic micro multiple fixed-volume fuel injection system

1.
College of Transportation Science and Technology, Beijing University of Aeronautics and Astronautics,Beijing 100191,China
2.
School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 针对小排量发动机转速范围大、工作循环喷油量小的特点,提出了一种微型定容多次燃油喷射系统结构,建立了系统电、磁、液、机耦合模型,仿真计算了从输入电压到喷射输出的动态响应特性,分析了影响系统高速特性的关键因素.结果表明:该喷射系统响应频率可达到1000Hz,响应时间可以满足小排量发动机最高转速要求,具备工程可实现性.
- 喷油系统 /
- 定容多次 /
- 膜片阀 /
- 变刚度 /
- 响应特性
Abstract: According to small-displacement gasoline engine's wide speed range and small fuel requirement, a new kind of Electronic Micro Multiple Fixed-Volume Fuel Injection System was proposed, and then the electronic-magnetic-mechanic-hydraulic coupled mathematical system model was built,after that the transient response characteristic from input voltage actuation to output fuel injection was analyzed, also the key parameters were deduced. Results show that injection system's high speed response frequency can reach 1000Hz which meets the highest engine speed requirements of small displacement engine, and this new injection system work principle is correct in theory.
- electronic fuel injection(EFI) /
- multiple fixed-volume /
- diaphragm check valve /
- variable stiffness spring /
- response characteristic

HTML

参考文献(15)

[1]	杨笑风,曾科,蒋德明.实现小型二冲程汽油机分层扫气的膜片式喷射化油器[J].内燃机学报,1999,17(2):161-165. YANG Xiaofeng,ZENG Ke,JIANG Deming,et al.Investigation on diaphragm injection carburetor in a two stroke spark ignition engine with stratified scavenging[J].Transactions of CSICE,1999,17(2):161-165.(in Chinese)
[2]	彭美春,彭汉锐,谢兴文,等.摩托车发动机电控系统匹配技术与性能研究[J].小型内燃机与摩托车,2008,37(3):4-7. PENG Meichun,PENG Hanrui, XIE Xingwen,et al.Study of Mmatching technology of electronic control systemand performance for motorcycle engine[J].Small Internal Combustion Engine and Motorcycle,2008,37(3):4-7.(in Chinese)
[3]	Hayakawa K,Yamazaki S,Takenaka S.125cc small engine fuel injection system with low emissions solutions .SAE,2004-32-0094,2004.
[4]	万冬,白富强,顾维东,等.摩托车电喷系统进气量计量方法的研究[J].小型内燃机与摩托车,2007,36(1):12-15. WAN Dong, BAI Fuqiang, GU Weidong,et al.Investigation of air intake characteristics of the fuel injection systemof four-stroke motorcycle engine[J].Small Internal Combustion Engine and Motorcycle,2007,36(1):12-15.(in Chinese)
[5]	Brogan M S,Swallow D,Brisley R J.A new approach to meeting future european emission standards with the orbital direct injection gasoline engine .SAE,2000-01-2913,2000.
[6]	倪振华.振动力学[M].西安:西安交通大学出版社,1990.
[7]	林海.压缩机自动阀[M].西安:西安交通大学出版社,1991.
[8]	吴丹青.压缩机簧片阀的数学模拟与设计[M].北京:机械工业出版社,1993.
[9]	黄克智.板壳理论[M].北京:清华大学出版社,1987.
[10]	罗志昌.流体网络理论[M].北京:机械工业出版社,1988.
[11]	Munson B R.Fundamentals of fluid mechanics[M].New York:Wiley,1990.
[12]	Allen J,Ravenhill P.Flow and spray characteristics of a high frequency low cost fuel injection system for small engines .SAE.ICLASS-2006,2006.
[13]	Holly Moore.Matlab实用教程[M].2版.高会生,刘童娜,李聪聪,译.北京:电子工业出版社,2010.
[14]	李颖.Simulink动态系统建模与仿真[M].2版.西安:西安电子科技大学出版社,2009.
[15]	张威.Stateflow 逻辑系统建模[M].西安:西安电子科技大学出版社,2007.
