叶片安装角对叶盘结构受迫响应特性的影响

兰海强; 臧朝平

叶片安装角对叶盘结构受迫响应特性的影响

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 江苏省高校优势学科建设工程(PADA); 教育部博士点基金(20093218110008); 国家自然科学基金(51175244)

计量
- 文章访问数: 1725
- HTML浏览量: 165
- PDF量: 628
- 被引次数: 0
出版历程
- 收稿日期: 2011-11-08
- 刊出日期: 2012-11-28

Effect of blade stagger angle on forced response of bladed disk assemblies

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 利用简化的叶盘结构有限元模型和基于极值原理的改进Monte Carlo模拟技术,详细分析了叶片安装角失谐对叶盘结构受迫响应特性的影响.分别对6种不同安装角误差的叶盘结构的受迫响应进行了数值计算,得到了各自对应的响应放大因子概率密度曲线,通过曲线比较,分析了叶片安装角误差对叶盘结构受迫响应特性的影响规律.研究表明:安装角误差虽对叶盘结构的固有频率影响较小,但对叶片受迫响应影响是很大的,并且受迫响应幅值放大因子随安装角失谐程度增加而增加.
- 安装角 /
- 叶盘结构 /
- 失谐 /
- Monte Carlo模拟 /
- 受迫响应
Abstract: Using simplified finite element model and the accelerated Monte Carlo simulation based on extremum principle,the forced response characteristics of bladed disks with stagger angle mistuning were investigated in detail.Six different variations of stagger angle error were simulated and corresponding probability density functions of response magnification factors were calculated separately.By comparing different curves,effect regularity of bladed stagger angle on the forced response of bladed disk assemblies was explored.Results indicate that stagger angle mistuning has small effect natural frequencies,but has a great effect on the blade response.The forced response would increase when stagger angle mistuning strength increases.
- stagger angle /
- bladed disk /
- mistuning /
- Monte Carlo simulation /
- forced response

HTML

参考文献(17)

[1]	王建军,李其汉,朱梓根.失谐叶片-轮盘结构系统振动局部化问题的研究进展[J].力学进展,2000,30(4):517-528. WANG Jianjun,LI Qihan,ZHU Zigen.Vibratory localization of mistuned bladed disk assemblies:a review[J].Advances in Mechanics,2000,30(4):517-528.(in Chinese)
[2]	Castanier M P,Pierre C.Modeling and analysis of mistuned bladed disk vibration:status and emerging directions[J].Journal of Propulsion and Power,2006,22(2):384-396.(in Chinese)
[3]	臧朝平,兰海强.失谐叶盘结构振动问题研究新进展[J].航空工程进展,2011,2(2):133-142. ZANG Chaoping,LAN Haiqiang.Advances in research vibration problem of mistuned blisk assemblies[J].Advances in Aeronautical Science and Engineering,2011,2(2):133-142.(in Chinese)
[4]	王红建.复杂耦合失谐叶盘系统振动局部化问题研究.西安:西北工业大学,2006. WANG Hongjian.Investigation of the vibration localization problem of the mistuned bladed disk with complicated coupling.Xi'an:Northwestern Polytechnical University,2006.(in Chinese)
[5]	Yang M T,Griffin J H.A reduced-order model of mistuning using a subset of nominal system modes[J].Journal of Engineering for Gas Turbines and Power,2001,123(4):893-900.
[6]	Feiner D M,Griffin J H.A fundamental model of mistuning for a single family of modes[J].Journal of Turbomachinery,2002,124(4):597-605.
[7]	袁惠群,杨少明,吴震宇,等.基于蚁群算法和模态局部化参数的失谐叶盘减振研究[J].东北大学学报:自然科学版,2010,31(11):1611-1614. YUAN Huiqun,YANG Shaoming,WU Zhenyu,et al.Vibration reduction of mistuned blade-disc by ant colony algorithm and modal localization parameter[J].Journal of Northeastern University:Natural Science,2010,31(11):1611-1614.(in Chinese)
[8]	Petrov E P.Reduction of forced response levels for bladed discs by mistuning:overview of the phenomenon.ASME Paper GT-2010-23299,2010.
[9]	Lim S,Castanier M P,Pierre C.Intentional mistuning design space reduction based on vibration energy flow in bladed disks.ASME Paper GT-2004-53873,2004.
[10]	Rzadkowski R.The general model of free vibrations of mistuned bladed discs:PartⅠ theory[J].Journal of Sound and Vibration,1994,173(3):377-393.
[11]	Feiner D M,Griffin J H.Mistuning identification of bladed disks using a fundamental mistuning model:part Ⅰ theory[J].Journal of Turbomachinery,2004,126(1):150-158.
[12]	Sladojevic I,Petrov E P,Imregun M,et al.Forced response variation of aerodynamically and structurally mistuned turbo-machinery rotors [R].ASME Paper GT-2006-90948,2006.
[13]	Chiu Y J,Huang S C.The influence of a mistuned blade's staggle angle on the vibration and stability of a shaft-disk-blade assembly[J].Shock and Vibration,2008,15(1):3-17.
[14]	王艾伦,孙勃海.随机失谐的成组叶片-轮盘固有振动局部化研究[J].中国机械工程,2011,22(7):771-775. WANG Ailun,SUN Bohai.Analysis of national vibration localization of random mistuned bladed disk with grouped blades[J].China Mechnical Engineering,2011,22(7):771-775.(in Chinese)
[15]	Bladh R,Pierre C,Castanier M P,et al.Dynamic response predictions for a mistuned industrial turbomachinery rotor using reduced-order modeling[J].Journal of Engineering for Gas Turbines and Power,2002,124(2):311-324.
[16]	Whitehead D S.Effect of mistuning on the vibration of turbo-machine blades induced by wakes[J].Journal of Mechanical Engineering Science,1966,8(1):15-21.
[17]	Nikolic M,Petrov E P,Ewins D J.Robust strategies for forced response reduction of bladed disks based on large mistuning concept [R].ASME Paper GT-2007-27183,2007.
