基于小波包分析和支持向量机的转静碰摩部位识别

于明月; 陈果; 李成刚; 冯国全; 王德友

基于小波包分析和支持向量机的转静碰摩部位识别

1.
南京航空航天大学民航学院,南京 210016
2.
中国航空工业集团公司沈阳发动机设计研究所,沈阳 110015

基金项目: 国家安全重大基础研究项目(613139); 国家自然科学基金(61179057)

计量
- 文章访问数: 1714
- HTML浏览量: 192
- PDF量: 1219
- 被引次数: 0
出版历程
- 收稿日期: 2012-01-16
- 刊出日期: 2013-01-28

Rotor-stator rubbing positions identification of aero-engine based on wavelet packet analysis and support vector machine

1.
College of Civil Aviation College, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China
2.
Shenyang Engine Design and Research Institute, Aviation Industry Corporation of China,Shenyang 110015,China

摘要

摘要: 利用航空发动机转子实验器模拟不同径向碰摩部位下的碰摩故障,提出基于小波包分析的支持向量机转静碰摩部位识别方法.首先将从机匣测得的加速度信号进行小波包分解,提取其归一化能量特征,接下来将得到的归一化能量特征输入至支持向量机中,用以识别不同的碰摩部位.利用航空发动机转子实验器模拟大量不同碰摩程度和不同碰摩部位的样本,利用支持向量机进行训练和测试.结果表明小波包能量特征与支持向量机相结合可以有效地判别转静碰摩部位,且仅需1个传感器即可达到98%的识别率.
- 小波包 /
- 加速度信号 /
- 能量特征 /
- 支持向量机 /
- 碰摩位置识别
Abstract: Rubbing faults of different radial rubbing positions by using the rotor experiment rig of aero-engine are simulated.An identification method based on wavelet packet analysis and support vector machine(SVM) was proposed.Firstly,the acceleration signals on the casing were collected.Secondly,the signals were decomposed by wavelet packet analysis,and the normalized energy features were extracted.Finally,the normalized energy characteristics were input into support vector machine to identify the different rubbing positions.By using an aero-engine rotor experiment rig,a large number of samples including different rubbing positions and different rubbing degrees were simulated, and the support vector machine was trained and tested by these samples.The results show that the new method combining the wavelet packet energy features and support vector machine can effectively identify the rotor-stator rubbing positions of aero-engine;in addition,only one sensor is required to reach the recognition rate of 98%.
- wavelet packet /
- acceleration signals /
- energy feature /
- support vector machine(SVM) /
- rubbing position identification

HTML

参考文献(15)

[1]	孙云岭,张永祥,常汉宝.基于定子振动的转子碰摩故障诊断方法研究[J].机械工程学报,2009,22(4):391-394. SUN Yunlin,ZHANG Yongxiang,CHANG Hanbao.Method of rotor rub-impact faults diagnosis based on stator vibration signal[J].Journal of Mechanical Engineering,2009,22(4):391-394.(in Chinese)
[2]	邓艾东,包永强,赵力.基于能量衰减模型的转子碰摩声发射源次梯度投影定位方法[J].机械工程学报,2010,46(9):66-72. DENG Aidong,BAO Yongqiang,ZHAO Li.Positioning of acoustic emission source by using sub-gradient projection based on energy attenuation model[J].Journal of Mechanical Engineering,2010,46(9):66-72.(in Chinese)
[3]	褚福磊,王庆禹,卢文秀.用声发射技术与小波包分解确定转子系统的碰摩位置[J].机械工程学报,2002,38(3):139-143. CHU Fulei,WANG Qingyu,LU Wenxiu.Detective of the rub location in a rotor system with AE sensors and wavelet analysis[J].Journal of Mechanical Engineering,2002,38(3):139-143.(in Chinese)
[4]	Wang Q,Chu F.Experimental determination of the rubbing location by means of acoustic emission and wavelet transform[J].Journal of Sound and Vibration,2001,248(1):91-103.
[5]	Bachschmid N,Pennacchi P,Vania A. Identification of multiple faults inrotor systems[J].Journal of Sound and Vibration,2002,254(2):327-366.
[6]	Han Q K,Yu T,Li H,et al.Hybrid model based identification of local rubbing fault in rotor systems[J].Key Engineering Materials,2005,293/294:355-364.
[7]	Chu F,Lu W.Determination of the rubbing location in a multi-disk rotor system by means of dynamic stiffness identification[J].Journal of Sound and Vibration,2001,248(2):235-246.
[8]	Kicinski J.Rotor dynamics[M].Gdansk:Institute of Fluid-Flow Machinery,2005.
[9]	何田,刘耀光,陈亚农,等.基于声发射波束形成法的转静子碰摩故障定位[J].航空动力学报,2011,26(10):2207-2213. HE Tian,LIU Yaoguang,CHEN Yanong,et al.Method for locating rub fault of rotor-stator based on acoustic emission beamforming[J].Journal of Aerospace Power,2011,26(10):2207-2213.(in Chinese)
[10]	卢文秀,褚福磊,郭丹.基于遗传算法的碰摩位置辨识[J].清华大学学报:自然科学版,2005,45(2):208-211. LU Wenxiu,CHU Fulei,GUO Dan.Rubbing location identification based on genetic algorithms[J].J Tsinghua University:Sci ＆ Tech,2005,45(2):208-211.(in Chinese)
[11]	袁胜发,褚福磊.球结构支持向量机在转轴碰摩位置识别中的应用[J].振动与冲击,2009,28(8):70-77. YUAN Shengfa,CHU Fulei.The application on shaft rubbing positions identification based on sphere support vector machine[J].Journal of Vibration and Shock,2009,28(8):70-77.(in Chinese)
[12]	马建仓,叶佳佳.基于小波包分析的航空发动机故障诊断[J].计算机仿真,2010,27(2):48-51. MA Jiancang,YE Jiajia.Aero-engine faults diagnosis based on wavelet packet analysis[J].Computer Simulation,2010,27(2):48-51.(in Chinese)
[13]	王国胜.支持向量机的理论与算法研究 .北京:北京邮电大学,2007. WANG Guosheng.Research on theory algorithm for support vector machine classifier .Beijing:Beijing University of Posts and Telecommunications.(in Chinese)
[14]	苗学问,田喜明,洪杰.基于支持向量机的滚动轴承状态寿命模型[J].航空动力学报,2008,23(12):2190-2195. MIAO Xuewen,TIAN Ximing,HONG Jie.Grade-life model of rolling bearing based on support vector machine[J].Journal of Aerospace Power,2008,23(12):2190-2195.(in Chinese)
[15]	尉询楷,陆波,汪诚,等.支持向量机在航空发动机故障诊断中的应用[J].航空动力学报,2004,19(6):844-848. WEI Xunkai,LU Bo,WANG Cheng,et al.Application of support vector machines to aero-engine fault diagnosis[J].Journal of Aerospace Power,2004,19(6):844-848.(in Chinese)
