凹槽孔槽深和动量比对气膜冷却特性的影响

王振伟; 朱惠人; 张宗卫; 孟庆昆

凹槽孔槽深和动量比对气膜冷却特性的影响

西北工业大学动力与能源学院, 西安 710072

基金项目: 国家重点基础研究发展计划(2007CB707701)

计量
- 文章访问数: 1542
- HTML浏览量: 2
- PDF量: 493
- 被引次数: 0
出版历程
- 收稿日期: 2011-10-31
- 刊出日期: 2012-11-28

Effect of trench hole depth and momentum flux ratio on film cooling characteristics

School of Engine and Energy, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 采用瞬态液晶全表面测量技术测量了凹槽孔的气膜冷却特性,研究了动量比和槽深对冷却效率的影响,并和圆柱形孔的测量结果实施了比较.结果表明:冷气在凹槽内横向传播,凹槽抑制了冷气射流分离,凹槽孔比圆柱形孔提供更多的二维气膜.槽深孔径比为0.75是最佳的.随着动量比的增加,冷却效率值逐渐趋于稳定,冷却效率仅有轻微增加.
- 凹槽孔 /
- 气膜冷却 /
- 热色液晶 /
- 全表面测量 /
- 冷却效率
Abstract: Film cooling characteristics of trench hole were measured using a transient liquid crystal full-surface measurement technique.The influence of momentum flux ratio (I=0.5,1,2,4) and trench depth (s=0.5 D,0.75D,D;D stands for film hole diameter) were studied comparison between trench hole and cylindrical hole was conducted.The results show that the trench suppresses coolant jet separation,and the trench hole provides greater lateral film coverage compared with the cylindrical hole.An optimum trench depth is s=0.75 D.With a further increase in momentum flux ratio,the cooling effectiveness levels start to plateau,so increased coolant would not be warranted because only a slight increase in film cooling effectiveness would occur.
- trench hole /
- film cooling /
- liquid crystal /
- full-surface measurement /
- cooling effectiveness

HTML

参考文献(15)

[1]	Lu Y P, Dhungel A,Ekkad S V,et al.Effect of trench width and depth on film cooling from cylindrical holes embedded in trenches [R].ASME Paper GT-2007-27388,2007.
[2]	Dorrington J S,Bogard D G,Bunker R S.Film effectiveness performance for coolant holes embedded in various shallow trench and crater depressions [R].ASME Paper GT-2007-27992,2007.
[3]	Waye S K,Bogard D G.High resolution film cooling effectiveness measurements of axial holes embedded in a transverse trench with various trench configurations [R].ASME Paper GT-2006-90226,2006.
[4]	Bunker R S.Film cooling effectiveness due to discrete holes within a transverse surface slot [R].ASME Paper GT-2002-30178,2002.
[5]	Lu Y P,Nasir H,Ekkad S V.Film cooling from a row of holes embedded in transverse slots [R].ASME Paper GT-2005-68598,2005.
[6]	Lu Y P,Srinath V.Predictions of film cooling from cylindrical holes embedded in trenches [R].AIAA-2006-3401,2006.
[7]	Lu Y P,Dhungel A,Ekkad S V,et al.Film cooling measurements for cratered cylindrical inclined holes [R].ASME Paper GT-2007-27386,2007.
[8]	Wang T,Chintalapati S,Bunker R S,et al.Jet mixing in a slot[J].Experimental Thermal and Fluid Science,2000,22(1):1-17.
[9]	Liu C L,Zhu H R,Bai J T,et al.Film cooling performance of converging-slot holes with different exit-entry area ratios [R].ASME Paper GT-2009-59002,2009.
[10]	Drost U,Bolcs A,Hoffs A,Utilization of the transient liquid crystal technique for film cooling effectiveness and heat transfer investigations on a flat plane and a turbine airfoil [R].ASME Paper 97-GT-026,1997.
[11]	张宗卫,朱惠人,杜小琴,等.带60°肋和出流孔的矩形通道端壁换热特性研究[J].西安交通大学学报,2010,44(5):116-119. ZHANG Zongwei,ZHU Huiren,DU Xiaoqin,et al.Investigations of endwall heat transfer in the rectangular passage with 60-degree ribs and suction holes[J].Journal of Xi'an Jiaotong University,2010,44(5):116-119.(in Chinese)
[12]	张宗卫,朱惠人,王振伟,等.出流孔位置对带肋矩形通道换热特性的影响[J].推进技术,2011,32(4):581-585. ZHANG Zongwei,ZHU Huiren,WANG Zhenwei,et al.Influence of bleed hole location on heat transfer in rectangular channels with ribs[J].Journal of Propulsion Technology,2011,32(4):581-585.(in Chinese)
[13]	刘存良,朱惠人,白江涛,等.基于瞬态液晶全表面测量技术的圆柱形孔气膜冷却特性研究[J].航空动力学报,2009,24(9):1959-1965. LIU Cunliang,ZHU Huiren,BAI Jiangtao,et al.Experimental research on film cooling characteristics of cylindrical hole with transient liquid crystal measurement technique[J].Journal of Aerospace Power,2009,24(9):1959-1965.(in Chinese)
[14]	郭涛,朱惠人,许都纯,等.热色液晶瞬态测量全表面换热系数的技术研究[J].测控技术,2006,25(9):789-795. GUO Tao,ZHU Huiren,XU Duchun,et al.Research on transient measurement of heat transfer coefficient distribution with liquid crystal technique[J].Measurement and Control Technology,2006,25(9):789-795.(in Chinese)
[15]	梁卫颖,朱惠人,郭涛,等.利用液晶瞬态技术测量离散缝的气膜加热效率及换热系数[J].西北工业大学学报,2006,24(4):501-504. LIANG Weiying,ZHU Huiren,GUO Tao,et al.New transient state measurements of film heated effectiveness and heat transfer coefficients of the discrete slots with liquid crystal technique[J].Journal of Northwestern Polytechnical University,2006,24(4):501-504.(in Chinese)
