电控旋翼气动特性建模与风洞试验验证

陆洋; 王超

电控旋翼气动特性建模与风洞试验验证

陆洋,
王超

南京航空航天大学航空宇航学院直升机旋翼动力学国防科技重点实验室,南京 210016

基金项目: 国防科技重点实验室基金项目(502090C40); 航空科技创新基金(08A52001)

计量
- 文章访问数: 1512
- HTML浏览量: 93
- PDF量: 1085
- 被引次数: 0
出版历程
- 收稿日期: 2012-01-14
- 刊出日期: 2013-01-28

Aerodynamic characteristic modeling of electrically controlled rotor and wind tunnel test verification

LU Yang,
WANG Chao

Science and Technology on Rotorcraft Aeromechanics Laboratory, College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 首先建立了带襟翼翼型的非定常气动力模型,继而基于Peters-He广义动态尾迹理论,考虑襟翼偏转对电控旋翼叶素环境的影响,建立了电控旋翼有限状态尾迹模型;进一步基于Theodorsen理论推导出电控旋翼桨叶挥舞响应与桨叶变距和襟翼操纵量的关系,综合以上建立了电控旋翼气动特性分析模型.以改进型电控旋翼试验系统为平台进行了风洞试验,测量了不同风速、不同襟翼操纵条件下的电控旋翼气动力、桨距、襟翼偏角及旋翼挥舞角的变化情况.理论计算结果与试验数据符合情况良好,验证了所建立的分析模型的正确性,并得出以下结论:旋翼转速一定时,桨叶变距与襟翼操纵基本呈线性关系;旋翼拉力随襟翼总距的增加而逐渐减小,襟翼总距较大时,其实际气动效率略有下降;前飞状态时,襟翼总距操纵会引起桨叶的纵向周期变距.
- 电控旋翼 /
- 后缘襟翼 /
- 尾迹 /
- 气动力 /
- 风洞试验
Abstract: Firstly,the unsteady aerodynamic model of the airfoil with trailing-edge flap was developed.Secondly,the finite state wake model of electrically controlled rotor(ECR) based on the Peters-He generalized dynamic wake theory was developed,in which the effect of the trailing-edge flap on the rotor aerodynamic environment was considered.Combined with the relationship among the blade flapping angle, the blade pitch and the deflection angle of the trailing-edge flap,the model of calculating the aerodynamic characteristics of ECR was established finally.Then,wind tunnel tests were conducted,in which the aerodynamic force,the blade pitch,the deflection angle of the trailing-edge flap and the blade flapping angle varying with different test statuses were measured.Theoretical results basically coincided with the experimental data, which verified the correction of the theoretical model. Conclusions are drawn as follows: with the fixed rotor speed, there is a linear relationship between blade pitch response and flap control; rotor thrust decreases with the increase of flap collective control, and actual aerodynamic efficiency of the flap decreases under large collective control; in forward flight, flap collective control can cause changes of blade cyclic pitch.
- electrically controlled rotor(ECR) /
- trailing-edge flap /
- wake /
- aerodynamic force /
- wind tunnel test

HTML

参考文献(16)

[1]	Shen J,Yang M,Chopra I.Swashplateless helicopter rotor with active trailing-edge flaps for flight and vibration control[J].Journal of Aircraft,2006,43(2):346-352.
[2]	Bao J,Allen K,Chopra I.Design and test of a Mach scale swashplateless rotor using smart trailing-edge flaps .Phoenix:American Helicopter Society 62th Annual Forum,AHS,2006.
[3]	Falls J,Datta A,Chopra I.Performance analysis of trailing edge flaps in helicopter primary control[J].Journal of the AHS,2008,55(3):5-15.
[4]	Straub F K,Anand V R,Birchette T S,et al,Wind tunnel test of the smart active flap rotor .Grapevine:American Helicopter Society 65th Annual Forum,AHS,2009.
[5]	Chaudhry Z A,Wake B E,Bagai A,et al,Active rotor development for primary and secondary flight control .Grapevine:American Helicopter Society 65th Annual Forum,AHS,2009.
[6]	Lorber P F,Oneill J O,Isbella B.Whirl test of a large scale high authority active flap rotor .Phoenix:American Helicopter Society 66th Annual Forum,AHS,2010.
[7]	陆洋.电控旋翼系统研究 .南京:南京航空航天大学,2004. LU Yang.Research on the electrically controlled rotor system .Nanjing:Nanjing University of Aeronautics and Astronautics,2004.(in Chinese)
[8]	陆洋,王浩文,高正.电控旋翼气弹动力学建模研究[J].航空动力学报,2006,21(6):1022-1026. LU Yang,WANG Haowen,GAO Zheng.Aeroelastic dynamic modeling of the electrically controlled rotor[J].Journal of Aerospace Power,2006,21(6):1022-1026.(in Chinese)
[9]	陆洋,王浩文,高正.用于电控旋翼气弹分析的带襟翼翼型气动力模型[J].空气动力学报,2005,23(2):243-247. LU Yang,WANG Haowen,GAO Zheng.Aerodynamic model of airfoil with flap used for electrical controlled rotor aeroelastic analysis[J].ACTA Aerodynamic Sinica,2005,23(2):243-247.(in Chinese)
[10]	夏鹤鸣,陆洋.改进型电控旋翼桨距控制的建模与仿真[J].计算机仿真,2010,27(2):72-75. XIA Heming,LU Yang.Modeling and simulation of the blade pitch control system of the improved electrically controlled rotor[J].Computer Simulation,2010,27(2):72-75.(in Chinese)
[11]	Leishman J G,Beddoes T S.A generalized model for airfoil unsteady aerodynamic behavior and dynamic stall using the indicial method .Washington DC:American Helicopter Society 42nd Annual Forum,AHS,1986.
[12]	Hariharan N,Leishman J G.Unsteady aerodynamics of a flapped airfoil in subsonic flow by indicial concepts .New Orleans:36th AIAA/ASME/ASCE/AHS/ASC Structures,Structural Dynamics and Materials Conference,AIAA,1995.
[13]	Theodorsen T,Garrick I E.Nonstationary flow about a wing-aileron-tab combination including aerodynamic balance .NACA-736,1942.
[14]	He C J.Development and application of a generalized dynamic wake theory for lifting rotors .Atlanta:Georgia Institute of Technology,1989.
[15]	Peters D A,He C J.A closed-form unsteady aerodynamic theory for lifting rotors in hover and forward flight .St Louis:American Helicopter Society 43rd Annual Forum,AHS,1987.
[16]	Lieshman J G.Principles of helicopter aerodynamics[M].Cambridge:Cambridge University Press,2006.
