跨声串列静子叶片匹配特性分析及其优化

陶源; 于贤君; 刘宝杰

跨声串列静子叶片匹配特性分析及其优化

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室,北京 100191

基金项目: 国家自然科学基金(51006007)

计量
- 文章访问数: 1826
- HTML浏览量: 85
- PDF量: 524
- 被引次数: 0
出版历程
- 收稿日期: 2011-12-16
- 刊出日期: 2012-10-28

Analysis of matching characteristic of transonic tandem stator airfoil and its optimization

National Key Laboratory of Science and Technology on Aero-Engine Aero-Thermodynamics, School of Jet Propulsion,Beijing University of Aeronautics and Astronautics, Beijing 100191,China

摘要

摘要: 以数值模拟的方法对串列叶片的匹配特性展开研究,分析其前后排叶片的工作特点,并在此基础上利用可控扩散叶型(CDA叶型)替换常规叶型,有效提高了叶栅性能.研究结果表明:随来流攻角的变化,前排叶片的工作状态变化很大,并且串列叶栅的可用攻角范围几乎只由前排叶片决定;而后排叶片的攻角由前排叶片落后角确定,同时前排叶片的尾迹在后排主流区中的堆积能够削弱后排叶片中气流扩压的过程,前排分离严重的情况下,后排叶片工作状态反而有所改善.在分析串列叶片工作特点的基础上,以CDA叶型分别替换常规叶型能够取得良好的效果.
- 燃气轮机 /
- 压气机 /
- 串列叶栅 /
- 匹配特性 /
- 数值模拟
Abstract: Matching characteristic of tandem airfoil was researched by using numerical simulation.The forward and aft blade working characteristics were analyzed,and then,an attempt to optimize the blades with the controlled diffusion airfoil was made,by doing which a higher cascade performance was achieved.The result indicates that:the working status of forward blade changes obviously with the incidence,and the incidence range of whole stage almost depends on forward blade alone;aft blade incidence depends on the working status of forward blade deviation.Flow diffusion and turning in aft blade is weakened because of forward blade trailing edge's piling up,thus the working status of aft blade is improved on condition that the forward blade has large flow separations.Based on the analysis of tandem airfoil working characteristics,routine blade was replaced with controlled diffusion airfoil and a good result was achieved.
- gas turbine /
- compressor /
- tandem cascade /
- matching characteristic /
- numerical simulation
