干摩擦对称黏滑响应的级数解及黏滑边界特性

钱大帅; 刘占生; 王乐; 解亮

干摩擦对称黏滑响应的级数解及黏滑边界特性

哈尔滨工业大学能源科学与工程学院,哈尔滨 150001

计量
- 文章访问数: 1620
- HTML浏览量: 110
- PDF量: 1080
- 被引次数: 0
出版历程
- 收稿日期: 2012-01-12
- 刊出日期: 2013-01-28

Series solution of symmetric dry frictional stick-slip motion and stick-slip boundary characteristics

School of Energy Science and Engineering, Harbin Institute of Technology,Harbin 150001,China

摘要

摘要: 针对航空发动机中的摩擦振动问题,给出了对称黏滑运动摩擦力的分段表达式.利用谐波平衡方法推导了具有偶数次黏着的黏滑运动的级数形式解析解,并基于该解析解给出了参数平面内的黏滑边界线方程.黏滑运动响应仅包含奇次谐波成分,在奇次分数倍频处存在超谐次共振.当频率比小于0.4时,黏滑边界线呈现凸凹交替特征,局部极小值位于各阶超谐次共振频率处.黏性阻尼增大能够缩小无黏着运动的参数范围,但在各阶超谐共振频率附近,黏性阻尼增大会扩大无黏着运动的参数区域.
- 干摩擦 /
- 对称黏滑运动 /
- 级数解 /
- 黏滑边界 /
- 超谐次共振
Abstract: To study frictional vibration problems in areo-engine,piecewise expression of frictional force in symmetric stick-slip motion was presented.Analytical series solution of symmetric stick-slip motion with even stops was derived by using harmonic balance method.Stick-slip boundary function in parameter plane was derived based on the series solution.Stick-slip response contained only odd harmonic components and super-harmonic resonances existed at odd fractional frequency ratios.When frequency ratio was less than 0.4,the stick-slip boundary curve had the feature of concave-convex alternation and its local minimums located at the super-harmonic resonant frequencies.Increase in viscous damping reduced the non-sticking parameter range at most frequency ratio ranges except near super-harmonic resonant frequencies,where larger viscous damping led to larger non-sticking parameter range.
- dry friction /
- symmetric stick-slip motion /
- series solution /
- stick-slip boundary /
- super-harmonic subresonant

HTML

参考文献(17)

[1]	Lim Y F,Chen K.Dynamics of dry friction:a numerical investigation[J].Physical Reviews,1998,58(5):5637-5642.
[2]	Batako A D L,Lalor M J,Piiroinen P T.Numerical bifurcation analysis of a friction-driven vibro-impact system[J].Journal of Sound and Vibration,2007,308(2):392-404.
[3]	Liang J W,Feeny B F.Wavelet analysis of stick-slip in an oscillator with dry friction //ASME Design Engineering Technical Conferences.Boston:ASME,1995:1061-1069.
[4]	Luo A C J,Gegg B C.Periodic motions in a periodically forced oscillator moving on an oscillating belt with dry friction[J].Journal of Computational and Nonlinear Dynamics,2006:206(1):212-220.
[5]	Luo A C J,Gegg B C.Stick and non-stick periodic motions in periodically forced oscillators with dry friction[J].Journal of Sound and Vibration,2006,291(1):132-168.
[6]	Hong H K,Liu C S.Non-sticking oscillation formulae for coulomb friction under harmonic loading[J].Journal of Sound and Vibration,2001,244(5):883-898.
[7]	Hong H K,Liu C S.Coulomb friction oscillator:modeling and responses to harmonic loads and base excitations[J].Journal of Sound and Vibration,2000,229(5):1171-1192.
[8]	郭树起,杨绍普,郭京波.干摩擦阻尼系统的非黏结受迫振动分析[J].振动工程学报,2005,18(3):276-281. GUO Shuqi,YANG Shaopu,GUO Jingbo.Analysis of non-sticking forced vibrations in a dry friction damper system[J].Journal of Vibration Engineering,2005,18(3):276-281.(in Chinese)
[9]	杨绍普,郭树起.一类摩擦振子的纯滑动运动分析[J].振动与冲击,2009,28(10):43-48. YANG Shaopu,GUO Shuqi.Analysis of pure slip motions of a class of friction oscillator[J].Journal of Vibration and Shock,2009,28(10):43-48.(in Chinese)
[10]	Liu C S,Chang W T.Frictional behavior of a belt-driven and periodically excited oscillator[J].Journal of Sound and Vibration,2002,258(2):247-268.
[11]	Andreaus U,Casini P.Dynamics of friction oscillators excited by a moving base and/or driving force[J].Journal of Sound and Vibration,2001,245(4):685-699.
[12]	Duan C.Dynamic analysis of dry friction path in a torsional system .Columbus:Ohio State University,2004.
[13]	Duan C,Singh R.Dynamics of a 3-D of torsional system with a dry friction controlled path[J].Journal of Sound and Vibration,2006,289(3):657-688.
[14]	丁旺才,张有强,张庆爽.含干摩擦振动系统的非线性动力学分析[J].工程力学,2008,25(10):212-217. DING Wangcai,ZHANG Youqiang,ZHANG Qingshuang.Nonlinear dynamic analysis of vibrate system with dry friction[J].Engineering Mechanics,2008,25(10):212-217.(in Chinese)
[15]	张有强,丁旺才.干摩擦对碰撞振动系统周期运动的影响分析[J].振动与冲击,2009,28(6):111-116. ZHANG Youqiang,DING Wangcai.Study on effect of dry friction on periodic motion of impact vibration system[J].Journal of Vibration and Shock,2009,28(6):111-116.(in Chinese)
[16]	Den H J P.Forced vibrations with combined coulomb and viscous friction[J].Journal of Applied Mechanics,1931,53(9):107-115.
[17]	郭树起,杨绍普.三分之一固有频率谐激励下干摩擦振子的双Stop黏滑运动[J].振动与冲击,2009,28(4):81-85. GUO Shuqi,YANG Shaopu.2-Stop stick-slip motion of a dry friction oscillator under a harmonic excitation of one-third natural frequency[J].Journal of Vibration and Shock,2009,28(4):81-85.(in Chinese)
