某双级高压涡轮全三维计算

曾军; 王彬; 卿雄杰

某双级高压涡轮全三维计算

中国航空工业集团公司中国燃气涡轮研究院涡轮技术室, 成都 610500

计量
- 文章访问数: 1556
- HTML浏览量: 85
- PDF量: 477
- 被引次数: 0
出版历程
- 收稿日期: 2012-01-12
- 刊出日期: 2012-11-28

Three-dimensional analysis of two-stage high pressure turbine

Turbine Technique Department, China Gas Turbine Establishment, Aviation Industry Corporation of China, Chengdu 610500, China

摘要

摘要: 采用自主研发的全三维黏性涡轮设计体系对某双级高压涡轮进行了反设计,并利用商业软件CFX12.0在采用二方程湍流模型SST(shear stress transportation)模型、考虑冷气和转捩等条件下对反设计得到的叶型进行了全三维计算分析,采用源项模拟技术处理气膜冷却流动.计算结果与试验数据进行了对比,结果表明计算得到的效率与试验值吻合,中等负荷高压涡轮气冷叶型采用后部加载设计技术可有效控制流动损失.
- 高压涡轮 /
- 三维计算 /
- 转捩 /
- 气冷叶型 /
- 后部加载
Abstract: The blade profiles of a two-stage high pressure turbine(HPT) were redesigned using 3-D viscous turbine design system developed independently,and the 3-D analysis with cooling air and transition being considered was conducted by commercial software CFX 12.0.A two-equation turbulence model shear stress transportation (SST) was used.The film cooling flow was dealt with using source term modeling techniques.The comparison of calculation results and the test data shows that the predicted efficiency agrees well with the test data,and aft-loaded technique can reduce loss effectively for the cooling blade profile of normal level HPT.
- high pressure turbine /
- 3-D calculation /
- transition /
- cooling blade profile /
- aft-loaded

HTML

参考文献(12)

[1]	Timko L P. Energy efficient engine high pressure turbine component test performance report [R].NASA, CR-168289,1990.
[2]	李剑白,卿雄杰,周山,等.涡轮叶片设计软件BladeDesign[J].燃气涡轮试验与研究,2011,24(3):11-15. LI Jianbai,QING Xiongjie,ZHOU Shan,et al.Turbine blade aerodynamic design software:Blade Design[J]. Journal of Gas Turbine Experiment and Research,2011,24(3):11-15.(in Chinese)
[3]	ANSYS Europe Limited.ANSYS TurboGrid12.0 help document[M].[S.l.]:ANSYS Europe Limited,2009.
[4]	ANSYS Europe Limited.ANSYS ICEM CFD12.0 help document[M].[S.l.]:ANSYS Europe Limited,2009.
[5]	ANSYS Europe Limited.ANSYS CFX12.0 help document[M].[S.l.]:ANSYS Europe Limited,2009.
[6]	曾军,王彬,康勇.气膜冷却涡轮导向叶片流场数值模拟[J].燃气涡轮试验与研究,2006,19(4):16-19,34-34. ZENG Jun,WANG Bin,KANG Yong.Numerical simulation of flow field in a turbine stator with film cooling[J].Journal of Gas Turbine Experiment and Research,2006,19(4):16-19,34.(in Chinese)
[7]	张剑,曾军,程信华,等.跨音速HTA涡轮级全三维流场计算分析 [C]//中国航空学会动力分会第十二届叶轮机学术会议论文集.成都:中国航空学会,2003:120-126.
[8]	张剑,曾军,程信华,等.跨音速HTA涡轮导向器全三维流场计算分析[J].燃气涡轮试验与研究,2003,16(4):21-24. ZHANG Jian,ZENG Jun,CHENG Xinhua,et al.Three-dimensional flow field analysis of the stator in transonic HTA turbine[J].Journal of Gas Turbine Experiment And Research,2003,16(4):21-24.(in Chinese)
[9]	Menter F R.Two-equation eddy-viscosity turbulence models for engineering applications[J].AIAA Journal,1994,32(8):269-289.
[10]	Vieser W,Esch T,Menter F R,Heat transfer predictions using advanced two-equation turbulence models.CFX-VAL10/0602,2002.
[11]	Menter F R,Kuntz M,Langtry R.Ten years of industrial experience with SST turbulence model [C]//Turbulence,heat and mass transfer 4.:Begell House Inc.,2003:625-632.
[12]	Menter F R,Langtry R B,Likki S R,et al.A correlation based transition model using local variables:Part 1 model formulation [R].ASME Paper 2004-GT-53452,2004.
