TAPS/MLDI低污染燃烧室油雾特性
Fuel spray characteristic of TAPS/MLDI low emission combustor
-
摘要: 采用粒子图像测速仪对一个带多点贫油直接喷射双环预混旋流燃烧室头部的低污染燃烧室油雾场进行了测量,试验研究不同燃油喷射方式时燃油流量变化对油雾特性的影响.结果表明:在试验工况下,粒径40μm左右的油珠数目最多,大于或小于此粒径的油珠数目都较少;单开值班级喷嘴时,随着燃油流量增加,燃油雾化变差;单开主燃级喷嘴时,增加燃油流量使燃油雾化稍有改善.同时打开值班级和主燃级喷嘴,保持油气比不变时,值班级和主燃级燃油量分配比例改变对燃油雾化特性的影响不大.
-
关键词:
- 多点燃油直接喷射 /
- 双环预混旋流低污染燃烧室 /
- 粒子图像测速仪 /
- 油雾特性 /
- 燃油雾化
Abstract: A particle image velocimetry (PIV) was employed to measure fuel spray fields of the TAPS/MLDI (twin annular premixing swirler/multipoint lean direct injection) low emission combustor under different inlet conditions.The influences of different fuel flow rates with various fuel injection fashions on fuel spray characteristic of the low emission combustor were experimentally investigated.Results show that:the number of droplet with the size of 40μm reaches maximum under experimental conditions.The number of droplet,which is larger or smaller than the droplet size of 40μm,harply decreases.When the pilot fuel atomizer is operated,the fuel atomization is worsened with the increase of the fuel flow rate.When the primary fuel injector is operated,the fuel atomization is slightly improved with the increase of the fuel flow rate.When the pilot and primary atomizer are operated at the same time,the inlet fuel air ratio is the same,and the effect of the decrease of primary fuel flow rate and increase of pilot fuel flow rate on the fuel atomization is weak. -
[1] 赵坚行.民用发动机污染排放及低污染燃烧技术发展趋势[J].航空动力学报,2008,23(6):986-996. ZHAO Jianxing.Pollutant emission and development of low-emission combustion technology for civil aero engine[J].Journal of Aerospace Power,2008,23(6):986-996.(in Chinese) [2] Wulff A,Hourmouziadis J.Technology review of aeroengine pollutant emissions[J].Aerospace Science and Technology,1997,1(8):557-572. [3] Gleason C C,Bahr D W.Experimental clean combustor program (ECCP) phase III final report.NASA CR-135384,1979. [4] Maier G,Wiitig S.Fuel preparation and emission characterististics of a pressure loaded LPP combustor [R].AIAA-99-3774,1999. [5] Novlck A S,Troth D L.Low NOx heavy fuel combustor concept program [R].NASA CR-165481,1981. [6] Stouffer S D,Ballal D R.Development and combustion performance of a high-pressure WSR and TAPS combustor [R].AIAA-2005-1416,2005. [7] Mongia H C.TAPS-A 4th generation propulsion combustor technology for low emissions [R].AIAA-2003-2657,2003. [8] Marek C J,Smith T D.Low emission hydrogen combustors for gas turbines using lean direct injection [R].AIAA-2005-3776,2005. [9] Fu Y,Jeng S M.Characteristics of the swirling flow in a multipoint LDI combustor [R].AIAA-2007-846,2007. [10] Bulzan D L.Velocity and drop size measurements in a confined,swirler-stabilized,combusting spray [R].AIAA-96-3164,1996. [11] 柳朝晖,郑楚光,王汉封.不同旋流数下湍流气粒两相流动特性的PDPA实验研究[J].化工学报,2001,52(6):491-494. LIU Zhaohui,ZHENG Chuguang,WANG Hanfeng.Experimental study on turbulent dilute gas-particle flows of different swirling intensuty[J].Journal of Chemical Industry and Engineering,2001,52(6):491-494.(in Chinese) [12] 邢小军,徐行,郭志辉,等.模型燃烧室冷态喷雾场的实验研究[J].推进技术,2000,21(5):61-65. XING Xiaojun,XU Hang,GUO Zhihui,et al.Experimental study on spray field in combustor by phase dopplor analyzer[J].Journal of Propulsion Technology,2000,21(5):61-65.(in Chinese) [13] 盛森芝,徐月亭,袁辉靖.近十年来流动测量技术的新发展[J].力学与实践,2002,24(5):1-14. SHENG Senzhi,XU Yueting,YUAN Huijing.New development in the technology of flow measurement over the last decade[J].Mechanics and Engineering,2002,24(5):1-14.(in Chinese) [14] 颜应文,李红红,赵坚行,等.双环预混旋流低污染燃烧室数值研究[J].航空动力学报,2009,24(9):1923-1929. YAN Yingwen,LI Honghong,ZHAO Jianxing,et al.Numerical study of low emissions for twin annular premixing swirler combustor[J].Journal of Aerospace Power,2009,24(9):1923-1929.(in Chinese) [15] Olinger D S,Sallam K A,Lin K C,et al.Effects of GLR on the spray in the near injector region of aerated liquid jets in crossflow [R].AIAA 2009-1373,2009.
