可调静子旋转凸台位置对端区流动的影响

王靖宇; 杨荣菲; 王志强; 胡骏

可调静子旋转凸台位置对端区流动的影响

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 南京航空航天大学引进人才科研启动经费(1002-56YAH11025)

计量
- 文章访问数: 1336
- HTML浏览量: 5
- PDF量: 598
- 被引次数: 0
出版历程
- 收稿日期: 2011-11-12
- 刊出日期: 2012-11-28

Effect of location of penny platform in variable stator vane on endwall flow

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 对包含凸台的可调静子模型进行简化,研究了不同凸台位置对端区流动的影响.通过实验测量与数值模拟对比可以发现:可调静子端区流动损失主要是由叶片气动负荷引起的泄漏及气流绕过凸台造成的掺混2个部分组成;通过合理优化设计,将凸台置于气动负荷高的叶片前缘并覆盖尽可能多的前缘间隙,能够有效降低损失,改善气动性能.
- 可调静子 /
- 旋转凸台 /
- 间隙 /
- 端区损失 /
- 泄漏流 /
- 压气机
Abstract: Through experiment and numerical simulation of simplified variable stator vane(VSV) model,the effect of different penny platform locations on the flow in endwall region was studied.The results show that there are two factors affect the loss of endwall flow:the leakage cause by aerodynamic loading and the mixing of flow around the penny platform.Optimization of the location and size of the penny platform which aims at covering the front end of the aerofoil can decrease the leakage and flow loss,thus aerodynamic performance would be improved.
- variable stator vane /
- penny platform /
- gap /
- flow loss in endwall region /
- leakage flow /
- compressor

HTML

参考文献(12)

[1]	刘长福,邓明.航空发动机结构分析[M].西安:西北工业大学出版,2006.
[2]	胡骏,吴铁鹰,曹人靖.航空叶片机原理[M].北京:国防工业出版社,2006.
[3]	Ronald D F.Fundamentals of jet propulsion with applications[M].Cambridge:Cambridge University Press,2005.
[4]	Klinger H,Lazik W,Thomas Wunderlich.The engine 3E core engine [R].ASME Paper GT-2008-50679,2008.
[5]	Lee C,Song J,Lee S,et al.Effect of a gap between inner casing and stator blade on axial compressor performance [R].ASME Paper GT-2010-22439,2010.
[6]	Ribi B,Meyer M P.Influence of a gap between casing and variable stator blade on axial compressor performance [R].ASME Paper GT-2008-5.301,2008.
[7]	Rice E C,Ress R A,Jeffrey Lister Hansen.Variable vane with winglet.US:No.6283705.2001-09-04.
[8]	隋岩峰,邴连喜,施磊,等.某发动机高压压气机进口可调静子叶片角度控制方法[J].航空动力学报,2010,25(11):2589-2593. SUI Yanfeng,BING Lianxi,SHI Lei,et al.Control method of compressor stator vane angle for an aeroengine[J].Journal of Aerospace Power,2010,25(11):2589-2593.(in Chinese)
[9]	JIA Xicheng,WANG Zhengming,CAI Ruixian.Numerical investigation of different tip gap shape effects on aerodynamic performance of an axial-flow compressor stator [R].ASME Paper 2001-GT-0337,2001.
[10]	程朝青.叶尖泄漏流损失模型探索 [D].北京:北京航空航天大学,2010. CHENG Chaoqing.Numerical investigation of the blockage model of the tip clearance flow [D].Beijing:Beijing University of Aeronautics and Astronautics,2010.(in Chinese)
[11]	杨荣菲,王靖宇,葛宁.压气机可调静子凸台几何布局的研究 [R].湖南株洲:第十三届推进系统气动热力学术交流会,2011.
[12]	王志强.高压压气机低速模拟方法研究 [D].南京:南京航空航天大学,2010. WANG Zhiqiang.Research on the method of low-speed model testing for high pressure compressor [D].Nanjing:Nanjing University of Aeronautics and Astronautics,2010.(in Chinese)
